Side 1/24

Table of Contents

1. Important Safety Instructions 2

2. Overview 2

3. Feature Identiﬁcation 3

4. Enclosure Installation 4

4.1 Preparation 4

4.2 Unpacking 4

4.3 Placement 4

4.4 Power Requirements 4

5. Wall Mounting the Enclosure 5

5.1 Mounting the CS16AC and CS32AC 5

6. Enclosure Conﬁguration 5

6.1 Door Locks 5

6.2 Power Cord/Cable – 6

Access & Management

7. 16-Outlet AC Charger Unit 6

7.1 AC Charger Unit Features 6

7.2 Connecting Devices to the 6

AC Charger Unit

8. Adjusting Storage Shelf Dividers 7

8.1 Adjusting the CS16AC and 7

CS32AC Shelf Dividers

9. Speciﬁcations 7

10. Optional Casters 7

11. Storage and Service 8

12. Warranty & Product Registration 8

Español 9

Français 17

AC Device Charging Station

Models: CS16AC, CS32AC

Owner’s Manual

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

1. Important Safety Instructions

2. Overview

SAVE THESE INSTRUCTIONS

This Manual contains instructions and warnings that must be followed during the installation and operation of the product described in this manual.

Failure to comply may invalidate the warranty and cause property damage or personal injury.

AC Charger Unit:

• To remove the AC charger unit from the supply mains, the appliance inlet serves as a disconnect device.

• If any of the following situations arise, schedule an appointment to have your equipment inspected by a service technician:

• The equipment has been exposed to moisture

• The equipment has been dropped and damaged

• The equipment shows obvious signs of breakage

• The equipment is not functioning properly or is not functioning according to the instructions described in this Owner’s Manual

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support

equipment or to significantly affect its safety or effectiveness is not recommended.

• Do not use this equipment in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide.

Enclosure Unit:

• Keep the enclosure in a controlled indoor environment, away from moisture, temperature extremes, flammable liquids and gasses, conductive

contaminants, dust and direct sunlight.

• Leave adequate space at the front and rear of the enclosure for proper ventilation. Do not block, cover or insert objects into the external ventilation

openings of the enclosure.

• The enclosure is extremely heavy. Use caution when handling the enclosure. Do not attempt to unpack, move or install it unassisted. Use a

mechanical device such as a forklift or pallet jack to move the enclosure in the shipping container.

• Do not place any object on the enclosure, especially containers of liquid, and do not attempt to stack the enclosures.

• Inspect the shipping container and the enclosure for shipping damage. Do not use the enclosure if it is damaged.

• Leave the enclosure in the shipping container until it has been moved as close to the final installation location as possible.

• For wall-mounted installations, first make sure that the wall surface can safely support the combined load of the enclosure, equipment and all

attached hardware and components.

• For floor installations, make sure the unit is placed in a structurally sound area capable of bearing the weight of the enclosure, all equipment that

will be installed, and any other enclosures and/or equipment that will be installed nearby.

• Enclosure must be installed by a qualified technician.

• Use suitable mounting means when installing to cinder block, concrete, drywall or wood studs.

• Use caution when cutting packing materials. The enclosure could be scratched, causing damage not covered by the warranty.

• Save all packing materials for later use. Repacking and shipping the enclosure without the original packing materials may cause product damage

that will void the warranty.

If installing optional casters (SRCASTER—see page 7 for caster installation):

• Do not push the enclosure from the side panels to move it. Pushing from the side panels will cause a tipping hazard.

• When rolling the enclosure on its casters, always push it from behind; never pull it toward you.

• A rolling enclosure can cause personal injury and property damage if not properly supervised. If rolling the enclosure down a ramp is required, use

extreme caution. Do not attempt to use ramps that have a slope grade greater than 12%.

Your charging station is an all-in-one solution for storing and charging for up to 16 (CS16AC) or 32 (CS32AC) devices. Housed in a standard, 19-inch

rack enclosure, your charging station can be conveniently mounted to walls as well as be configured for desktop or floor placement (with optional

rolling casters, sold separately). To prevent theft and device tampering, your tablet charging station enclosure comes equipped with locking steel doors

and side panels.

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	CS32AC
Bredde:	600 mm
Dybde:	550 mm
Højde:	904 mm
Vægt:	43200 g
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	49500 g
Pakkedybde:	560 mm
Pakkebredde:	610 mm
Pakkehøjde:	1040 mm
Materiale:	Stål
Certificering:	EIA-310-E, UL60950, FCC & IEC Class B\r\nNOM
Strømkilde type:	Vekselstrøm
Bæredygtighedscertifikater:	RoHS
Oplader, kompabilitet:	Tablet
Kapabilitet:	Chromebook
Oplader type:	Indendørs
