Owner’s Manual

AVR Series UPS Systems

Important Safety Instructions 2

Features 3

Installation 6

Optional Installation 6

Troubleshooting 7

Storage & Service 7

Español 9

Français 17

Deutsche 25

Ðóññêèé 33

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

AVRX550UF

AVRX550UD

AVRX550UI

AVRX550UK

AVRX750UF

AVRX750UD

AVRX750UI

AVRX750UK

Agency Model Numbers: AGOM7594 • AGOM7595 • AGOM7596 • AGOM7597

AGOM7745 • AGOM7746 • AGOM7747 • AGOM7748

Not suitable for mobile applications.

201001098 93-2976.indb 1 7/8/2010 10:42:28 AM

Important Safety Instructions

SAVE THESE INSTRUCTIONS—This manual contains instructions and warnings that should be

followed during the installation, operation and storage of all Tripp Lite UPS Systems. Failure to

heed these warnings may affect your warranty.

UPS Location Warnings

• Install UPS indoors, away from excess moisture or heat, conductive contaminants, dust or

direct sunlight.

• Keep the indoor temperature between 32º F and 104º F (0º C and 40º C).

• Leave adequate space around all sides of UPS for proper ventilation.

UPS Connection Warnings

• Connect UPS directly to a properly grounded AC power outlet. Do not plug UPS into itself;

this will damage the UPS.

• Do not modify the UPS’s plug, and do not use an adapter that would eliminate the UPS’s

ground connection.

• Do not use extension cords to connect UPS to an AC outlet.

• If UPS receives power from a motor-powered AC generator, the generator must provide clean,

ltered, computer-grade output.

• The mains socket outlet that supplies the UPS should be near the UPS and be easily accessible.

• To remove AC voltage from the UPS, pull the plug from the outlet after unplugging your

equipment.

Equipment Connection Warnings

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to signicantly

affect its safety or effectiveness is not recommended. Do not use this equipment in the

presence of a ammable anesthetic mixture with air, oxygen or nitrous oxide.

• Do not connect another UPS, surge suppressor or extension cord to the output of UPS. This

might damage the UPS and may affect the surge suppressor and UPS warranties.

• Connect the UPS to an outlet that is adequately protected against excess currents, short circuits

and earth faults, as part of the building installation. The outlet protection for the UPS should be

in series with the mains input.

Battery Warnings

• Batteries can present a risk of electrical shock and burn from high short-circuit current.

Observe proper precautions. Do not dispose of the batteries in a re. Do not open the UPS or

batteries. Do not short or bridge the battery terminals with any object. Unplug and turn off

the UPS before performing battery replacement. Use tools with insulated handles. There are

no user-serviceable parts inside the UPS. Battery replacement should be performed only by

authorized service personnel using the same number and type of batteries (Sealed Lead-Acid).

The batteries are recyclable. Refer to your local codes for disposal requirements or visit www.

tripplite.com/UPSbatteryrecycling for recycling information. Tripp Lite offers a complete line

of UPS System Replacement Battery Cartridges (R.B.C.).Visit Tripp Lite on the Web at

www.tripplite.com/support/battery/index.cfm to locate the specic replacement battery for

your UPS.

Correct Disposal of this Product

This marking indicates that this product should not be disposed with other household

wastes throughout the EU. To prevent possible harm to the environment or human

health from uncontrolled waste disposal, recycle it responsibly to promote the

sustainable reuse of material resources. To return your used device, please use the

return and collection systems or contact the retailer where the product was purchased.

They can take this product for environmental safe recycling.

201001098 93-2976.indb 2 7/8/2010 10:42:29 AM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	AVRX550UD
Bredde:	279.4 mm
Dybde:	152.4 mm
Højde:	120.1 mm
Vægt:	5220 g
Produktfarve:	Sort
Pakkevægt:	5580 g
Pakkedybde:	242.1 mm
Pakkebredde:	360.7 mm
Pakkehøjde:	185.4 mm
Formfaktor:	Kompakt
Opbevaringstemperatur (T-T):	-15 - 50 °C
Relativ luftfugtighed ved drift (H-H):	0 - 95 %
Relativ luftfugtighed ved opbevaring (H-H):	0 - 95 %
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	1
Driftstemperatur (T-T):	0 - 40 °C
Husmateriale:	Acrylonitrilbutadienstyren
Udgangseffekt:	300 W
Certificering:	CE, FCC, IEC 62040, IEC 60950, EN 62040, GS MARK
LED-indikatorer:	Ja
Kabellængde:	1.8 m
Opladningstid for batteri:	15 t
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	400 mm
Hovedkassens længde (udvendigt):	262.1 mm
Hovedkassens bruttovægt (udvendigt):	11840 g
Hovedkassens bredde (udvendigt):	381 mm
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	2 stk
Indgangsfrekvens:	50/60 Hz
Hovedkasse (udvendig) GTIN (EAN/UPC):	10037332156829
Lydalarmer:	Ja
Strømbeskyttelsesfunktioner:	Over voltage, Under voltage
Effektivitet:	99 %
Modem-porte (RJ-11):	1
AC udgange, antal:	8 AC stikkontakt(er)
AC stikkontakt typer:	Type F
Overspænding energivurdering:	320 J
Indgående driftsspænding (maks.):	282 V
Output strømkapacitet (VA):	0.55 kVA
Indgående driftsspænding (min.):	159 V
Udgangs driftsspænding (min.):	220 V
Udgangs driftsspænding (maks.):	240 V
UPS topologi:	Interaktivt indgangsstik
Beskyttelsesfunktioner mod strømstød:	Telefon
Strøm (maks.):	10 A
Beskyttelse ved overspænding:	Ja
Bølgeform:	Sine
Typisk backup tid ved halv styrke:	9.7 min.
Typisk backup tid ved fuld styrke:	3 min.
Antal F type udgange:	8
Koldstart:	Ja
Hot-swap batteri:	Ja
Automatisk spændingsregulering (AVR):	Ja
EMI/RFI støjfiltrering:	Ja
Antal indgående faser:	1
Regulering af udgangsspænding:	+8, -21 %
