Side 1/12

Owner’s Manual

1111 W. 35th Street Chicago, IL 60609 USA

www.tripplite.com/support

Installation 2

FCC Part 68 Notice 3

Lifetime Limited Warranty 3

Ultimate Lifetime Insurance Policy 4

Protect It!™

Surge Suppressors

Español 5

™ is a trademark of Tripp Lite.

Warranty Registration 4

WARRANTY

REGISTRATION:

to win a FREE Tripp Lite product—

www.tripplite.com/warranty

Français 9

Important Safety Instructions 2

201010194 93-2666.indd 1 11/12/2010 9:36:52 AM

SAVE THESE INSTRUCTIONS

CAUTION! DO NOT connect to an ungrounded outlet. DO NOT use with 2-wire extension

cords or adapters. This surge suppressor is designed for indoor use only. Install the surge

suppressor away from heat-emitting appliances such as radiators or heat registers. Do not

install where excessive moisture is present. Do not plug extension cords into it. Never install

electrical, telephone, network or coaxial wiring during a lightning storm. Do not drill into any part

of the housing or open the housing for any reason. There are no user-serviceable parts inside.

Important Safety Instructions

• Use of this equipment in life support applications where failure of this equipment can reasonably be

expected to cause the failure of the life support equipment or to significantly affect its safety or

effectiveness is not recommended. Do not use this equipment in the presence of a flammable

anesthetic mixture with air, oxygen or nitrous oxide.

Installation

Mount Your Surge Suppressor (Optional Installation. Available on Select Models Only): If

desired, mount your surge suppressor on a wall or other sturdy, vertical surface. However, you must

mount the surge suppressor prior to connecting your equipment. Place a sheet of paper over the surge

suppressor’s mounting holes and mark their centers with a push pin. Next, place this template over the

desired area and mark with the push pins. Install screws (user supplied) into the marks until ¼ in. (0.6

cm) of the screw heads are exposed. Mount the surge suppressor over the screw heads and slide into

place.

Connect Your Surge Suppressor to the AC Power Line: Plug the surge suppressor’s power cord

into a standard, 3-wire grounded 120V AC outlet.

Turn Your Surge Suppressor ON: Press the surge suppressor’s power switch to “ON” or “RESET”

(depending on model). Select models feature an illuminated switch.

Check Your Surge Suppressor’s Diagnostic Indicator Lights (Available on Select Models Only):

If your surge suppressor features diagnostic LEDs, check them prior to connecting your equipment.

They will indicate various operating conditions when the surge suppressor is plugged into a live 120V

AC outlet and the surge suppressor’s power switch is on.

“PROTECTED” LED: Indicates the surge suppression components are intact and providing

complete protection against surges. If this LED does not illuminate, some of the surge suppression

components are not functioning, and the unit should be replaced. Visit www.tripplite.com/support.

“GROUNDED” LED: Indicates wall outlet is grounded and surge protection can properly

function. If this light DOES NOT illuminate and power is present, consult a qualified electrician to

examine your outlet’s wiring.

“GROUNDED” LED (STIK and SUPER8 only): Indicates wall outlet is grounded and surge

protection can properly function. If this light ILLUMINATES and power is present, consult a

qualified electrician to examine your outlet's wiring.

“LINE OK” LED (select models): Indicates 120V AC power is present with no wiring faults

detected.

Connect Your Equipment to the Surge Suppressor’s AC Outlets: Plug your equipment’s power

cords (including 2-wire devices) into the surge suppressor’s AC outlets. Select models feature

integrated safety covers which cover the outlets when not in use. Other models feature special widely-

spaced outlets to accommodate transformers without covering other outlets. DO NOT plug in

extension cords. DO NOT OVERLOAD the surge suppressor’s outlets. The surge suppressor can

accommodate a total equipment load of up to 15 amps (whether plugged into a single outlet or spread

out over multiple outlets). If the load on the surge suppressor exceeds 15 amps, the circuit breaker*

will trip and the outlets will stop providing power. If the circuit breaker trips, reduce the load by

unplugging some devices. Depress the circuit breaker to reset.

* Circuit breakers are integrated into the power switch on select models and offered as a separate feature on other models.

201010194 93-2666.indd 2 11/12/2010 9:36:52 AM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	Protect It! TLP604
Tænd-/slukkontakt:	Ja
Bredde:	47 mm
Dybde:	31.2 mm
Højde:	274.3 mm
Vægt:	360 g
Produktfarve:	Grå
Pakkevægt:	450 g
Pakkedybde:	124.5 mm
Pakkebredde:	40.6 mm
Pakkehøjde:	320 mm
Kabellængde:	1.2 m
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	335.3 mm
Hovedkassens længde (udvendigt):	436.9 mm
Hovedkassens bruttovægt (udvendigt):	9120 g
Hovedkassens bredde (udvendigt):	259.1 mm
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	20 stk
Hovedkasse (udvendig) GTIN (EAN/UPC):	10037332100495
Maksimal strøm:	1800 W
Strømstik:	NEMA 5–15P
Nominel indgangsspænding:	120 V
AC udgange, antal:	6 AC stikkontakt(er)
AC stikkontakt typer:	NEMA 5–15R
Overspænding energivurdering:	790 J
Nominel udgangsstrøm:	15 A
Spidsstrøm, almindelig modus:	36000 A
