2
Table of Contents
1. Package Contents 2
2. Features 2
3. System Requirements 3
3.1 Computer 3
3.2 Console 3
3.3 Cables 3
3.4 Operating Systems 3
4 4. Introduction
4.1 Front View of Console KVM Switch 4
4.2 Rear View of Console KVM Switch 5
5. Installation 5
5.1 Pre-Installation Safety Instructions 5
5.2 Rackmounting Instructions for Console KVMs 6
5.3 Grounding 7
5.4 Single-Station Installation 7
5.5 Multiple-Station (Daisy-Chained) Installation 7
5.6 Hot Plugging 8
6. Basic Operation 8
6.1 Opening the NetDirector Console KVM 8
6.2 Closing the NetDirector Console KVM 8
6.3 LCD OSD (On-Screen Display) Conguration 9
6.4 Sharing USB Peripheral Devices 9
6.5 Powering O and Restarting 9
7. Hotkeys 10
7.1 Invoking the Hotkey Mode 10
7.2 Port ID Numbering 10
7.3 Selecting the Active Port 10
7.4 Auto-Scanning 11
7.5 Starting Auto-Scan 11
7.6 Pausing in Auto-Scan 11
7.7 Skip Mode 11
7.8 Hotkey Beeper Control 11
7.9 Computer Keyboard/Mouse Reset 11
7.10 Quick Hotkey Control 12
7.11 OSD Hotkey Comtrol 12
7.12 Port OS Control 12
7.13 Restore Default Values 12
7.14 Hotkey Summary Table 12
8. OSD (On-Screen Display) Operation 13
8.1 OSD Overview 13
8.2 Logging-In for the First Time 13
8.3 OSD Invocation Sequence 13
8.4 OSD Navigation 13
8.5 OSD Main Screen Headings 13
8.6 OSD Functions 14
9. Firmware Upgrade Utility 17
9.1 Before You Begin 17
9.2 Starting the Upgrade 18
9.3 Upgrade Succeeded 18
9.4 Upgrade Failed 18
9.5 Firmware Upgrade Recovery 19
10. Appendix A 19
10.1 Specications 19
10.2 OSD Factory Default Settings 20
10.3 Keyboard Emulation 20
11. Warranty 21
• (1) B020-U16-19-KG or B020-U16-19-KF KVM Switch
• (8) P778-006 USB/PS2 Combo KVM Cable Kits
• (1) USB/PS2 Combo Console Cable Kit
• (1) RJ11 to DB9 Firmware Upgrade Cable
• (1) C13 to C14 Power Cord
• (1) Quick Start Guide
• (1) Grounding Wire
• (1) Rackmount Hardware Kit (Pre-Installed)
Check to see that the unit arrived undamaged and with all of its contents. Contact your dealer if there is a problem.
• Integrated KVM console with 19” LCD for the B020-U16-19-KG and B020-U16-19-KF models.
• B020-U16-19-KG and B020-U16-19-KF models include (8) P778-Series USB/PS2 Combo KVM Cable Kits.
• B020-U16-19-KG and B020-U16-19-KF models include an external console port, allowing an external local console (PS/2 or USB) to be
connected. An additional USB port is included on the front panel can be used with an external mouse.
1. Package Contents
2. Features
