INSTRUCTIONS AND
RECOMMENDATIONS FOR THE USE,
INSTALLATION AND MAINTENANCE OF
BUILT-IN GAS COOKTOPS
Dear customer,
Thank you for buying one of our products.
We are sure that this new, modern, functional and practical appliance, made using the finest quality
materials, will fully satisfy your requirements. This new appliance is very easy to use, but in order to
obtain the best results, we strongly recommend that you read this booklet carefully before use.
These instructions are valid exclusively for countries indicated on the label of the appliance.
The manufacturer cannot be considered responsible for any damages to people or to things in the
event of incorrect installation or improper use of the appliance.
Felix Storch, Inc.
Summit Appliance Division
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, New York 10474
www.summitappliance.com
MODEL: GC22SS - GC527SS - GC5271W - GC5272B
The Manufacturer cannot be held responsible for any imprecision due to printing or copying errors
contained in this booklet. The figures shown are purely indicative. We reserve the right to make any
changes to our products which we consider to be necessary or useful, also in the interest of the user,
without affecting their essential characteristics in terms of functionality and safety.
This cooktop was designed to be used exclusively as a cooking appliance: any other use (such as
heating rooms) is to be considered improper and dangerous.
COD. 04037GT - 11..05.2017
2
TABLE OF CONTENTS
Important Safeguards .......................................................................... 3
Location of Parts ................................................................................. 4
Installation..................................................................................... 5 - 8
Installing the Cooktop. ................................................................ 5
Sealing the Cooktop. .................................................................. 6
Room Ventilation. ........................................................................ 6
Gas Connection. ......................................................................... 7
Electrical Connection. ................................................................. 8
Adjustments ......................................................................................... 9
Conversions .................................................................................. 10-11
Using the Cooktop .............................................................................. 12
Lighting the Burners................................................................... 12
Proper Use of the Burners. .................................................. 12-13
Cleaning .............................................................................................. .14
Servicing. ............................................................................................ .15
Replacing Components
Limited Warranty................................................................................ .16
3
IMPORTANT SAFEGUARDS
1) SAFETY INSTRUCTIONS
For all appliances:
●
The product shall be installed according to the statement that the installation must conform with local
codes
or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54.
●
The product must be electrically grounded in accordance with local codes or, in the absence of local
codes, with the National Electrical Code, ANSI/NFPA 70.
●
Make sure the gas connection complies with local codes and regulations. In the absence of local codes,
installations must comply with the American National Standard, National Fuel Gas Code ANSI Z223 / NFPA
54 or Canadian CAN / CGA_B 149.1 or CAN / CGA-149.2.
●
The appliance and its individual shutoff valve must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of ½ psi (3.5 kPa). The maximum
gas supply pressure is 4 inch WC and 11 inch WC and the gas pressure regulator provided is regulated
to 1 inch water column above the manufacturer’s specified manifold pressure.
●
Always disconnect all cord-connected appliances before servicing. Appliances shall include
instructions relative to location of the wall
receptacle and a warning to the user to disconnect the
electrical supply before servicing the
appliance.
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
●
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
2) WHAT TO DO IF YOU SMELL GAS
-
Do not try to light any appliance.
-
Do not touch any electrical switch; do not use any phone in your building.
-
Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
-
If you cannot reach your gas supplier, call the fire department.
●
Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
●
Save any nozzles removed from the appliance for future use.
●
The maximum depth of cabinets installed above the cooktop should be 13 inches (330 mm).
●
Keep the appliance clear and free from combustible materials, gasoline and other flammable vapors
and liquids.
●
Do not obstruct the flow of gas or block any air vents.
●
Shut off gas to the unit by manually closing the independent gas valve before performing any pressure
testing of the gas supply system with test pressures equal to or lower than 1/2 psi (3.5 kPa).
4
LOCATION OF PARTS
: GC22SSMODEL
MODELS :
GC527SS
GC5271W
GC5272B
art No. Description Heat supplied
1
Ultra rapid burner 11 000 Btu/h
2 Fast burner 10 000 Btu/h
3 Auxiliary burner 3 550 Btu/h
4 Semirapid burner 6 100 Btu/h
6-7 Grate
8
Burner no. 1 control knob
9 Burner no. 3 control knob
10 Burner no. 2 control knob
11 Burner no. 4 control knob
NOTICE: This appliance has been manufactured for residential use only.
Warning: During operation the work surfaces
of the cooking area become very hot:
Keep
children away!
5
INSTALLATION
Installation, adjustment of controls and maintenance must only be carried out by qualified
personnel.
Incorrect installation may cause damage to persons, animals or property for which the
Manufacturer will not be considered responsible. During the life of the system, the automatic
safety or regulating devices on the appliance may only be modified by the manufacturer or by his
duly authorized dealer.
Installing the Cooktop
Check that the appliance is in good condition after having removed the outer packaging and internal
wrappings from around the various loose parts. In case of doubt, do not use the appliance and contact
qualified personnel.
Never leave packaging materials (cardboard, bags, Styrofoam, nails, etc.) within the reach of
children since these items could become sources of danger.
The measurements of the opening made in the top of the modular cabinet and into which the cooktop will
be installed are indicated in Fig. 1 and the following chart. Always comply with the measurements given
for the hole into which the appliance will be recessed (see Figs. 1 and 2).
30”
Min. 6”
FIG. 1 FIG. 2
Use
These
Dimensions
(in
inches)
Model No.
A
B
C
D
E
GC22SS
11-
¼
19
2-
½
2-
½
2-
7/8
GC527SS – GC5271W
GC5272B
21-49/64
18-5/8
2-
½
2-
½
6 - 57/64
Use These Dimensions (mm)
Model No.
A
B
C
D
E
GC22SS
282
482
59
59
100
GC527SS – GC5271W
GC5272B
553
473
63,5
63,5
175
7
Gas Connection
Natural Gas and Propane Gas
Natural gas installations require the connection of a gas regulator to the cooktop. You will find this
regulator among the accessories supplied with the appliance.
Assemble the regulator (noting the direction of gas flow) and transition pieces (supplied) in accordance
with the figure below.
The transition piece on the supply side of the regulator must be provided by the installer. Unions
compatible with the hose fittings must be used and connections tested for gas leaks.
Be sure that the supply connection point is accessible with the appliance installed.
WARNING:
Be sure the hose assembly is restrained from accidental contact with the flue or flue outlet of an under-
counter oven.
Electrical Connection
The electrical connections of the appliance must be carried out in compliance with local standards and
provisions.
Before connecting the appliance, check that:
1.
The electrical capacity of the main electrical supply and current sockets suit the maximum power
rating of the appliance. (See the data label attached to the bottom of the cooktop.)
2.
The socket or system has an efficient ground connection in compliance with local standards and
provisions. The manufacturer is not responsible for failure to comply with these provisions.
