NOTES
This manual contains information for:
• Important Safeguards
• Installation
• Use and Care
Certain ranges come equipped with special features. Determine from a study of
your range which of the instructions given in this booklet pertain to your range.
This booklet gives valuable instructions covering the installation, adjustment and
use of your range.
HOW TO OBTAIN SERVICE AND/OR PARTS
When your range does not operate in accordance with the instructions in the
manual, you should contact the dealer in the immediate vicinity for service. Or,
the purchaser may contact the service organization noted on the wa
rranty.
Gas Range
Read and Save These Instructions
IMPORTANT
TO THE OWNER OF THE RANGE: Retain this owner's manual for future reference.
TO THE INSTALLER: Leave this owner's manual with the range.
Range
Record in the space provided below the Model No. and Serial No. of this appliance. These
numbers are found on the serial plate located below the lift-up cooktop.
Model No._______________________ Type Number _____________________
Serial No. _______________________ Purchase Date_____________________
Record these numbers for future use.
IMPORTANT: Keep a copy of your bill of sale. The date on the bill establishes the
warranty period should service be required. If service is performed, it is in your best
interest to obtain and keep all receipts.
PLEASE DO THIS NOW!
The PRODUCT REGISTRATION CARD should be lled in completely, signed and
returned. This information will register your product and help us to serve you quickly in
the future if necessary.
Contents
Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Energy Saving Ideas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Backguard Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Wall Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Alignments and Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-21
Operation of Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-24
Broiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Optional Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-26
Cleaning the Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-28
Lift-Off Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Trouble Shooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Built-In Cooktops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Built-In Wall Ovens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Note: For warranty and service information, please see attachments packaged with range.
If the information in this manual is not followed exactly,
a re or explosion may result causing property damage,
personal injury or death.
2
Do not store or use gasoline or other ammable vapors and liquids in
the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier, call the re department.
Installation and service must be performed by a qualied installer,
service agency or the gas supplier.
39
GAS RECESSED WALL OVEN
Slide the oven unit into the cabinet recess as shown in the diagram. Secure the oven unit to
the cabinet with wood screws. Be sure to use the cabinet spacer with the wood screw as a
“washer” between the wood cabinet and the oven front frame.
The recess in which the oven is installed shall be constructed so as to provide a complete
closure around the recessed portion of the unit and any openings around gas and
electrical service outlets MUST be closed at time of installation. The installation must
conform with local codes. In the absence of local codes, the National Fuel Gas Code
Z223.1 latest edition.
A MANUAL GAS VALVE MUST BE INSTALLED IN AN ACCESSIBLE
LOCATION IN THE GAS LINE EXTERNAL TO THE UNIT FOR THE
PURPOSE OF TURNING ON OR SHUTTING OFF GAS TO THE UNIT.
ELECTRICAL GROUNDING
INSTRUCTIONS
This appliance is equipped with a three prong
grounding plug for your protection against
shock hazard and should be plugged directly
into a properly grounded receptacle. Do not cut
or remove the grounding prong from this plug.
INSURE PROPER
GROUND EXISTS
BEFORE USE.
FLEXIBLE CONNECTORS - If the gas range/oven is connected to a gas supply with a
metal exible connector, move the range/oven with CAUTION for service or cleaning.
Flexible connectors are not intended for repeated bending. Do not allow cleaners to make
contact with exible connectors.
The connector and its ttings are designed for use only on the original
installation and are not to be reused for another appliance or at another
location. Connectors must comply with ANSI Z21.24.
