Quick Start Guide

Installation

Cat5/5e/6/6a 110-Type UTP Patch Panels

Models: N052-024, N052-048, N252-024, N252-024-6A, N252-024-6A-OF, N252-048

Español 3 • Français 5 • Русский 7

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

22-24 AWG

Avoid gaps

Wrap strap

around cables.

Figure 1: T568A/B Wiring Scheme

Strip the cable jacket approximately 1.25 in. (30 mm).

Use a 110 impact tool for termination.

Note: Set the tool to the “Low Impact” setting.

Seat each wire according to the wiring scheme shown in Figure 1.

Ensure the untwisted length is as short as possible. Avoid overlapping

one pair over the others.

Note: 110 punchdown orientation may vary by model.

In order to maintain stable performance, ensure the cable bundles

are secured with the attached straps.
