Supermicro X12STD-F Manual

Supermicro Bundkort X12STD-F

Læs gratis den danske manual til Supermicro X12STD-F (1 sider) i kategorien Bundkort. Denne vejledning er vurderet som hjælpsom af 16 personer og har en gennemsnitlig bedømmelse på 5.0 stjerner ud af 8.5 anmeldelser. Har du et spørgsmål om Supermicro X12STD-F, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

SUPERMICR R

ContaCt nformatIon I

• Manuals: http://www.supermicro.com/support/manuals

• Drivers & Utilities: https://www.supermicro.com/wdl/driver/

• Safety: http://www.supermicro.com/about/policies/safety_information.cfm

consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.

P CaCkage ontents

X12stD-f

Q r g 1.00uICk eferenCe uIDe

• One Supermicro Motherboard

• One Quick Reference Guide

• Website: www.supermicro.com

• General Information: marketing@supermicro.com

• Technical Support: support@supermicro.com

• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008

f or your system to work ProPerly Please DownloaD aPProPrIate,

DrIvers Images user s manual from the lInks below/ / ' :

MNL-2369-QRG 100

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

SRW3

CPU

X12STD-F

REV: 1.02

DESIGNED IN USA

MH6

SRW1

LEDM1

JTPM1

MH2

MH3

MH1

JKVM1

LED1

JMD1JMD2

MH7 MH4

SAS2

SAS1

MH9

JPWR1

JBT1

SRW5

SRW4 SRW2

BT1

S-SGPIO1

DIMMB1

DIMMB2

DIMMA1

DIMMA2

MH8

JPG1

JVRM1

JVR1

JPME2

JWD1

JBM1

JPO1

JPT1 JCPLD1

CPU SLOT1 PCIE 4.0 X8

CPU MICRO-LP PCIE 4.0 X8

MAC CODE

BAR CODE

BIOS LICENSE

LED2

JUIDB1

USB2 (3.0)

SW1 USB0/1

JPCIE1

Connectors

DIMM Memory Installation

Jumpers, Connectors, and LED Indicators Memory SupportMotherboard Layout and Features

Jumpers

Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in

this guide.

Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors, and LED indicators. Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/

motherboard installation instructions.

LED Indicators

The X12STD-F motherboard supports up to 128GB of ECC and Non-ECC

UDIMM DDR4 memory with speeds of up to 3200MHz in four memory slots.

Recommended Population (Balanced)

DIMMA1 DIMMB1 DIMMA2 DIMMB2 Total System Memory

4GB 4GB 8GB

4GB 4GB 4GB 4GB 16GB

8GB 8GB 16GB

8GB 8GB 8GB 8GB 32GB

16GB 16GB 32GB

16GB 16GB 16GB 16GB 64GB

32GB 32GB 64GB

32GB 32GB 32GB 32GB 128GB

64GB 64GB 128GB

Jumper Description Default Setting

J1 SATA/SAS Select Pins 1-2: Onboard SATA

Pins 2-3: AOC SAS

JBM1 Disable IPMI Share LAN Pins 1-1 (Enabled)

JBT1 CMOS Clear Open (Normal)

JPG1 VGA Enable/Disable Pins 1-2 (Enabled)

JPME2 Manufacturing Mode Pins 1-2 (Normal)

JPO1 CPU Throttle When PWR_Fail Pins 2-3 (Disabled)

JPT1 Onboard TPM Enable/Disable Pins 2-3 (Disabled)

JWD1 Watch Dog Pins 1-2 (Reset)

LED Description Status

LED1 Unit Identier LED Solid Blue: Unit Identied

LED2 OH/Power Fail/FAN Fail Blinking Red: Power Fail or FAN Fail

Solid Red: Overheat

LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal

Connector Description

BT1 Onboard Batttery

J2 CPU MICRO-LP PCIe 4.0 p1-x8 Slot

J3 RESET Button (Debug Only)

JKVM1 KVM Connector

JMD1 M.2 Slot (PCIe 3.0 x4/I-SATA 3.0)

JMD2 M.2 Slot (PCIe 3.0 x4/I-SATA 3.0)

JPCIE1 CPU PCIe 4.0 p1-x8 Slot

JPWR1 Power Connector

JTPM1 Trusted Platform Module/Port 80 Connector

JVR1 VRM SMBus to Header

JUIDB1 UID Button

SAS1, SAS2 SAS Ports

SRW1 - SRW5 M.2 Mounting Holes

S-SGPIO1 Serial Link General Purpose I/O Header

SW1 Power Switch, Power LED

USB0/1 USB 2.0 Ports

USB2 USB 3.2 Type-C Port

CPU Installation

Pin 1

Socket Key

CPU Key

Heatsink Installation

Thermal

Grease

Screw 1 Screw 2

Screw 3

Screw 4

Mounting

Holes

CPU Support

The X12STD-F motherboard supports an Intel Xeon E-2300 Family processor and

Pentium processor with up to 95W in an LGA1200 socket.

Back Panel I/O Connectors

# #Description Description

1. KVM 3. USB Type C

2. 4.Power Switch UID Button
