USE AND CARE GUIDE
If you need service or call with a question, please have the following information ready.
We advise you to keep this Owner’s Manual in your possession.
Model: _______________________ Serial number: _____________________________
Options added: ___________________________________________________________
Date of Purchase _______________ Where Purchased___________________________
BUILT-IN UNDER-COUNTER REFRIGERATORS
BUILT-IN UNDER-COUNTER FREEZERS
BUILT-IN WINE CELLARS
OUTDOOR REFRIGERATORS AND FREEZERS
INDOOR DRAWER REFRIGERATORS AND FREEZERS
OUTDOOR DRAWER REFRIGERATORS AND FREEZERS
AUTO-DEFROST BI605FF SERIES
MODELS
• ALB651 / ALB653B SERIES • SCR600LOS SERIES
• ALB751 / ALB753B SERIES • SP6 DRAWER SERIES
• BI540 / BI541 SERIES • SP6DS2DOS SERIES
• BI605FF SERIES • SP6DSSTBOS SERIES
• CT66BI / CT67BI SERIES • SPF5DSSTB
• FF6BI & FF7BI SERIES • SPR601OS SERIES
• FS62BI SERIES • SPR7OS SERIES
• SCFF55 SERIES • SWC6GBI SERIES
• SCR600BI SERIES • OUTDOOR REFRIGERATORS
Felix Storch, Inc.
Page 2
SUMMIT PROFESSIONAL DIV.
APPLIANCE SAFETY
Your safety and the safety of others are very important to us.
We have provided many important safety messages in this manual and on your appliance. Always read
and obey all safety messages. You can be killed or seriously injured if you do not follow these instructions.
Safety messages will tell you what the potential hazard is, how to reduce the chance of injury, and what
can happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS!
WARNING: To reduce the risk of fire, electric shock or injury when
using your refrigerator/freezer, follow these basic precautions:
Plug into a grounded 3-prong outlet.
Do not remove ground prong, nor use a 3/2 adapter.
Do not use an extension cord.
Use care not to plug into outlets controlled by wall switches.
Disconnect power before servicing.
After servicing, replace all parts and panels before operating.
Use nonflammable cleaners.
Keep flammable materials and vapors, such as gasoline, away from appliances.
Use two or more people to move and install appliance.
Drawer refrigerators are provided with anti-tip brackets. Always install prior to use.
Proper Disposal of Your Old Appliance
Old appliances can represent a suffocation hazard to children.
Remove doors from your old appliance.
Leave shelves in place.
If an old appliance contains refrigerants, it must be recycled by a licensed service or
disposal company.
Felix Storch, Inc.
SUMMIT PROFESSIONAL DIV. Page 3
INSTALLATION INSTRUCTIONS
UNPACKING Excessive Weight Hazard!
Use two or more people to move and install your appliance.
Failure to do so can result in back or other injury.
ALLOW APPLIANCE TO SIT UPRIGHT FOR 24 HOURS BEFORE TURNING ON, TO ALLOW THE
COMPRESSOR LUBRICANT TO DRAIN.
1. Remove packaging materials.
2. Remove tape and glue residue from surfaces before turning on the appliance. Rub a small amount of liquid
dish soap over the adhesive with your fingers. Rinse with warm water and dry.
3. Do not use sharp instruments, rubbing alcohol, flammable fluids, or abrasive cleaners to remove tape or glue.
These products can damage the surface of your appliance.
4. When Moving Your Appliance:
Your appliance is heavy. When moving the appliance for cleaning or service, be sure to protect the floor.
Always pull the appliance straight out when moving it. Do not wiggle or “walk” the appliance when trying to
move it, because floor damage can occur.
5. Clean Before Using
After you remove all of the packaging materials, clean the inside of your appliance before using it. See the
cleaning instructions in Appliance Care.
6. All upright models have level legs in the front and many also have them in the rear. Level as necessary for
best operation.
7. If your appliance has casters, after moving into place, lock the brakes on those casters supplied with brakes.
Always unlock before moving the appliance for cleaning.
Keep flammable materials and vapors, such as gasoline, away from appliances. Failure to do so can result in
explosion or fire.
LOCATION REQUIREMENTS
IMPORTANT: Do not install the appliance near an oven, radiator, or other heat source, nor in a location where the
temperature will fall below 45°F (7°C). Do not place in direct sunlight.
Check the strength of the floor before installing your appliance. It should hold the weight of a fully-loaded
appliance. Allow at least 1” (2.5 cm) of airspace at the top and on both sides of the appliance and 1” (2.5 cm)
between the back of the appliance and the wall. If the appliance is going to be placed against a wall, if possible,
leave extra space on the hinge side so the door can open wider than its width (to make it easier to remove
shelves or storage bins).
NOTE: This appliance may be installed side by side with another appliance. Allow for a 3’’ (7.5 cm) clearance at
the top and sides, and a 1/4” (0.64 cm) clearance between the appliances.
IF YOUR MODEL HAS THE LETTERS “BI” IN THE MODEL NUMBER OR SUFFIX, OR BEGINS WITH “ALB”, IT
IS DESIGNED FOR BUILT-IN USE AND DOES NOT REQUIRE CLEARANCE EXCEPT IN THE BACK. BE SURE
THAT YOU DO NOT BLOCK THE AIRFLOW UNDER THE APPLIANCE .
Felix Storch, Inc.
Page 4 SUMMIT PROFESSIONAL DIV.
INSTALLATION INSTRUCTIONS
CHOOSING THE RIGHT PLACE
Place the appliance in a dry and regularly ventilated place. It is recommended that this appliance always be operated
in an ambient temperature of at least 60°F and under 85°F. The appliance may be exposed to lower or higher
temperatures but only for a short period of time and the temperature should never be lower than 45°F. Never place the
appliance near heat-emitting devices (e.g., oven, radiator, water heater) and do not expose it to direct sunlight.
RECOMMENDED GROUNDING METHOD
A 115 Volt (AC only) 60 Hz grounded electrical supply equipped with a 15- or 20- amp fuse or circuit breaker is required.
It is recommended that a separate circuit serving only your appliance be provided. Use outlets that cannot be turned
off by a switch or pull chain. Connect this appliance to a 3-prong power supply outlet that has a ground terminal. If you
only have a 2-prong outlet, have it replaced by a qualified technician with an outlet that meets the local codes. DO NOT
USE AN EXTENSION CORD. Required nominal voltage and frequency are indicated on the rating plate. The connection
to the power supply and grounding has to be made according to current standards and regulations. The appliance can
resist temporary voltage fluctuations from -15 to +10%.
FOR OUTDOOR MODELS ONLY
Electrical Shock Hazard! Plug into a grounded 3-prong outlet. Do not remove ground prong. Do not use an adapter.
Do not use an extension cord. Failure to follow these instructions can result in fire or electrical shock.
Many outdoor outlets are controlled by wall switches. Turning power off and then on again may cause the GFCI switch
to trip.
A GFCI (ground fault circuit interrupter) is built into every line cord. Do not defeat or bypass this important safety
feature. The line cord supplied with this appliance is specially designed for outdoor use. Use only a factory-supplied
replacement cord with a GFCI in the event the cord becomes damaged.
You may purchase these cords from either our sales or service department at 718-893-3900 718-328-8700 (sales) or
(service).
They can also be ordered online from www.summitapplianceparts.com
ENERGY SAVING TIPS
The more airflow you can provide around an appliance, the less energy it will use.
If your appliance needs defrosting, keep ice build-up to less than 1/2 inch.
Keep doors or drawers open a minimum of time, and shut securely.
LEVELING YOUR APPLIANCE
1. Locate the two front leveling legs, which may be taped among the packing materials. In most models these legs are
already mounted into the underside of the appliance.
2. Screw these legs into the front holes on the bottom of the appliance. The back of the appliance rests on two fixed
supports. (Built-in models also have rear level legs that can provide more precise leveling).
3. Adjust the front legs just enough to lift the cabinet up off the floor.
4. Place a leveling tool on top of the appliance: first side to side, then front to back. Turn leg counter-clockwise to
raise a corner. Turn leg clockwise to lower a corner.
5. Repeat Step 4 until appliance is level.
6. After appliance is fully loaded, recheck with level as in Step 4.
7. If your appliance is equipped with casters, the two front casters have brakes to prevent rolling. Keep brakes locked,
and unlock for moving only.
Felix Storch, Inc.
SUMMIT PROFESSIONAL DIV. Page 5
APPLIANCE USE
In order to ensure proper temperature, you need to permit proper airflow in the appliance. Do not block any air
vents. If the vents are blocked, airflow will be prevented, and temperature and moisture problems may occur.
Always position contents to allow some airflow between shelves or baskets.
Allow the appliance to cool at least 6 to 8 hours before adding contents. Allow 24 hours for temperature to
stabilize.
NOTE: When the appliance is first started, the compressor will run constantly until the appliance is cold. It may
take 6 to 8 hours (or longer), depending on room temperature and the number of times the appliance door is
opened. After the appliance is cooled, the compressor will turn on and off as needed to keep the appliance at
the proper temperature.
The outside of your appliance may feel warm. This is normal. The appliance’s design and main function is to
remove heat from packages and air space inside the appliance. The heat is transferred to the room air, making
the outside of the appliance feel warm. In some models the condenser that gets warm is inside the side walls,
making these walls warm to the touch.
REVERSING THE DOOR SWING (Selected models)
If you find the direction of opening the door on your appliance inconvenient, on some models you can change it.
Holes on the opposite side have already been prepared in the factory. On models with our wrapped stainless
steel door and 12-inch pro handle (suffix SSTB, SSVH or CSS, or with optional handles “TB” or “SH” ), you must
order these with either a right hand or left hand door swing in advance. These doors cannot be reversed. Models
with suffix SSHH, BIFR, BIIF and CSSHH can be reversed.
TO REVERSE YOUR DOOR
Take off the upper hinge cover from the door and remove the screws that hold the top hinge.
Lift the hinge straight up to free the hinge pin from the socket in the top of the door.
Lift the door up and away to free its bottom socket from the hinge pin.
Remove the screws to the bottom hinge.
Remove the decorative caps from the opposite side and plug the holes from the original side with the
decorative caps.
Move the bottom hinge to the opposite side and tighten the screws. Use any lock washers or nuts if they were
included in the original installation.
Replace door onto the hinge pin on the bottom hinge. Place top hinge pin into door. Insert screws into top
hinge and tighten.
If you notice the door is not hanging straight, loosen the top hinges, adjust the door until it is level and tighten
the screws.
Felix Storch, Inc.
Page 6 SUMMIT PROFESSIONAL DIV.
APPLIANCE OPERATION
Base Grill (some models only)
To Remove and Replace the Base Grill:
1. Open the appliance door and remove the base grill by pulling down and out from the top.
2. Replace the base grill by putting the clips in the openings in the appliance panel. Push in until the base grill snaps into
place.
An optional stainless steel grill is available for some models (model numbers beginning with FF6, FF7, CT66, CT67,
SCR600, FS62, SCFF55, BI540, BI541, SWC6G and outdoor units and drawer units). You can order at
www.summitapplianceparts.com
Changing the light bulb (some models only)
NOTE: Not all appliance bulbs will fit your appliance. Be sure to replace the bulb with one of the same size, shape, base
size and wattage. You can purchase bulbs at www.summitapplianceparts.com
1. Unplug appliance or disconnect power.
2. Remove the light shield. Most models do not require tools.
3. Replace the light bulb with an appliance bulb of the same wattage.
4. Replace the light shield.
5. Plug in appliance or reconnect power.
Loss of Power
After the power is restored, unplug the appliance for 30 minutes to allow the refrigeration system to equalize. During this
time, keep the door closed whenever possible.
REMEMBER: A full appliance stays cold longer than a partially filled one.
Moving Care
1. Remove all containers.
2. Unplug the appliance.
3. Clean it thoroughly.
4. Tape the appliance shut and tape the electrical cord to the cabinet.
When you get to your new location, refer to the Installation Instructions and Appliance Use sections for informa-
tion on installation and setting the controls.
Removal / Replacing of the Drawers on the SP6DS, SP6DSSTB or SP6DS2D models
To remove the drawers from the refrigerator, these directions need to be followed:
1. Pull the drawer out towards you completely.
2. On both sides of the drawer there are stainless steel slides.
3. On each slide there is a black lever.
4. The left lever should be pulled up.
5. The right lever should be pulled down. Both levers should be pulled at the same time while continuing to pull the
drawer.
To re-install the drawers on the appliance:
Simply line up the hinges on the drawer and the hinges on the appliance and gently push the drawer in. Once lined up,
close the drawer completely, then open again to make sure the drawer is on track.
Felix Storch, Inc.
SUMMIT PROFESSIONAL DIV. Page 7
APPLIANCE CARE
Cleaning Your Frost-Free Refrigerator
Use nonflammable cleaners.
Frost-free means that you do not have to defrost your appliance. Frost is removed by air moving and collecting any
moisture and depositing it on the cooling coil. The cooling coil periodically warms up enough to melt the frost, and the
water then flows down to the drain pan (located behind the base grill) where it is evaporated.
Complete cleaning should be done at least once a year.
1. Unplug appliance or disconnect power.
2. Remove all substances.
3. Wash the inside walls with a solution of mild detergent in warm water or 2 tbs (26 g) baking soda to 1 qt (0.95 L) warm
water.
Do not use abrasive or harsh cleaners such as window sprays, scouring cleansers, flammable fluids, cleaning
waxes, concentrated detergents, bleaches or cleansers containing petroleum products on plastic parts, interior and
door liners or gaskets. Do not use paper towels, scouring pads, or other harsh cleaning tools. These can scratch or
damage materials.
4. Rinse well and wipe dry with a clean soft cloth.
5. Use the appropriate cleaning method for your exterior finish.
Painted metal: Wash exteriors with a clean sponge or soft cloth and a mild detergent in warm water. Do not use
abrasive or harsh cleaners, or cleaners designed for stainless steel. Dry thoroughly with a soft cloth. For additional
protection against damage to painted metal exteriors, apply appliance wax (or auto paste wax) with a clean, soft cloth.
Do not wax plastic parts.
6. Plug in appliance or reconnect power.
7. Replace all containers.
Stainless steel: Clean stainless steel with special stainless steel cleaners only. Do not use bleach or any abrasive
cleaners.
Cleaning your cycle defrost or manual defrost refrigerator
Cycle defrost models utilize a system where ice builds up on the rear wall and melts when the compressor is off. Manual
defrost models continually build ice on inner walls.
NEVER USE A METAL OBJECT TO REMOVE ICE FROM THE REAR WALL. IF NEEDED, USE A PLASTIC ICE-
SCRAPER OR A HAIR DRYER.
Clean surfaces, using the same instructions as for frost-free models.
For CSS Models (completely stainless steel) or models with stainless steel doors and handles, please
use only cleaners especially made for stainless steel.
Felix Storch, Inc.
Page 8 SUMMIT PROFESSIONAL DIV.
TEMPERATURE SELECTION
YOUR APPLIANCE MAY HAVE A MECHANICAL (DIAL) OR DIGITAL THERMOSTAT.
INSTRUCTIONS FOR BOTH FOLLOW:
MECHANICAL THERMOSTAT INSTRUCTIONS
The refrigerator is controlled with a thermostat knob located inside the unit, toward the upper right-hand corner. Turn the knob clockwise from
the
STOP (0)
position toward the higher numbers for colder temperatures.
Temperature Controls
Higher settings on the knob (higher numbers) mean lower temperatures (colder) in all compartments of the appliance. At
the coldest settings, temperatures in some spots of the interior of the appliance may even drop below 32°F. Use higher
thermostat settings only when required or recommended. When the ambient temperature is normal, we recommend the
medium setting.
Changes of the ambient temperature affect temperature in the interior of the appliance so keep this in mind when
choosing the setting of the thermostat knob.
In the STOP (0) position the appliance does not operate (the cooling system is switched off), yet power supply is not interrupted (the light goes on
when you open the refrigerator door).
The temperature in the refrigerator and in the freezer compartment also depend on how often you open the door.
In all small refrigerators and freezers without interior fans, temperatures are coldest near the bottom, and occasionally near the rear. Place
contents accordingly. It is best not to operate these units mostly empty. If temperatures are erratic, try putting some water bottles or freezer packs
inside to create a load for the compressor.
DIGITAL THERMOSTAT INSTRUCTIONS
If you find that it is necessary to change the temperature setting for your digital thermostat-controlled appliance, please refer to the following
instructions. The front panel of the thermostat is illustrated here:
To see the SETPOINT:
Push and immediately release the SET key. The display will show the point value. Wait 5 seconds and the probe SET
value will display again.
To change the SETPOINT:
Push and hold the SET key for more then 3 seconds to change the setpoint value. The value of the setpoint will be
displayed and the “snowflake” LED will start blinking. To change the SET value , push the up or down arrows to the
desired setting. The new setting will be memorized after 15 seconds, provided no other keys are pushed.
Note: The minimum and maximum range of your thermostat is preset and locked by us, so it cannot easily be accidentally
moved between freezer and refrigerator temperatures. To reset this range lock, either call us or find information on
our website under Troubleshooting.
Up & Down arrows
SET key
Felix Storch, Inc.
SUMMIT PROFESSIONAL DIV. Page 9
KEYPAD LOCK (optional on most models)
Factory set default password: T
he factory set default password is 0123. If the default password is lost
,
press the key (located inside the battery box) for 30 seconds, then wait for the warning sound
which signifies the factory set default password has been restored.
To set the password: While door is open, press the key (located inside the battery box) until it
jingles, enter the 0123 password then the # key within 10 seconds to confirm. Enter the password (1-16
digits), then press # again to confirm. A total of 10 passwords can be set.
Note: Each password starts from the number 0 to 9 in order. The first password starting with 0 is the default password.
For example, use 1xxx, then 2xxx etc. for 10 users.
Changing password: While the door is open, press the key (located inside the battery box) until it jingles, enter the
old password and press # within 10 seconds to confirm. Enter new password then press # to confirm. Note that the first
digit cannot be changed.
To open the door: While the door is closed, press the key, enter the password then press again to confirm.
To lock door manually: Press #.
Function setting of automatic lock: To set the auto-lock to lock on a preset time interval, press the key (inside the
battery box), enter a number (the time interval in seconds from 10-99) then press # to confirm. The auto-lock time can be
set between 10-99 seconds after opening the door. If the time is set less than 10 seconds, the door will not lock
automatically, only manually.
Deleting the door-opening passwords: Press the key, enter default password followed by 0000, then press # and
all the door-opening passwords will be deleted except for the default password.
Note: To access the battery box you need to remove only the two small screws on the top and bottom of that cover. Do
not remove the 4 screws holding the keypad and cover to the appliance door.
IF YOUR MODEL HAS A FRONT LOCK (SELECTED MODELS)
Your lock has a feature called automatic key eject. To lock or unlock the appliance, you must push and hold the key in the
lock while turning. The lock is spring-loaded, so the key cannot be left in the lock.
If the key is lost, contact your dealer or SUMMIT APPLIANCE to purchase a replacement. Always give the model and
serial number of your appliance when re most models can be ordered online at questing a replacement key. Keys for
www.summitapplianceparts.com
NEVER KEEP KEYS WITHIN THE REACH OF CHILDREN
Produkt Specifikationer
| Mærke: | Summit |
| Kategori: | Køleskab |
| Model: | ALB753BSSHV |
Har du brug for hjælp?
Hvis du har brug for hjælp til Summit ALB753BSSHV stil et spørgsmål nedenfor, og andre brugere vil svare dig
Køleskab Summit Manualer
9 Juli 2025
9 Juli 2025
9 Juli 2025
9 Juli 2025
9 Juli 2025
8 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
25 Juni 2025
Køleskab Manualer
- True
- Mercury
- AKAI
- Krowne
- Hatco
- InAlto
- Teka
- Kenmore
- SPT
- Goddess
- Igloo
- John Lewis
- Changhong
- Palsonic
- GE
Nyeste Køleskab Manualer
23 Juli 2025
23 Juli 2025
23 Juli 2025
22 Juli 2025
22 Juli 2025
22 Juli 2025
22 Juli 2025
22 Juli 2025
22 Juli 2025
22 Juli 2025
