REV N DATE: 06/27/2023
USER MANUALS\20-78347_REVEAL_USER MANUAL_NR(L)(H)RRSSV_REF_COMBO_OVER-UNDER_CASE
SCC P/N
20-78347
USER
MANUAL
REVEAL® FREE STANDING OVER-UNDER REFRIGERATED COMBO MERCHANDISERS
> CONVERTIBLE UPPER SECTION MAY BE EITHER AMBIENT OR REFRIGERATED
> REFRIGERATED LOWER SECTION
> SELF-CONTAINED OR REMOTE UNITS
> UPPER SECTION: REAR SLIDING DOORS
> OPTIONAL RISERS (IN LIEU OF SHELVING)
> LOWER SECTION: REAR SLIDING DOORS WITH
PERFORATED ACRYLIC PLENUMS OR SOLID BACK PANELS
> CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE!
> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!
Models Are Shipped WITHOUT
Panels and Cladding Attached.
See Pages 10 & 11 For Component
Attachment Instructions.
Reveal
READ AND SAVE THESE INSTRUCTIONS
®
Reveal® Model NR3631RRSSV
Self-Service Solid Back Rear Panel
Optional Product Steps / Shown As
Shipped From Factory (Without
Components) / Front Slide-Out
Access To Condenser Package
Reveal® Model NR3631RRSSV /
Rear Sliding Doors and Acrylic
Perforated Plenums / Shown As
Shipped From Factory (Without
Components) / Rear Slide-Out
Access To Condenser Package
Reveal® Model
NR4838RRSSV
Rear Sliding Doors
and Acrylic Perforated
Plenums / Cladding
Shown Attached
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS …………………………………………………………………………………...…...
REVEAL® REFRIGERATED OVER-UNDER COMBO MODEL APPLICABILITY & DIMENSIONS ..
OVERVIEW / DISPLAY TYPE I vs. II / COMPLIANCE / WARNINGS / PRECAUTIONS ……………...
INSTALLATION: TOE-KICK & GRILLE REMOVAL / DISONNECTING CASE FROM PALLET …….
INSTALLATION, CONT’D: CASTER ADJUSTMENT / LOCK / UNLOCK / CASE REMOVAL
FROM PALLET .……….………………………………………………………………………..……...
INSTALLATION, CONT’D: SHELVING ASSEMBLY COMPONENTS ...………………………………...
INSTALLATION, CONT’D: MAIN POWER SWITCH / TOE-KICK & AIR INTAKE GRILLE / PLUG-IN
INSTALLATION, CONT’D: SHIPPING BRACE / ATTACHING FRONT PANEL COMPONENTS /
HANDLES ……………………………………………………………………………………………….
INSTALLATION, CONT’D: ATTACHING SIDE PANELS, REAR PANEL AND REAR GRILLE ……..
INSTALLATION, CONT’D: OPTIONAL ACRYLIC SECURITY COVER ………………………………...
CASE DESIGN: FRONT OF CASE (UNITS WITH LOWER REAR DOORS) .......................................
CASE DESIGN, CONT’D: REAR OF CASE (UNITS WITH LOWER REAR DOORS) ..……………….
CASE DESIGN, CONT’D: CONTROLLER / DC DRIVERS / MAIN POWER SWITCH /
CONDENSER COIL FILTER ….………………………………………………………………………
CASE DESIGN, CONT’D: NIGHT CURTAIN ACCESS AND OPERATION ……………………………..
CASE DESIGN, CONT’D: UPPER SECTION - AMBIENT VS. REFRIGERATED VIA REAR
COVER/BAFFLE POSITION ………………………………………………………………………….
CASE DESIGN, CONT’D: TUB AREA (AFTER DECK PAN REMOVAL) ……………………………….
CASE DESIGN, CONT’D: LED LIGHT SWITCH LOCATIONS / LED LIGHTS / THERMOMETERS ..
CASE DESIGN, CONT’D: REAR SLIDING DOOR REMOVAL / REAR PERFORATED PLENUM
CONTROL ………………………………………………………………………………………………
CASE DESIGN, CONT’D: CONDENSER PACKAGE (SELF-CONTAINED UNITS ONLY) …………..
PRODUCT PLACEMENT / UPPER SECTION & HONEYCOMB AIRFLOW / LOAD LINES ………….
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ..…....…...…………...….
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER) ……....
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL ONLY) ...………………......
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ……….
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) -
CONDENSING SYSTEM ..………………………………………………………………………...….
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) -
EVAPORATOR SYSTEM ...…………………………………………………………………………...
SERIAL LABEL INFORMATION & LOCATION ..…………………………….……...…....……………..…
PROGRAMMABLE CONTROLLER INFORMATION ………………………………………......………….
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION…………………..
2
3
4-5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24-26
27-28
29-32
33
34
35
36
37
