Owner’s Manual

NetDirector Console KVM Switch

(8- or 16-Port) or

Rackmount KVM Switch (8-Port)

Models: B020-U08-19-K, B020-U08-19KTAA, B020-U16-19-K or

B022-U08

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

1. Package Contents 2

2. Features 2

3. System Requirements 3

3.1 Computer 3

3.2 Console 3

3.3 Cables 3

4 4. Introduction

4.1 Front View of Console KVM Switch 4

4.2 Front View of B022-U08 5

4.3 Rear View of Console KVM Switch 5

4.4 Rear View for B022-U08 6

5. Installation 6

5.1 Pre-Installation Safety Instructions 6

5.2 Rackmounting Instructions for Console KVMs 7

5.3 Rackmounting for B022-U08 8

5.4 Grounding 8

5.5 Single-Station Installation 8

5.6 Multiple-Station (Daisy-Chained) Installation 8

5.7 Multiple Station (Cascaded) Installation 8

5.8 Hot Plugging 9

6. Basic Operation 9

6.1 Opening the NetDirector Console KVM 9

6.2 Closing the NetDirector Console KVM 9

6.3 LCD OSD (On-Screen Display) Conﬁguration 10

6.4 Sharing USB Peripheral Devices 10

6.5 Powering Off and Restarting 10

7. Hotkeys 11

7.1 Invoking the Hotkey Mode 11

7.2 Port ID Numbering 11

7.3 Selecting the Active Port 11

7.4 Auto Scanning 12

7.5 Starting Auto Scan 12

7.6 Pausing in Auto Scan 12

7.7 Skip Mode 12

7.8 Hotkey Beeper Control 12

7.9 Computer Keyboard/Mouse Reset 12

7.10 Quick Hotkey Control 13

7.11 OSD Hotkey Comtrol 13

7.12 Port OS Control 13

7.13 Restore Default Values 13

7.14 Hotkey Summary Table 13

8. OSD (On-Screen Display) Operation 14

8.1 OSD Overview 14

8.2 Logging-In for the First Time 14

8.3 OSD Invocation Sequence 14

8.4 OSD Navigation 14

8.5 OSD Main Screen Headings 14

8.6 OSD Functions 15

9. Firmware Upgrade Utility 18

9.1 Before You Begin 18

9.2 Starting the Upgrade 19

9.3 Upgrade Succeeded 19

9.4 Upgrade Failed 19

9.5 Firmware Upgrade Recovery 20

10. Appendix A 20

10.1 Speciﬁcations 20

10.2 OSD Factory Default Settings 21

10.3 Keyboard Emulation 21

11. Appendix B 22

11.1 FCC Radio/TV Interference Notice 22

12. Warranty and Product Registration 22

Table of Contents

2. Features

1. Package Contents

• (1) B020-U08-19-K, B020-U08-19KTAA, B020-U16-19-K or B022-U08 KVM Switch

• (8) P778-006 USB/PS2 Combo KVM Cable Kits*

• (1) USB/PS2 Combo Console Cable Kit

• (1) RJ45 to DB9 Firmware Upgrade Cable

• (1) C13 to 5-15P Power Cord*

• (1) AC Power Adapter (Input: 100-240V, 50/60 Hz, 0.5A/Output: 5.3V, 2.4A)**

• (1) CD with Owner’s Manual

• (1) Quick Start Guide

• (1) Grounding Wire

• (1) Rackmount Hardware Kit

• (1) Set of Rubber Feet**

*B020-U08-19-K, B020-U08-19KTAA and B020-U16-19-K only

**B022-U08 only

Check to see that the unit arrived undamaged and with all of its contents. Contact your dealer if there is a problem.

• Integrated KVM console with 19” LCD for the B020-U08-19-K, B020-U08-19KTAA and B020-U16-19-K.

• B020-U08-19-K, B020-U08-19KTAA and B020-U16-19-K come with (8) P778-Series USB/PS2 Combo KVM Cable Kits.

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	B020-U16-19-K
Bredde:	480.1 mm
Dybde:	689.1 mm
Højde:	43.9 mm
Vægt:	14060 g
Brugervejledning:	Ja
Produktfarve:	Sort
Indbygget skærm:	Ja
Pakkevægt:	19840 g
Pakkedybde:	665.5 mm
Pakkebredde:	830.1 mm
Pakkehøjde:	130 mm
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 80 %
Strømforbrug (typisk):	29.1 W
Driftstemperatur (T-T):	0 - 50 °C
Maksimal opløsning:	1280 x 1024 pixel
Skærm:	LCD
Hurtig installationsvejledning:	Ja
Kabler inkluderet:	PS/2, USB
Certificering:	UL, cUL, CE, FCC
Kabellængde:	1.83 m
Harmoniseret systemkode (HS):	8471.80.1000
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	130 mm
Hovedkassens længde (udvendigt):	665.5 mm
Hovedkassens bruttovægt (udvendigt):	19840 g
Hovedkassens bredde (udvendigt):	830.1 mm
Oprindelsesland:	Taiwan
Produkter pr. hovedkasse (udvendigt):	1 stk
Stativ-montering:	Ja
Vægt (efter britisk standard):	31.3 Pund
Antal kontrollerede computere:	16
Tastatur porttype:	USB, PS/2
Mus porttype:	USB, PS/2
Video porttype:	VGA
Porte, antal:	16
Rackkapacitet:	1U
