Side 1/25

REV D DATE: 06/23/2023

21-26059_REVEAL_USER MANUAL_NE(L)(H)HSSV_HTD_SELF-SVC_SLIDE-IN_CASE

SCC P/N

21-26059

REVEAL® SLIDE-IN SELF-SERVICE HEATED MERCHANDISERS

> REAR SLIDING DOOR UNITS WITH PERFORATED PLENUMS THAT SLIDE IN TANDEM WITH DOORS

> SOLID BACK UNITS WITH FIXED METAL PERFORATED PLENUMS

> CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE!

> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!

Reveal

USER

MANUAL

READ AND SAVE THESE INSTRUCTIONS

Model NE4835HSSV Slide-In Unit Shown With

Solid Perforated Metal Back and 3 Shelves

(Illustration Shown May Not Reflect Every

Feature Or Option of Your Particular Case)

Important! See Structural Concepts

Reveal® Self-Service Counter Guide

P/N 21-26260 (That Accompanies This

Manual) For Cabinetry Construction/

Design Requirements.

Model NE4835HSSV Slide-In Unit Shown With

Rear Sliding Doors and 3 Shelves

(Illustration Shown May Not Reflect Every

Feature Or Option of Your Particular Case)

Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com

TABLE OF CONTENTS

TABLE OF CONTENTS …………………………………………………………………………………...…...

REVEAL® FREE STANDING HEATED SELF-SERVICE MODEL APPLICABILITY &

DIMENSIONS ....………………………………………………………………………………………..

REVEAL® SLIDE-IN SELF-SERVICE HEATED MODEL APPLICABILITY & DIMENSIONS ....……..

INSTALLATION: DISCONNECTION/REMOVAL OF CASE FROM SKID / REVIEW CASE

SURROUNDINGS ……………………………………………………………………………….……..

INSTALLATION, CONT’D: SHELVING ASSEMBLIES / SHELVING RETAINER CLIP REMOVAL ...

INSTALLATION, CONT’D: PLUG IN UNIT / MAIN POWER SWITCH AND LED LIGHT SWITCH .....

CASE DESIGN & FIELD SERVICE PARTS LIST: CASE FRONT AND REAR VIEWS ……….………

CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: ELECTRICAL BOX COMPONENTS ....

CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: HEATER / DECKS / BAFFLE / AIR

DEFLECTOR ………………………………………………………………………………..….……….

CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: SHELVING ASSEMBLY COMPONENTS

CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: LED LIGHT / PLUG / THERMOMETER ..

CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: REAR PIKE DOORS / REAR

PERFORATED PLENUM DOORS ………………………………………………...…….…….....….

CASE STARTUP / HEATER SETTINGS / LIGHTS SWITCH / SHUTTING DOWN CASE .……………

PRODUCT PLACEMENT / AIRFLOW CONSIDERATION / LOAD LINES ………………………….…..

CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ..…....…...…………...….

PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER) ……....

TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL ONLY) ...………………......

TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ……….

SERIAL LABEL INFORMATION & LOCATION ..…………………………….……...…....……………..…

PROGRAMMABLE CONTROLLER INFORMATION ………………………………………………………

TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ...…...…...….....

4-5

19-20

21-22
