Quick Start Guide

Installation

DisplayPort 1.2 to VGA /

HDMI All-in-One Converter

Model: P136-06N-HV-V2

Mini DisplayPort 1.2 to VGA /

HDMI All-in-One Converter

Model: P137-06N-HV-V2W

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Product Features

•

Connect a VGA or HDMI monitor to a DisplayPort or Mini DisplayPort on your laptop, tablet or computer

• All-in-One converter offers maximum ﬂexibility to connect to any available monitor

• Portable design with built-in cable is perfect for travel and stowing in your laptop bag

•

HDMI port supports 4K x 2K Ultra High Deﬁnition (UHD) video resolutions up to 3840 x 2160 (24 Hz or 30 Hz)

• VGA port supports video resolutions up to 1920 x 1200, including 1080p

•

Supports up to 36-bit Deep Color (12 bits per channel)

• P137-06N-HV-V2W model is compatible with the Thunderbolt port on Mac

® computers, such as the MacBook

Pro and MacBook Air

• Passive converter requires no external power supply

System Requirements

• Computer or tablet with a DisplayPort or Mini DisplayPort

•

Monitor with a VGA or HDMI port

Package Includes

• P136-06N-HV-V2 or P137-06N-HV-V2W

• Quick Start Guide

Notes:

• Only one monitor can be connected at a time.

• To connect a Mac to an HDMI monitor with audio, go to “System Preferences” and select “Sound”. Then click

the “Output” tab and select your HDMI device from the list. DisplayPort or Mini DisplayPort audio is Note:

available on all Mac models introduced after April 2010.

• When connecting an HDMI monitor, the distance between the converter and monitor must be no longer than

6 ft. (2 m). When connecting a VGA monitor, the distance must be no longer than 10 ft. (3 m).

Optional Accessories

• P502-006 High Resolution VGA Cable with RGB Coax – 6 ft.

•

P568-006 High Speed HDMI Cable – 6 ft.

1. Connect the converter to the DisplayPort or Mini DisplayPort on your computer or tablet.

2. Connect a monitor to the VGA or HDMI port on the converter.

WARRANTY REGISTRATION

an ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

Este guía esta disponible en español en la página de Tripp Lite: tripplite.com/support

Ce guide est disponible en français sur le site Web de Tripp Lite : tripplite.com/support

Русскоязычная версия настоящего краткого руководства представлена

на веб-сайте компании

Tripp Lite по адресу: tripplite.com

19-11-116-933541-EN.indd 1 11/19/2019 9:55:08 AM

Speciﬁcations

Warranty and Product Registration

Speciﬁcation Description

Input Signal DisplayPort 1.2 or Mini DisplayPort 1.2

Output Signal VGA and HDMI

Vertical Frequency Range 50/60 Hz

Video Ampliﬁer Bandwidth 2.25 Gbps / 225 MHz

Maximum HDMI Resolution 4K x 2K, 3840 x 2160 (24 Hz or 30 Hz)

Maximum VGA Resolution 1920 x 1200, including 1080p

Maximum Cable Length 6 ft. (2 m) for HDMI, 10 ft. (3 m) for VGA

Operating Temperature 32 to 113 °F (0 to 45 °C)

Operating Humidity 10% to 85% RH, Non-Condensing

Storage Temperature 14 to 176 °F (-10 to 80 °C)

Storage Humidity 5% to 90% RH, Non-Condensing

Maximum Power Consumption 700mW

3-Year Limited Warranty

Tripp Lite warrants its products to be free from defects in

materials and workmanship for a period of three (3) years from

the date of initial purchase. Tripp Lite’s obligation under this

warranty is limited to repairing or replacing (at its sole option)

any such defective products. To obtain service under this

warranty, you must obtain a Returned Material Authorization

(RMA) number from Tripp Lite or an authorized Tripp Lite service

center. Products must be returned to Tripp Lite or an authorized

Tripp Lite service center with transportation charges prepaid

and must be accompanied by a brief description of the problem

encountered and proof of date and place of purchase. This

warranty does not apply to equipment which has been damaged

by accident, negligence or misapplication or has been altered or

modiﬁed in any way.

EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. Some states do not permit limitation or exclusion

of implied warranties; therefore, the aforesaid limitation(s) or

exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite

BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS

PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH

DAMAGE. Speciﬁcally, Tripp Lite is not liable for any costs, such

as lost proﬁts or revenue, loss of equipment loss of use of

equipment, loss of software, loss of data, costs of substitutes,

claims by third parties, or otherwise.

Product Registration

Visit tripplite.com/warranty today to register your new Tripp Lite

product. You’ll be automatically entered into a drawing for a

chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some

restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.

Note: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is

no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Any changes or modiﬁcations to this equipment not expressly

approved by Tripp Lite could void the user’s authority to operate

this equipment.

WEEE Compliance Information for Tripp Lite Customers and

Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment

(WEEE) Directive and implementing regulations, when

customers buy new electrical and electronic equipment

from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one,

like-for-like basis (this varies depending on the country)

• Send the new equipment back for recycling when

this ultimately becomes waste

WARNING

Use of this equipment in life support applications where failure

of this equipment can reasonably be expected to cause the

failure of the life support equipment or to signiﬁcantly affect its

safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Speciﬁcations

are subject to change without notice.

19-11-116 93-3541_RevB

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

19-11-116-933541-EN.indd 2 11/19/2019 9:55:08 AM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	P136-06N-HVV2BP
Vægt:	50 g
Antal pr. pakke:	50 stk
Produktfarve:	Sort
Pakkevægt:	2440 g
Pakkedybde:	249.9 mm
Pakkebredde:	279.9 mm
Pakkehøjde:	150.1 mm
Understøttede videotilstande:	1080p,2160i
Opbevaringstemperatur (T-T):	-10 - 80 °C
Relativ luftfugtighed ved drift (H-H):	10 - 85 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 90 %
HDCP:	Ja
Driftstemperatur (T-T):	0 - 45 °C
Maksimal opløsning:	3840 x 2160 pixel
Understøttede grafikopløsninger:	1920 x 1200 (WUXGA),3840 x 2160
Certificering:	CE, FCC, REACH
Kabellængde:	0.15 m
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	300 mm
Hovedkassens længde (udvendigt):	325.1 mm
Hovedkassens bruttovægt (udvendigt):	10000 g
Hovedkassens bredde (udvendigt):	519.9 mm
Oprindelsesland:	Kina
Plug and play:	Ja
Maksimal opdateringshastighed:	60 Hz
HDMI-version:	1.4
Produkter pr. hovedkasse (udvendigt):	4 stk
Hovedkasse (udvendig) GTIN (EAN/UPC):	10037332237672
Stik 1:	DisplayPort
Stik 2:	HDMI + VGA (D-Sub)
Stik 1 køn:	Hanstik
Stik 2 køn:	Hunstik
Stikforbindelse kontakter plettering:	Nikkel/guld
HDCP-version:	1.4
Stik 1 formfaktor:	Lige
Kabeldiameter:	4.5 mm
Materiale for kapper:	ABS synthetics,Polyvinyl chloride (PVC)
