Side 1/52

Owner’s Manual

APS-Series DC-to-AC

Inverter/Chargers

Models: APS2012, APS2424, APS3636VR,

APSINT2012, APSINT2424, APSINT3636VR

Introduction 2

Safety 2

Feature Identification 3

Operation 4

Configuration 5

Battery Selection 8

Mounting 9

Battery Connection 10

AC Input/Output Connection 11

Service/Maintenance 11

Troubleshooting 12

Warranty/Product Registration 13

Español 14

Français 27

 40

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

® is a registered trademark of Tripp Lite.

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

Important Safety Instructions

Introduction

SAVE THESE INSTRUCTIONS!

This manual contains important instructions and warnings that should be followed during the installation, operation and storage of this

product.

Location Warnings

• Install your Inverter/Charger in a location or compartment that minimizes exposure to heat, dust, direct sunlight and moisture.

• Although your Inverter/Charger is moisture resistant, it is NOT waterproof. Flooding the unit with water will cause it to short circuit and

could cause personal injury due to electric shock. Never immerse the unit, and avoid any area where standing water might accumulate.

Mounting should be in the driest location available.

• Leave a minimum of 2” (50 mm) clearance at front and back of the Inverter/Charger for proper ventilation. To avoid automatic Inverter/

Charger shutdown due to overtemperature, any compartment that contains the Inverter/Charger must be properly ventilated with

adequate outside air ﬂow. The heavier the load of connected equipment, the more heat will be generated by the unit.

• Do not install the Inverter/Charger directly near magnetic storage media, as this may result in data corruption.

• Do not install near ﬂammable materials, fuel or chemicals.

• Do not mount unit with its front or rear panel facing down (at any angle). Mounting in this manner will seriously inhibit the

unit’s internal cooling, eventually causing product damage not covered under warranty.

Battery Connection Warnings

• The battery should be connected before operating the Inverter/Charger.

• Multiple battery systems must be comprised of batteries of identical voltage, age, amp-hour capacity and type.

• Because explosive hydrogen gas can accumulate near batteries if they are not kept well ventilated, your batteries should not be installed

(whether for a mobile or stationary application) in a “dead air” compartment. Ideally, any compartment would have some ventilation to

outside air.

• Sparks may result during ﬁnal battery connection. Always observe proper polarity as batteries are connected.

• Do not allow objects to contact the two DC input terminals. Do not short or bridge these terminals together. Serious personal injury or

property damage could result.

Equipment Connection Warnings

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of

the life support equipment or to signiﬁcantly affect its safety or effectiveness is not recommended. Do not use this equipment in the

presence of a ﬂammable anesthetic mixture with air, oxygen or nitrous oxide.

• Only connect your Inverter/Charger to a properly grounded hardwired AC power source. Do not plug the unit into itself; this will damage

the device and void your warranty.

• You may experience uneven performance if you connect a surge suppressor, line conditioner or UPS system to the output of your Inverter/

Charger.

Operation Warnings

• Your Inverter/Charger does not require routine maintenance. Do not open the device for any reason. There are no user serviceable parts

inside.

• Potentially lethal voltages exist within the Inverter/Charger as long as the battery supply and/or AC input are connected. During any

service work, the battery supply and AC input connection (if any) should therefore be disconnected.

• Do not connect or disconnect batteries while the Inverter/Charger is operating in either inverting or charging mode. Operating Mode

Switch should be in the DC OFF position. Dangerous arcing may result.

Caution: Your Inverter/Charger has a failsafe AC pass-through feature. The AC output will be live (if AC input is

available) even though the operating mode switch is set to DC OFF.

Congratulations! You’ve purchased the most advanced, feature-rich Inverter/Charger designed as an alternative energy source during utility

power failures. Tripp Lite APS Inverter/Chargers keep your equipment up and productive through all utility power problems (blackouts,

brownouts and overvoltages) by inverting DC power from user-supplied batteries into AC power. When utility power is present, APS Inverter/

Chargers automatically pass through power to your equipment while simultaneously recharging your connected battery bank. Built-in

Isobar® surge suppression provides an additional level of equipment protection. APS Inverter/Chargers are the quiet alternative to gas

generators for emergency backup applications. You get AC electricity anywhere and anytime you need it—with no fumes, fuel or noise!

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	APSINT3636VR
Bredde:	215.9 mm
Dybde:	355.6 mm
Højde:	177.8 mm
Vægt:	26310 g
Produktfarve:	Sort
Pakkevægt:	29300 g
Pakkedybde:	530.9 mm
Pakkebredde:	368.3 mm
Pakkehøjde:	340.4 mm
Relativ luftfugtighed ved drift (H-H):	0 - 95 %
Husmateriale:	Polykarbonat (PC)
Strømforsyningstype:	Indendørs
Udgangseffekt:	3600 W
Certificering:	RoHS
LED-indikatorer:	Ja
Udgangsspænding:	230 V
Harmoniseret systemkode (HS):	8504.40.9570
Indgangsspænding:	230 V
Formål:	Universel
Hovedkassen højde (udvendigt):	340.4 mm
Hovedkassens længde (udvendigt):	530.9 mm
Hovedkassens bruttovægt (udvendigt):	29300 g
Hovedkassens bredde (udvendigt):	368.3 mm
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	1 stk
Indgangsfrekvens:	50 Hz
Strømbeskyttelsesfunktioner:	Højspænding
Maksimal strøm:	7200 W
Justerbar udgangsspænding:	Ja
Uddgående frekvens:	50 Hz
