MY.SUBARU.COM

Your Subaru vehicle comes with a unique online resource that helps make your ownership

experience more convenient and enjoyable. My.Subaru.com is a personalized website that

offers useful features and content that makes it easy for you to manage your vehicle care

and enjoy all the beneﬁts of Subaru ownership. Log on to My.Subaru.com and access

features such as: automated service history, e-mail maintenance reminders, online

Owner’s Manual, warranty information, maintenance schedules and much more...

Access your site today @ My.Subaru.com

For Roadside Assistance, please call our 24-hour toll-free number at 1-800-261-2155.

Subaru of America, Inc.

Subaru Plaza

P.O. Box 6000

Cherry Hill, NJ 08034-6000

All information contained within this Subaru Owner Reference Guide was accurate

at the time of publication. We reserve the right to change features, operation

and/or functionality of any vehicle speciﬁcation at any time. Your Subaru dealer

is the best source for the most current information. For detailed operating and

safety information, please consult your Owner’s Manual.

MSA5B1005A

Printed in USA 07/09

Issued 04/09

2010 LEGACY/OUTBACK Owner Reference Guide

199379_10a_LegOutback_ORG_072709.indd 1-2 7/27/09 10:40:32 AM

Ve h i c l e Dy n a m i c s co n t r o l

Pressing the switch deactivates the Vehicle

Dynamics Control system. The indicator light

comes on. With the Vehicle Dynamics Control

system deactivated, the vehicle will behave like

a model without it. Press the switch again to

reactivate the system. The indicator light will

go off.

li g h t co n t r o l s

To turn on the

headlights, twist

the end of the

turn signal lever

forward. Push the

turn signal lever

up to activate the right signal; push down for

left signal. To change headlights from low

beam to high beam, push the lever forward

and release. To turn on the fog lights, move the

fog light switch forward to the

position. To

turn off, move the switch to the “OFF” position.

When the dial on the lower left dash is turned

downward, illumination becomes dim. When

the dial is turned upward, illumination becomes

bright. When the dial is fully turned upward

while the light switch is on, instrument panel

illumination becomes full bright.

Da y t i m e ru n n i n g li g h t s

Daytime running lights are standard on your

vehicle. A reduced brightness high beam will be

automatically turned on by the daytime running

light system when the engine has started and

the parking brake is fully released or the light

switch is in the “OFF” or “

” position. The

brightness of the illumination of the high beam

headlights is reduced by the daytime running

light system. You must always switch on your

headlights when it’s dark outside by turning the

light switch to the

position.

ch e c k en g i n e li g h t

If this light comes on and stays on, see your

Subaru dealer as soon as possible. There may be

a problem with your emission control system.

NOTE: If you have recently fueled your vehicle,

the “CHECK ENGINE” light may stay on due to

a missing or loose fuel ller cap. (The cap should

be tightened until a click is heard.)

srs ai r b a g sy s t e m

Wa r n i n g li g h t

The SRS airbag system warning light “AIRBAG”

will illuminate for about 6 seconds and then

go off when the ignition key is turned to the

“ON” position. If the warning light continuously

illuminates, there may be a malfunction in the

seatbelt pretensioners and/or the SRS airbag

system. Immediately take your vehicle to

your nearest Subaru dealer to have the

system checked.

lo W Fu e l Wa r n i n g li g h t

If this light appears, refuel promptly; your tank

is nearly empty. Approximately 2.6 U.S. gallons

of fuel remain.

abs Wa r n i n g li g h t

If the ABS (Anti-lock Brake System) light comes

on and stays on after the vehicle speed exceeds

approximately 8 mph, the ABS system may not

be working properly. (The conventional brake

system will continue to operate normally.) Have

the ABS system checked by your Subaru dealer

at the rst available opportunity.

cr u i s e co n t r o l

SET Push the main “CRUISE” switch located

on the steering wheel. The “CRUISE” indicator

light on the instrument panel will turn on. Press

the accelerator pedal until your vehicle reaches

the desired speed. Push the “RES/SET” switch

to the “SET” side and release. Ease off the

accelerator pedal. Your vehicle will maintain the

desired speed.

TEMPORARY CANCEL There are four ways

to temporarily cancel cruise control: depress the

brake pedal; push the “CANCEL” button; press

the clutch pedal (manual transmission); or, shift

the selector lever into the “N” position (AT, CVT

and MT models).

RESUME

Push the “RES/SET” switch to the

“RES” side.

SHUT OFF To quit cruise control, push the

main “CRUISE” switch again, or, when the

vehicle is stopped, turn the ignition switch to

the “ACC” or “LOCK” position.

INCREASE SPEED Push the “RES/SET”

switch to the “RES” side, hold until your vehicle

reaches the desired speed, and release. To

increase speed using the accelerator pedal,

press the pedal until you reach the desired

speed. Push the “RES/SET” switch to the “SET”

side to set the speed.

DECREASE SPEED Push the “RES/SET” switch

to the “RES” side, hold until your vehicle slows

to the desired speed, and release. To decrease

the speed using the brake pedal, press the pedal

to release cruise control temporarily. When the speed

decreases to the desired rate, push the “RES/

SET” switch to the “SET” side to set the speed.

Wi n D s h i e l D Wi p e r s

To turn wipers on,

press the wiper

control lever down

one level for

intermittent, two

levels for low, or

three levels for high speed. Return the lever

to the “OFF” position to stop wipers. For a

single wipe / mist, pull the lever toward you. To

spray washer uid, press the washer button at

the end of the wiper control lever. To operate

the rear wiper, turn the knob on the end of

the control lever forward to intermittent,

continuous, or wash position. Turn the end of

the lever backward for wash operation when

the rear wiper is not in use.

When the transmission is placed in reverse, the

rear wiper will operate continuously even if the

rear wiper switch is in the “INT” position.

cl o c k

WITHOUT NAVIGATION Press the “+”

button to advance time or the “–” button to

reverse the time.

WITH NAVIGATION Refer to the separate

“Operating Instructions for Navigation System.”

1 7

nstrument panel

Instrument panel shown

with optional accessories.

Dy n a m i c , pr o g r e s s i V e , re a l Wo r l D Ve r s a t i l i t y

Your 2010 Legacy/Outback offers the rugged, go-anywhere attitude that’s essential to an active lifestyle, as well as the reﬁned

performance that’s equally at home on city streets or highways. The Legacy/Outback models offer intelligent design and practicality, while the Legacy 2.5GT combines the conﬁdence and safety of All-Wheel

Drive in a package that does not compromise on performance. Available with a 6-speed manual transmission (6MT), Lineartronic

Continuously Variable Transmission (CVT) or the 5-speed Automatic Transmission

(5AT), depending on the model . Whether you’ve set the cruise control for a long, highway straightaway, or you are steering your way through winding roads, we’ll be there for the journey ahead. We wish

you many happy miles in your new Subaru and look forward to providing you with a satisfying owner experience.

199379_10a_LegOutback_ORG_072709.indd 3-4 7/27/09 10:40:49 AM
