Side 1/22

Before contacting, you must have the following:

Serial no., model no., store no., store address, details (photos, leak locations,

damage, store’s ambient conditions, etc.)

Support: structuralconcepts.com/support

Tech Service/Warranty: 1 (800) 433-9490, EXT. 1

Hours: Monday – Friday, 8am to 8pm EST (Closed holidays)

21-33829 REVEAL REFRIGERATED SERVICE MANUAL-EN REV B DATE: 12/05/2024

Reveal® User Manual

PART NUMBER: 21-33829

Please Note

Your specic model number is located on the

serial label (usually at the case rear). However,

label locations may vary depending on the

model – see page 20 for more details.

Models shown on this cover sheet do not

represent all models covered by this manual.

Models

NE3613RSV

NE3620RSV

NE3627RSV

NE3635RSV

NE4813RSV

NE4820RSV

NE4827RSV

NE4835RSV

NE6020RSV

NE6027RSV

NE6035RSV

NE7220RSV

NE7227RSV

NE7235RSV

NR3633RSV

NR3640RSV

NR3647RSV

NR3655RSV

NR4833RSV

NR4840RSV

NR4847RSV

NR4855RSV

NR6040RSV

NR6047RSV

NR6055RSV

NR7240RSV

NR7247RSV

NR7255RSV

Reveal® User Manual 2

Overview / Type / Compliance / Warnings / Precautions / Wiring / Plugs .............................................................................. 3-5

Installation: Case Removal From Skid .............................................................................................................................................6-7

Installation: Start Up ..............................................................................................................................................................................8

Placement of Case ................................................................................................................................................................................9

Product Placement .............................................................................................................................................................................. 10

Shelf and Deck Load Limits .................................................................................................................................................................. 11

Front Panel Removal ............................................................................................................................................................................12

Rear Panel Removal .............................................................................................................................................................................13

Cleaning Schedule (To Be Performed by Store Personnel) ........................................................................................................... 14

Preventative Maintenance ............................................................................................................................................................15-19

Serial Label Information & Location ..................................................................................................................................................20

Programmable Controller Information ..............................................................................................................................................21

Technical Service Contact Information / Warranty Information ..................................................................................................22

Table of Contents
