Owner’s Manual

Metered Rack-Mount PDU

with Automatic Transfer Switch

Models: PDUMH15HVAT, PDUMH15HVATNET, PDUMH20HVAT,

PDUMH20HVAT1, PDUMH20HVATNET, PDUMH20HVATS,

PDUMNH20HVAT1

Series Number: AGAC7625

1. Important Safety Instructions 2

2. Installation 4

2.1 Mounting the PDU 4

2.2 Connecting the PDU 4

2.3 Networking the PDU 6

3. Features 7

4. Conﬁguration and Operation 10

4.1 Automatic Transfer Switch 10

5. Warranty and Product Registration 12

Español 13

Français 25

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR®

surge protector in our monthly drawing!

tripplite.com/warranty

SAVE THESE INSTRUCTIONS

• This manual contains instructions and warnings that should be followed

during the installation, operation and storage of this product. Failure to

heed these instructions and warnings may affect the product warranty.

• Warning: This equipment is compliant with Class A of CISPR 32. In a

residential environment, this equipment may cause radio interference.

• The PDU provides the convenience of multiple outlets, but DOES NOT provide surge or line noise

protection for connected equipment.

• The PDU is designed for indoor use only, in a controlled environment, away from excess

moisture, temperature extremes, conductive contaminants, dust or direct sunlight.

• Keep indoor ambient temperature between 0°C and 50°C (32°F and 122°F).

• The PDU must be installed by a qualified technician only.

• Do not attempt to mount the PDU to an insecure or unstable surface.

• Install in accordance with National Electrical Code standards ANSI/NFPA 70 and Canadian

Electrical Code, Part I, C22.1. Be sure to use the proper overcurrent protection for the

installation, in accordance with the plug/equipment rating.

• Connect the PDU to an outlet that is in accordance with your local building codes and that is

adequately protected against excess currents, short circuits and earth faults.

• The electrical outlets supplying power to the equipment should be installed near the equipment

and easily accessible.

• Do not connect the PDU to an ungrounded outlet or to extension cords or adapters that

eliminate the connection to ground.

• Be sure to provide a local disconnect device on any models that are permanently installed

without a plug that is easily accessible.

• Never attempt to install electrical equipment during a thunderstorm.

• Individual equipment connected to the PDU should not draw more current than the individual

PDU’s outlet’s rating.

• The total load connected to the PDU must not exceed the maximum load rating for the PDU.

• Do not attempt to modify the PDU, input plugs or power cables.

• Do not drill into or attempt to open any part of the PDU housing. There are no user-serviceable

parts inside.

• Do not attempt to use the PDU if any part of it becomes damaged.

• Use of this equipment in life support applications where failure of this equipment can reasonably

be expected to cause the failure of the life support equipment or to significantly affect its safety

or effectiveness is not recommended.

• The AC Mains tolerance of this equipment is +6/-10%

• Short-circuit backup protection and overcurrent protection is provided by the building installation.

• To reduce the risk of fire, connect only to a circuit provided branch circuit overcurrent protection

in accordance with the National Electrical Code, ANSI/NFPA 70 and the Canadian Electrical

Code, Part I, C22.1. Be sure to use maximum 20A overcurrent protection in accordance with

the plug/equipment rating, for the installation.

• The plugs on the power supply cords and appliance inlet serve as the disconnect devices. Make

sure the socket-outlets providing power to the PDU are easily accessible.

• This equipment is not suitable for use in locations where children are likely to be present.

1. Important Safety Instructions

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	PDUMNH20HVAT1
Peso:	4690
Color del producto:	Negro
Frecuencia de entrada AC:	50/60
Altura:	43.7
Profundidad:	375.2
Ancho:	440.2
Peso del paquete:	7710
Ancho del paquete:	528.3
Tipos de PDU:	Metered, Monitored
Tipo:	Monofásico
Capacidad del estante:	1U
Montaje:	Horizontal
Pantalla:	LCD
Interruptor de encendido/apagado:	Y
Tensión nominal de entrada:	208 - 240
Máxima corriente:	20 A
Potencia máxima:	3840
Tensión de salida:	200 - 240
Cantidad de salidas AC:	10
Enchufe de alimentación:	Acoplador C20
Tipo de salida AC:	C13 coupler, C19 coupler
Puertos Ethernet LAN (RJ-45):	1
Cantidad de puertos USB:	2
Cantidad de puertos seriales:	1
Longitud de cable:	3.66
Indicadores LED:	Y
Monitoreo:	Current, Voltage
Altura del paquete:	137.2
Profundidad del paquete:	594.4
Temperatura de almacenamiento (T-T):	-30 - 50
Humedad relativa de operación (H-H):	5 - 95
Cumplimiento de sustentabilidad:	Y
Certificados de sustentabilidad:	CE, RoHS
Cantidad por caja principal (externa):	1 piezas
País de origen:	Taiwán
