Side 1/52

Owner’s Manual

BP Series

External Battery Packs

Not suitable for mobile applications.

Introduction 2

Important Safety Instructions 2

Mounting 4

Connection 11

Maintenance 12

Warranty and Product Registration 13

Español 14

Français 27

 40

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

24V Battery Packs 36V Battery Packs 48V Battery Packs 72V Battery Packs

BP24V15RT2U, 14AH

BP24V28-2U, 28AH

BP24V36-2US, 36AH

BP24V70-3U, 70AH

BP36V15-2U, 18AH

BP36V42-3U, 21AH

BP48V24-2U, 18AH

BP48V27-2US, 27AH

BP48V48RT4U, 42AH

BP48V60RT-3U, 42AH

BP72V15-2U, 15AH

BP72V18-2US, 18AH

BP72V28RT-3U, 28AH

19-01-135-9336FF.indb 1 1/9/2019 1:17:56 PM

Introduction

Important Safety Instructions

Tripp Lite BP Series External Battery Packs are designed for use with various Tripp Lite

UPS systems equipped with external battery pack connectors.

SAVE THESE INSTRUCTIONS

WARNING! The mounting shelves are not intended to support more than

one battery pack. Do not stack multiple battery packs on a single set of

mounting shelves. Failure to follow this warning may lead to product

damage and/or risk of personal bodily harm.

• Use caution when lifting battery packs. Because of the considerable weight of

all battery packs, at least two people should assist in lifting and installing

them.

• Make certain the battery packs and UPS use the same DC voltage before

connecting them.

• Use only Tripp Lite external battery packs with overcurrent protection.

Installation is by qualified service personnel only. Contact Tripp Lite Customer

Support at 773.869.1234 for the appropriate Tripp Lite battery pack to

connect.

• Your external metal battery cabinets are provided with a means for

equipotential protective bonding for safety. When using 2-pin connector

external batteries, be sure to bond the metal enclosure of your external

battery to the metal enclosure of the UPS system. Three-pin/conductor battery

packs are equipped with a ground bond plug. Plastic enclosures do not require

bonding. See below for ground bonding strap requirements:

24V Battery Packs

BP24V15RT2U: Plastic enclosure, so ground bonding strap is not required.

BP24V28-2U: 12 AWG ground bonding strap

BP24V36-2US: 12 AWG ground bonding strap

BP24V70-3U: 12 AWG ground bonding strap

36V Battery Packs

BP36V15-2U: 12 AWG ground bonding strap

BP36V42-3U: 12 AWG ground bonding strap

48V Battery Packs

BP48V24-2U: 12 AWG ground bonding strap

BP48V27-2US: 12 AWG ground bonding strap

BP48V48RT4U: 12 AWG ground bonding strap

BP48V60RT-3U: 12 AWG ground bonding strap

Note: The battery connector on 72V battery packs has a built-in ground bonding plug, so an

additional ground bonding strap isn’t needed.

19-01-135-9336FF.indb 2 1/9/2019 1:17:57 PM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	BP36V15-2U
Bredde:	444.5 mm
Dybde:	336.6 mm
Højde:	88.9 mm
Vægt:	20410 g
Produktfarve:	Sort
Batterispænding:	36 V
Pakkevægt:	26220 g
Pakkedybde:	594.4 mm
Pakkebredde:	513.1 mm
Pakkehøjde:	226.1 mm
Batterilevetid:	6 År
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	226.1 mm
Hovedkassens længde (udvendigt):	594.4 mm
Hovedkassens bruttovægt (udvendigt):	26220 g
Hovedkassens bredde (udvendigt):	513.1 mm
Oprindelsesland:	Taiwan
Produkter pr. hovedkasse (udvendigt):	1 stk
Kapabilitet:	Tripp Lite SMART1000RMXL2U, SMART1200XLHG, SMART1500RMXL2Ua, SMART1500XL, SMX1200XLHG, SMX1500XLRT2U
