Synology DiskStation DS210+

High-Performance 2-bay All-in-1 NAS Server Provides Peace of Mind for SMB Users

Synology® DiskStation DS210+ oers a high-performance, secure, and full-featured network

attached storage solution that helps small and medium-sized businesses centralize backup, protect

critical assets and share les quickly and eciently. Synology protects your investment in the

DS210+ with a 2-year limited warranty.

Highlights

●108.5MB/sec Reading, 58MB/sec Writing1

●256-bit AES (Advanced Encryption Standard) Hardware Encryption Engine

●Power-saving with only 30W in Operation

●Wake on LAN/WAN

●Scheduled Power On/O

●Includes Feature-Rich Synology DiskStation Manager 2.3 (DSM 2.3)

High Performance

The Synology DS210+ is designed for business users who require a reliable

storage solution and demand high-performance for le sharing. The

Synology DS210+ delivers an average 108.5MB/sec reading and 58MB/sec

writing speeds under RAID 1 conguration in a Windows® environment.

Peace of Mind with Data Encryption

The Synology DS210+ is equipped with an encryption engine which

ooads the encryption calculation task away from the main CPU, helping

to improve le transfer speeds of the DiskStation. The Synology testing lab

shows that the hardware encryption engine boasts read speed that is about

200% faster than the pure software encryption 2.

Data protection is an important matter for businesses of all sizes. High-

end features previously available only on enterprise level hardware are

now accessible via the DS210+ to small and medium-sized businesses.

DiskStation Manager 2.3, standard on all Synology DiskStations, provides

share-level AES 256-bit encryption to aid in the prevention of unauthorized

access attempts to the hard drives.

Easy Setup and Management

For users who are limited on time or may not be familiar with conguring

complicated routers, the Synology EZ-Internet Wizard simplies the process

of allowing access to the Synology DS210+ from the Internet. The EZ-

Internet Wizard walks the user through all of the settings required including

rewall settings, port-forwarding, PPPoE setup and DDNS registration for a

hassle-free solution to remote access.

Running on AJAX technology, DiskStation Manager’s UI is intuitive and

easy-to-use. To save time and minimize redundancy, common tasks are

automated, such as creating private shared folders for a large number of

users with the User Home feature. Sub-folder privilege settings further

extend the exibility to allocate permissions to dierent workgroups.

Synology DiskStation Manager now also oers the ability to customize the

management UI for end-users or specic projects.

Complete Backup Solutions

The Synology DS210+ oers a centralized backup target to consolidate

fragmented and unstructured data across the network. Integrating easily

into a current network structure and compatible with Windows®, Mac®, and

Linux systems, the DS210+ provides the entire oce data redundancy and

protection. PC Users can back up their data to the Synology DS210+ using

the free Synology Data Replicator software, while Mac OS X users enjoy

native Apple® Time Machine® integration. A backup wizard is also provided

for backing up data in the DS210+ to another Synology DiskStation or any

rsync server via an encrypted transmission, or to an external hard drive via

USB or eSATA connection. Furthering options, the wizard also makes it easy

to backup to the cloud via Amazon® S3.

Full-featured Business Applications

The Synology DS210+ runs on the renowned system rmware, Synology

DSM 2.3, oering applications and features designed specically for SMBs.

Comprehensive network protocol support assures seamless le sharing

across Windows®, Mac®, and Linux® platforms. Windows® ADS integration

allows the Synology DS210+ to quickly and easily t in an existing business

network environment with no need to recreate user accounts.

Internet le access is simplied with the included encrypted FTP server

and the web-based le explorer, Synology File Station 3. HTTPS, the built-in

rewall, and IP auto-block support ensure le sharing over the Internet is

protected at a high security level.

A wealth of additional features allows the Synology DS210+ to replace

several pieces of network hardware. Synology Web Station with support

for PHP/MySQL content allows for the hosting of up to 30 websites on a

single Synology DS210+. Synology Surveillance Station oers a centralized

interface to safeguard the oce environments by deploying IP cameras

throughout the network. The Mail Station add-on turns a Synology DS210+

into a mail server with only few steps of installation and the USB printer

sharing capability minimizes businesses’ printing cost by sharing printing

resources throughout the oce.

Using the NFS protocol or iSCSI target support within DiskStation Manager

2.3, the Synology DS210+ provides seamless serving with Windows, Linux,

or Virtual Machine Servers.

DSM 2.3 users are encouraged to develop and install third-party

applications on the Synology DS210+. Meanwhile, a list of third-party

applications that were tested by Synology is available for users to install on

the Synology DS210+.

Energy Ecient Design

Synology DiskStations are designed and developed with energy eciency

in mind. Compared with the average PC counterparts, the Synology DS210+

consume relatively low amount of power at 30 watts only in operation.

The support of Wake on LAN/WAN, scheduled power on/o and hard drive

hibernation can further reduce power consumption and operation cost.

All Synology products are produced with RoHS compliant parts and

packed with recyclable packing materials. Synology acknowledges

the responsibility as a global citizen to continually work to reduce the

environmental impact of every product produced.

Data Sheet

DS210+

Data Sheet

DS210+

CONNECTIONS & BUTTONS

Networking

SYNOLOGY INC.

Founded in 2000, Synology is a young and energetic

company dedicated to developing high-performance,

reliable, versatile, and environmentally-friendly

Network Attached Storage (NAS) products. Our goal

is to deliver user-friendly solutions and solid customer

service to satisfy the needs of businesses, home oces,

individual users and families.

Synology, the Synology logo are trademarks or

registered trademarks of Synology Inc. Other product

and company names mentioned herein may be

trademarks of their respective companies. Synology

may make changes to specication and product

descriptions at anytime, without notice.

Printed in Taiwan,

DS210+-2010-ENU-REV002

http://www.synology.com

Headquarters

Synology Inc.

3F-3, No. 106, Chang An W. Rd., Taipei, Taiwan

Tel: +886 2 2552 1814 Fax: +886 2 2552 1824

North & South America

Synology America Corp.

2899 152nd Ave NE, Redmond, WA 98052. USA

Tel: +1 425 818 1587

Synology UK Ltd.

Davy Avenue, Knowlhill,

Milton Keynes, Bucks,

MK5 8PB, UK

Tel: +44 01908 673 709

Technical Specications

Hardware

• CPU: 1.06 GHz, 64bit@DDR533

• RAM Size: DDR2 512MB

• Internal HDD3: 2X 3.5” SATA(II) or 2X 2.5” SATA/SSD

• External HDD Interface: 3X USB ports, 1X eSATA port

• Size: 161mm X 88mm X 218mm

• Weight: 0.98kg

• LAN: 1X Gigabit

• Wireless Support4

• Hardware Encryption Engine

• Fan: 1X (70mm X 70mm)

• Noise Level5: 22.1 dB(A)

• Power Recovery

• AC Input Power Voltage: 100V to 240V

• Power Frequency: 50Hz to 60Hz, Single Phase

• Max Internal Capacity: 4TB (2X 2TB hard drives) 6

• Operating Temperature: 5°C to 35°C (40°F to 95°F)

• Storage Temperature: -10°C to 70°C (15°F to 155°F)

• Relative Humidity: 5% to 95% RH

• Max Operating Altitude: 10,000 feet

• Power Consumption 7: 30W (Access); 14.4W (HDD

Hibernation)

• Certication: FCC Class, CE Class B, BSMI Class B

Applications

File Station 3

FTP Server

• Bandwidth Control

• Custom FTP Passive Port Range

• Anonymous FTP

• Transfer Log

Web Station

• Virtual Host (up to 30 websites)

• PHP/MySQL

• Alternative HTTP Error Page

• 3rd-Party Applications Support

Surveillance Station 4

• Default IP cam #: 1

• MAX IP cam # (licenses required): 128

Photo Station 4

• Supported Image Format: BMP, JPG (jpe, jpeg), GIF, RAW

(arw, srf, sr2, dcr, k25, kdc, cr2, crw, nef, mrw, ptx, pef, raf,

3fr, erf, mef, mos, orf, rw2, dng, x3f)

• Supported Video Format9: 3G2, 3GP, ASF, AVI, DAT, DivX,

FLV, M4V, MOV, MP4, MPEG, MPG, QT, WMV, XviD, RM,

RMVB, VOB, RV30, RV40, AC3, AMR, WMA3

Download Station 2

• Supported Download Protocols: BT/HTTP/FTP/NZB/eMule

• Custom BitTorrent Port Range

• BitTorrent / eMule Bandwidth Control

Audio Station 2

• Supported Audio Format: (USB Mode) AAC, FLAC, M4A,

MP3, Ogg Vorbis, WMA, WMA VBR; (Streaming Mode)

MP3, M4A, M4B

• Supported Playlist Format: M3U, WPL

• Internet Radio: SHOUTcast, Radioio

DLNA/UPnP Media Server Support

• PS3/Xbox 360 Support

• Supported Audio Format: AAC, FLAC, M4A, MP3, Ogg

Vorbis, PCM, WAV, WMA, WMA VBR, WMA PRO, WMA

Lossless

• Supported Video Format: 3GP, 3G2, ASF, AVI, DAT, DivX,

DVR-MS, ISO, M2T, M2TS, M4V, MKV, MP4, MPEG1, MPEG2,

MPEG4, MTS, MOV, QT, SWF, TP, TRP, TS, VOB, WMV, XviD,

RV30, RV40, AC3, AMR, WMA3

• Supported Image Format: BMP, JPG (jpe, jpeg), GIF, ICO,

PNG, PSD, TIF (ti ), UFO, RAW (arw, srf, sr2, dcr, k25, kdc,

cr2, crw, nef, mrw, ptx, pef, raf, 3fr, erf, mef, mos, orf, rw2,

dng, x3f)

• Supported Subtitles Format: srt, psb, smi, ass, ssa, sub,

idx, ifo

iTunes Server

• Supported Audio Format 10: MP3, M4A, M4P, WAV, AIF

• Supported Video Format: M4V, MOV, MP4

• Supported Playlist Format: M3U, WPL

Printer Support11

• Max Printer #: 2

• Supported Protocols: LPR, CIFS, AppleTalk

Synology Packages

• Mail Station

• SqueezeCenter

• Weblizer

• phpMyAdmin

iPhone Applications

• DS photo

• DS audio

• DS cam

General Specications

Networking Protocols

• CIFS, AFP, FTP, iSCSI, Telnet, SSH, NFS, SNMP

File System

• EXT3

• FAT32 (External Disk Only)12

• NTFS (External Disk Read Only)13

Volume Management

• iSCSI Target (Max size: 16TB): 10

• Volume Type: Basic, JBOD, RAID 0, RAID 1

• RAID Migration: from Basic to RAID 1

• Expand RAID 1 with Larger Hard Drives

File Sharing Capability

• Max User Account: 2048

• Max Group: 256

• Max Shared Folder: 256

• Max Concurrent Connections (SAMBA, FTP, AFP): 256

Windows ADS Domain Integration

• Domain Users login via Samba/AFP/FTP/File Station

Backup Solutions

• Network Backup

• Local Backup

• Desktop Backup (using Synology Data Replicator 3 or

Apple Time Machine backup application)

• USBCopy

• 3rd-Party Backup Support

Security

• FTP over SSL/TLS

• IP Auto-Block

• Firewall

• Encrypted Network Backup over Rsync

• HTTPS Connection

Management

• DSM Upgrade

• Email Notication

• SMS Notication

• Customized User Quota

• DDNS Support

• PPPoE

• Resource Monitor

• UPS Management

• Scheduled Power On/O

• Custom Management UI HTTP/HTTPS Ports

• System Temperature Display

HDD Management

• HDD Hibernation

• S.M.A.R.T.

• Dynamic Bad Sector Mapping

Utilities

• Synology Assistant

• Synology Download Redirector

• Synology Data Replicator 3

Supported Browsers

• Internet Explorer 7

• Internet Explorer 8

• Firefox 3

• Firefox 3.5

• Safari 3 (Mac)

• Safari 4 (Mac)

Supported Clients

• Windows 2000 onward

• Mac OS X 10.3 onward

• Ubuntu 9.04 onward

Supported Mobile Devices (Photo Station, File Station)

• iPhone OS 2.2.1 onward

• Windows Mobile (IE Mobile or Opera 9.0 onward)

• Symbian OS 9.1, S60 3rd Edition onward

Language

• Czech, Danish, Dutch, English, French, German, Hungarian,

Italian, Japanese, Korean, Norwegian, Polish, Portuguese

Brazil, Portuguese European, Russian, Simplied Chinese,

Spanish, Swedish, Traditional Chinese, Turkish

Environment and Packaging

Environment

• RoHS Compliant

Package Content

• DS210+ Main Unit

• Installation CD

• Welcome Note

• Assembling Kit

• AC Power Adaptor

• AC Power Cord

• 2M RJ-45 LAN Cable

Optional Accessories

• Remote

• Camera License Pack

1. The performance gures are achieved in Synology lab by using

very powerful client computers with extremely optimized

network settings, and could vary on dierent environments. A

regular oce desktop/notebook may not be able to achieve these

high performance gures.

2. The performance gures are achieved in Synology lab by using

very powerful client computers with extremely optimized

network settings, and could vary on dierent environments. A

regular oce desktop/notebook may not be able to achieve these

high performance gures.

3. Hard drive not included.

4. Wireless dongles not included. Please check http://www.synology.

com/ for supported wireless dongles

5. Fully loaded with Seagate 1TB ST31000520AS hard drive(s)

in operation; Two G.R.A.S. Type 40AE microphones, each

set up at 1 meter away from the DiskStation front and

rear; Background noise: 17.2 dB(A); Temperature: 23.6°C ;

Humidity: 58.2%; More details about dB(A) value, check:

http://www.quietnoise.com/facts.htm

6. The actual capacity will dier according to volume types.

7. Measured with 2 Seagate 750GB ST3750640NS hard drive. The

gures could vary on dierent environments.

8. 1 free license to install 1 IP camera. Additional licenses can be

purchased to expand the license quota.

9. User can click and download the following video formats: RM,

RMVB, VOB, RV30, RV40, AC3, AMR, WMA3, but not able to play it

in Photo Station as compressed Flash video.

10. The music in WAV and AIF format can be streamed, but the

metadata (ex: title, album) may not be indexed on the iTunes.

11. For Mac users, DS210+ supports PostScript USB printers only.

12. Primary partition only.

13. Primary partition only.

USB Copy

eSATA

POWER

FAN

USB 2.0

LAN

AC Input

USB 2.0

RESET

USB PrinterDS210+External Disk

Wireless RouterDS210+ Windows ADS Server

IP Camera

PC / Mac / Linux PC / Mac / Linux

Produkt Specifikationer

Mærke:	Synology
Kategori:	Server
Model:	DiskStation DS210+
Tænd-/slukkontakt:	Ja
Vægt:	980 g
Wi-Fi:	Ja
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	3
Strømforbrug (typisk):	30 W
Driftstemperatur (T-T):	5 - 35 °C
Intern hukommelse:	0.5 GB
Dimensioner (BxDxH):	88 x 218 x 161 mm
Støjniveau:	22.1 dB
Knap til nulstilling:	Ja
Processorfrekvens:	1.06 GHz
Intern hukommelsestype:	DDR2
Strømforbrug (dvale):	14.4 W
Ekstern strømadapter:	Ja
Antal blæsere:	1 blæser(e)
Forbindelses-LED'er:	HDD, LAN, Status
Grænseflade til lagerdisk:	Serial ATA II
Antal understøttede lagerdiske:	2
Relativ luftfugtighed:	5 - 95 %
eSATA:	Ja
Total installeret opbevaringskapacitet:	0 TB
Maksimalt understøttet lagerkapacitet:	4000 TB
Kapacitet af datalagringsdrev:	0 GB
Datalink-protokol:	CIFS/AFP/FTP/iSCSI/Telnet/SSH/NFS/SNMP
Link/Act LED:	Ja
iSCSI-understøttelse:	Ja
Flersproget support:	Ja
