Quick Start Guide

Product Features

System Requirements

Package Includes

Installation

Mini DisplayPort to VGA / DVI / HDMI All-in-One Converter

Models: P137-06N-HDV, P137-06N-HDVW

Espanol 3 • Français 5 • Русский 7

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA surge

protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

• Connect a VGA, DVI, or HDMI monitor to a

Mini DisplayPort on your laptop or tablet

• All-in-One converter offers maximum ﬂexibility

to connect to any available monitor

• Portable design with built-in cable is perfect

for travel and stowing in your laptop bag

• Supports computer video resolutions up to

1920 x 1200, or HD video resolutions up to

1920 x 1080 (1080p)

• Supports up to 36-bit Deep Color (12 bits per

channel)

• Compatible with the Thunderbolt port on

Mac® computers, such as the Macbook Pro

and Macbook Air

• Passive converter requires no external power

supply

• Computer or tablet with a Mini DisplayPort • Monitor with a VGA, DVI, or HDMI port

• P137-06N-HDV or P137-06N-HDVW • Quick Start Guide

Notes:

• Only one monitor can be connected at a time.

• To connect a Mac to a HDMI monitor with audio, go

to “System Preferences” and select “Sound”. Then

click the “Output” tab and select your HDMI device

from the list. Mini DisplayPort audio is available Note:

on all Mac models introduced after April 2010.

• When connecting a DVI or HDMI monitor, the distance

between the converter and monitor must be no longer

than 6 ft. (2 m). When connecting a VGA monitor, the

distance must be no longer than 10 ft. (3 m).

Optional Accessories

• P502-006 High Resolution VGA Cable with

RGB Coax – 6 ft.

• P561-006 DVI-D Single Link Cable – 6 ft.

• P568-006 High Speed HDMI Cable – 6 ft.

1. Connect the converter to the Mini DisplayPort on your computer or tablet.

2. Connect a monitor to the VGA, DVI, or HDMI port on the converter.

17-12-256-9337BF.indb 1 1/24/2018 1:19:40 PM

Speciﬁcations

Warranty and Product Registration

Speciﬁcation Description

Input Signal Mini Displayport 1.1a

Output Signal VGA, DVI, and HDMI

Vertical Frequency Range 50/60 Hz

Video Ampliﬁer Bandwidth 2.25 Gbps / 225 MHz

Maximum Video Resolution 1920 x 1200 / 1920 x 1080 (1080p)

Maximum Cable Length 6 ft. (2 m) for DVI and HDMI, 10 ft. (3 m) for VGA

Operating Temperature 32 to 158 °F (0 to 70 °C)

Operating Humidity 10% to 85% RH, Non-Condensing

Storage Temperature 14 to 176 °F (-10 to 80 °C)

Storage Humidity 5% to 90% RH, Non-Condensing

Maximum Power Consumption 700mW

3-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in

materials and workmanship for a period of three (3) years from

the date of initial purchase. TRIPP LITE’s obligation under this

warranty is limited to repairing or replacing (at its sole option)

any such defective products. To obtain service under this

warranty, you must obtain a Returned Material Authorization

(RMA) number from TRIPP LITE or an authorized TRIPP LITE

service center. Products must be returned to TRIPP LITE or an

authorized TRIPP LITE service center with transportation charges

prepaid and must be accompanied by a brief description of the

problem encountered and proof of date and place of purchase.

This warranty does not apply to equipment, which has been

damaged by accident, negligence or misapplication or has been

altered or modiﬁed in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. Some states do not permit limitation or exclusion

of implied warranties; therefore, the aforesaid limitation(s) or

exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE

BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS

PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH

DAMAGE. Speciﬁcally, TRIPP LITE is not liable for any costs,

such as lost proﬁts or revenue, loss of equipment, loss of use of

equipment, loss of software, loss of data, costs of substitutes,

claims by third parties, or otherwise.

Product Registration

Visit www.tripplite.com/warranty today to register your new

Tripp Lite product. You’ll be automatically entered into a drawing

for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some

restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.

Note: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is

no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for

help.

Any changes or modiﬁcations to this equipment not expressly

approved by Tripp Lite could void the user’s authority to operate

this equipment.

WEEE Compliance Information for Tripp Lite Customers and

Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment

(WEEE) Directive and implementing regulations, when

customers buy new electrical and electronic equipment

from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one,

like-for-like basis (this varies depending on the

country)

• Send the new equipment back for recycling when

this ultimately becomes waste

WARNING

Use of this equipment in life support applications where failure

of this equipment can reasonably be expected to cause the

failure of the life support equipment or to signiﬁcantly affect its

safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Product

speciﬁcations are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

17-12-256-9337BF.indb 2 1/24/2018 1:19:40 PM
