LM193-N
,
LM2903-N
,
LM293-N
,
LM393-N
SNOSBJ6G – OCTOBER 1999 – REVISED OCTOBER 2018
LMx93-N, LM2903-N Low-Power, Low-Oset Voltage, Dual Comparators
1
1 Features
1
Wide Supply
Voltage Range: 2.0 V to 36 V
Single or Dual Supplies: ±1.0 V to ±18 V
Very Low Supply Current Drain (0.4 mA) —
Independent of Supply Voltage
Low Input Biasing Current: 25 nA
Low Input Oset Current: ±5 nA
Maximum Oset voltage: ±3 mV
Input Common-Mode Voltage Range Includes
Ground
Dierential Input Voltage Range Equal to the
Power Supply Voltage
Low Output Saturation Voltage: 250 mV at 4 mA
Output Voltage Compatible with TTL, DTL, ECL,
MOS and CMOS logic systems
Available in the 8-Bump (12 mil) DSBGA Package
See AN-1112 ( ) for DSBGASNVA009
Considerations
• Advantages
High Precision Comparators
Reduced VOS Drift Over Temperature
Eliminates Need for Dual Supplies
Allows Sensing Near Ground
Compatible with All Forms of Logic
Power Drain Suitable for Battery Operation
2 Applications
Battery Powered Applications
Industrial Applications
3 Description
The LM193-N series consists of two independent
precision voltage comparators with an oset voltage
specication as low as 2.0 mV max for two
comparators which were designed specically to
operate from a single power supply over a wide range
of voltages. Operation from split power supplies is
also possible and the low power supply current drain
is independent of the magnitude of the power supply
voltage. These comparators also have a unique
characteristic in that the input common-mode voltage
range includes ground, even though operated from a
single power supply voltage.
Application areas include limit comparators, simple
analog to digital converters; pulse, squarewave and
time delay generators; wide range VCO; MOS clock
timers; multivibrators and high voltage digital logic
gates. The LM193-N series was designed to directly
interface with TTL and CMOS. When operated from
both plus and minus power supplies, the LM19-N
series will directly interface with MOS logic where
their low power drain is a distinct advantage over
standard comparators.
The LM393 and LM2903 parts are available in TI’s
innovative thin DSBGA package with 8 (12 mil) large
bumps.
Device Information(1)
PART NUMBER PACKAGE BODY SIZE (NOM)
LM193-N TO-99 (8) 9.08 mm x 9.08 mm
LM293-N
LM393-N SOIC (8) 4.90 mm x 3.91 mm
DSBGA (8) 1.54 mm x 1.54 mm
LM2903-N SOIC (8) 4.90 mm x 3.91 mm
DSBGA (8) 1.54 mm x 1.54 mm
(1) For all available packages, see the orderable addendum at
the end of the datasheet.
Simplied Schematic
2
LM193-N
,
LM2903-N
,
LM293-N
,
LM393-N
SNOSBJ6G – OCTOBER 1999 – REVISED OCTOBER 2018
www.ti.com
Product Folder Links: LM193-N LM2903-N LM293-N LM393-N
Submit Documentation Feedback Copyright © 1999–2018, Texas Instruments Incorporated
Table of Contents
1 Features .................................................................. 1
2 Applications ........................................................... 1
3 Description ............................................................. 1
4 Revision History..................................................... 2
5 Pin Conguration and Functions ......................... 3
6 Specications......................................................... 4
6.1 Absolute Maximum Ratings ..................................... 4
6.2 ESD Ratings ............................................................ 4
6.3 Recommended Operating Conditions....................... 4
6.4 Thermal Information.................................................. 5
6.5 Electrical Characteristics: LM193A V
+= 5 V, TA=
25°C ........................................................................... 5
6.6 Electrical Characteristics: LM193A (V+ = 5 V) ......... 5
6.7 Electrical Characteristics: LMx93 and LM2903 V
+= 5
V, TA= 25°C .............................................................. 6
6.8 Electrical Characteristics: LMx93 and LM2903 (V+ =
5 V)(1) ......................................................................... 7
6.9 Typical Characteristics: LMx93 and LM193A............ 8
6.10 Typical Characteristics: LM2903 ............................ 9
7 Detailed Description ............................................ 10
7.1 Overview ................................................................. 10
7.2 Functional Block Diagram ....................................... 10
7.3 Feature Description................................................. 10
7.4 Device Functional Modes........................................ 10
8 Application and Implementation ........................ 11
8.1 Application Information............................................ 11
8.2 Typical Applications ................................................ 11
9 Power Supply Recommendations...................... 18
10 Layout................................................................... 18
10.1 Layout Guidelines ................................................. 18
10.2 Layout Example .................................................... 18
11 Device and Documentation Support ................. 19
11.1 Related Links ........................................................ 19
11.2 Receiving Notication of Documentation Updates 19
11.3 Trademarks ........................................................... 19
11.4 Electrostatic Discharge Caution............................ 19
11.5 Glossary ................................................................ 19
12 Mechanical, Packaging, and Orderable
Information ........................................................... 19
4 Revision History
NOTE: Page numbers for previous revisions may dier from page numbers in the current version.
Changes from Revision F (December 2014) to Revision G Page
Added DSBGA packages inadvertantly omitted from Device Info table during format conversion ........................................ 1
Changes from Revision E (March 2013) to Revision F Page
• Added section, table, section,Pin Conguration and Functions ESD Ratings Feature Description Device Functional
Modes Application and Implementation Power Supply Recommendations Layout Device, section, section, section,
and Documentation Support Mechanical, Packaging, and Orderable Informationsection, and section .............................. 1
Changes from Revision D (March 2013) to Revision E Page
Changed layout of National Data Sheet to TI format ............................................................................................................ 1


Produkt Specifikationer

Mærke: Texas Instruments
Kategori: Ikke kategoriseret
Model: LM2903M/NOPB
Type: Komparator
Bredde: 5 mm
Dybde: 3.98 mm
Højde: 1.5 mm
Antal pr. pakke: 95 stk
Pakkedybde: 495 mm
Pakkebredde: 8 mm
Pakkehøjde: 4.064 mm
Opbevaringstemperatur (T-T): -65 - 150 °C
Driftstemperatur (T-T): -40 - 85 °C
Pakketype: SOIC
Antal kanaler: 2 kanaler
Antal stifter: 8
Bredde (med stifter): 5 mm
Højde (med stifter): 1.75 mm
Dybde (med stifter): 6.19 mm
