SuperServer AS -2123BT-HTR/-HNR/-HNC0R Quick Reference Guide

Board Layout

Descr t nNo. ip io

JBT1: Clear CMOS

SXB4: PCI-E 3.0 p1-x16 Slot2 supported

by CPU1

SIOM: PCI-E 3.0 p1-x16 slot for proprietary

add-on module supported by CPU1

CPU1

P1-DIMME1~H1 slots

P2-DIMMA1~D1 slots

CPU2

P2-DIMME1~H1 slots

Descr t nNo. ip io

SXB2: PCI-E 3.0 p1-x24 slot supported by CPU2

P1-DIMMA1~D1 slots

JF2: PCI-E 3.0 p1-x4 slot supported by CPU2

JSD1: SATA DOM power connector

SXB1: PCI-E 3.0 p1-x4 slot supported by CPU2

and SATA connections (SATA0~5) by CPU1

SATA6: SATA DOM with power-pin connector

J2: M.2 connector PCI-E 3.0 p1-x4 supported by

CPU1 and SATA7 connection

SXB3: PCI-E 3.0 p1-x16 Slot1 supported by CPU1

Dr ves tri Con oll ode y Nd b es

Node con rols dri A t ves

A0 2 3 4 5, A1 A , A , A and A

Node on rol dri B c t s ves

B0 1 2 3 4 5, B , B , B , B and B

Node on rols dri C c t ves

C0 C1 C2 C3 C4 and, , , , C5

Node on rols dri D c t ves

D0 D1 D2 D3 D4 and, , , , D5

Nodes and Corresponding Hard Drives

Hard Drive Installation

N e Bod

N e Aod

N e Dod

N e Cod

Removing a Hot-Swap Drive

Carrier from the Chassis

1. Press the release

button on the

drive carrier,

which will extend

the drive carrier

handle.

2. Use the drive

carrier handle to

pull the drive out

of the chassis.

Installing a Drive

1. Remove the dummy drive, by removing the

screws securing the dummy drive to the

carrier. These screws are not used to mount

the actual hard drive.

2. Insert a drive into the carrier with the PCB side

facing down and the connector end toward the

rear of the carrier. Align the drive in the carrier

so that the screw holes line up.

3. Secure the drive to the carrier with four M3

screws, included in the chassis accessory box.

4. Insert the drive carrier with the disk drive into

its bay, keeping the carrier oriented so that the

release button is on the right side. When the

carrier reaches the rear of the bay, the release

handle retracts.

5. Push the handle in until it clicks into its locked

position.

Re ease ttl Bu on

Front View & Interface Rear View

CPU Installation

Caution

SAFETY INFORMATION

IMPORTANT: See installation instructions and safety warning before

connecting system to power supply.

http://www.supermicro.com/about/policies/safety_information.cfm

WARNING:

To reduce risk of electric shock/damage to equipment, disconnect power

from server by disconnecting all power cords from electrical outlets.

If any CPU socket empty, install protective plastic CPU cap.

WARNING:

Always be sure all power supplies for this system have the same power

output. If mixed power supplies are installed, the system will not operate.

For more information go to : http://www.supermicro.com/support



1. Removing the Processor Force Frame

Use a Torx T20 driver to loosen the screws holding

down Force Frame in the sequence of 3-2-1. The

screws are numbered on the Force Frame next to each

screw hole.

2. Raising the Force Frame 3. Lifting the Rail Frame

5. Inserting the Carrier Frame/CPU Package 6. Lowering the Force Frame 7. Securing the Force Frame

Secure the screws in the order 1-2-3, tightening to

16.1 kgf-cm (14 lbf-in) of torque. The Force Frame

secures both the Rail Frame and CPU Package.

Caution: Tightening must be executed in proper

1-2-3 sequence to avoid causing catastrophic

damage to the socket or CPU Package.

8. The Force Frame Secured

1. Mounting the Heatsink

Screw #1

Screw #2

Screw #3

Force Frame

Rail Frame

PnP Cover Cap

Carrier Frame/

CPU Package

#1 Screw

#2 Screw

#3 Screw

#4 Screw

Processor Installation

2. Securing the Heatsink

Using a diagonal pattern and a Torx T20 driver, tighten the four

heatsink screws evenly to 16.1 kgf-cm (14.0 lbf-in) torque.

4. Removing the External Cap and PnP

Cover Cap

External Cap

PnP Cover Cap

Heatsink Installation

Description

No.

2 PCIe 3.0 p1-x16 LP slots in each node

VGA Connector

IPMI LAN Port

USB (3.0) Ports

SIOM Slot

*Redundant Power Supply Modules

1 6 24 35

*Redundancy based on configuration and application load

DescriptionNo.

Power button

NIC LED

Information LED

UID button/LED

Node A Node B Node C Node D

* * * *

POWE R

UID

POWE R

UID

SUPERMICRO

Node A

Node B

POWE R

UID

POWE R

UID

SUPERMICRO

Node C

Node D

POWER

UID

HDD0~HDD13 HDD14~HDD23

HDD0

HDD1

HDD2

HDD3

HDD4

HDD5

HDD6

HDD7

HDD8

HDD9

HDD10

HDD11

HDD12

HDD13

HDD14

HDD15

HDD16

HDD17

HDD18

HDD19

HDD20

HDD21

HDD22

HDD23

*6x SATA 2.5” Drives per Node for HTR

*6x NVMe 2.5” Drives per Node for HNR

*6x NVMe/SAS/SATA 2.5” Drives per Node for HNC0R

(limit Drives per Node)

4 NVMe

DIMM Module Population

Keep the following in mind:

• Always use DDR4 DIMM modules of the same type, size and speed.

• Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed of

the slowest DIMM.

• The motherboard will support odd-numbered modules (1 or 3 modules installed).

However, to achieve the best memory performance, fully populate the

motherboard with validated memory modules.

Memory

CPU1 D1 H1

8 DI SMM

F1B1

D1 H1F1B1

Processors and their Corresponding Memory Modules

CPU# Cha el nn

Cha el nn

4 DI SMM

CPU1

CPU1 C1 D1 G1 H1

CPU2

8 DI SMM

A1 E1 F1B1

CPU1

CPU2

C1 D1

G1 H1

C1 D1 G1 H1

E1 F1A1 B1

E1 F1B1

H1F1B1

16 MM DI S

Always use DDR4 DIMM modules of the same type, size and speed. To achieve the best memory

performance, a balanced memory population is recommended, as shown in the table.

P1-DIMME1

P1-DIMMF1

P1-DIMMG1

P1-DIMMH1

P1 B1-DIMM

P1 C1-DIMM

P1 D1-DIMM

P1 A1-DIMM P2-DIMME1

P2-DIMMF1

P2-DIMMG1

P2-DIMMH1

P2-DIMMA1

P2-DIMMB1

P2-DIMMC1

P2-DIMMD1

Produkt Specifikationer

Mærke:	Supermicro
Kategori:	Server
Model:	A+ Server 2123BT-HTR
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	438 mm
Dybde:	724 mm
Højde:	88 mm
Vægt:	24700 g
Produktfarve:	Sort
Pakkevægt:	38600 g
Opbevaringstemperatur (T-T):	-40 - 60 °C
Relativ luftfugtighed ved drift (H-H):	8 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Driftstemperatur (T-T):	10 - 30 °C
LED-indikatorer:	HDD, LAN, Power
Bæredygtighedscertifikater:	RoHS
Maksimal intern hukommelse:	2000 GB
Hukommelse form faktor:	288-pin DIMM
On-board grafikkort, model:	Aspeed AST2500
Antal VGA-porte (D-sub):	1
Indbygget processer:	Ingen
Antal blæsere:	4 blæser(e)
Antal understøttede lagerdiske:	6
Kabinettype:	Stativ (2U)
80 PLUS certificering:	80 PLUS Titanium
Ventilator diameter:	80 mm
Strømforsyning:	2200 W
Processor sokkel:	Socket SP3
Fejlkorrigerende kode:	Ja
Redundant strømforsyning:	Ja
Kompatibel processor serie:	AMD EPYC
Bundkort chipsæt:	Intel® SoC
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal M.2 (M) slots:	1
Understøttede lagerdrev brugerflader:	Serial ATA III
BIOS-type:	AMI
BIOS-hukommelsesstørrelse:	128 Mbit
Antal understøttede processorer:	2
Hukommelsesspænding:	1.2 V
PCI Ekspres x16 (Gen 3.x) slots:	2
Understøttede lagerdisk størrelser:	2.5 "
Hot-swap HDD båse:	Ja
Antal DIMM-slots:	16
Understøttet RDIMM-clockhastigheder:	2666 MHz
Antal installerede strømforsyninger:	1
Integreret BMC med IPMI:	Ja
Understøttet DIMM modul kapaciteter:	8GB, 16GB, 32GB, 64GB, 128MB
DC udgående strøm (+12 V):	183.33 A
Maksimal RDIMM hukommelse:	2000 GB
Understøttelse af Intelligent Platform Management Interface (IPMI):	Ja
Strømforsyning dimensioner (BxDxH):	45 x 480 x 40 mm
