Side 1/4

Owner’s Manual

Este manual esta disponible en español en la página de Tripp Lite:

www.tripplite.com/support

Ce manuel est disponible en français sur le site Web de Tripp Lite :

www.tripplite.com/support

Русскоязычная версия настоящего руководства представлена на веб-сайте

компании Tripp Lite по адресу: www.tripplite.com/support

Protect It!®

Surge Protectors

Important Safety Instructions 2

Installation 2

Warranty and Product Registration 3

Ultimate Lifetime Insurance Policy 4

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

® is a trademark of Tripp Lite.

17-04-264-9336F8-EN.indd 1 4/26/2017 4:07:18 PM

SAVE THESE INSTRUCTIONS

CAUTION! DO NOT connect to an ungrounded outlet. DO NOT use with 2-wire extension

cords or adapters. This surge protector is designed for indoor use only. Install the

surge protector away from heat-emitting appliances such as radiators or heat

registers. Do not install where excessive moisture is present. Do not plug extension

cords into it. Never install electrical, telephone, network or coaxial wiring during a

lightning storm. Do not drill into any part of the housing or open the housing for any

reason. There are no user-serviceable parts inside.

Important Safety Instructions

Installation

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to significantly

affect its safety or effectiveness is not recommended.

Mount Your Surge Protector (Optional Installation. Available on Select Models Only): If

desired, mount your surge protector on a wall or other sturdy, vertical surface. However, you

must mount the surge protector prior to connecting your equipment. Place a sheet of paper over

the surge protector’s mounting holes and mark their centers with a push pin. Next, place this

template over the desired area and mark with the push pins. Install screws (user supplied) into

the marks until ¼ in. (0.6 cm) of the screw heads are exposed. Mount the surge protector over

the screw heads and slide into place.

Connect Your Surge Protector to the AC Power Line: Plug the surge protector’s power cord

into a standard 3-wire grounded 120V AC outlet.

Turn Your Surge Protector ON: Press the surge protector’s power switch to “ON” or “RESET”

(depending on model). Select models feature an illuminated switch.

Check Your Surge Protector’s Diagnostic Indicator Lights (Available on Select Models

Only): If your surge protector features diagnostic LEDs, check them prior to connecting your

equipment. They will indicate various operating conditions when the surge protector is plugged

into a live 120V AC outlet and the surge protector’s power switch is on.

“PROTECTED” LED: Indicates the surge suppression components are intact and providing

complete protection against surges. If this LED does not illuminate, some of the surge

suppression components are not functioning, and the unit should be replaced.

Visit www.tripplite.com/support.

“GROUNDED” LED: Indicates wall outlet is grounded and surge protection can properly

function. If this light DOES NOT illuminate and power is present, consult a qualified electrician

to examine your outlet’s wiring.

“LINE OK” LED (select models): Indicates 120V AC power is present with no wiring faults

detected.

Connect Your Equipment to the Surge Protector’s AC Outlets: Plug your equipment’s power

cords (including 2-wire devices) into the surge protector’s AC outlets. Select models feature

integrated safety covers which cover the outlets when not in use. Other models feature special

widely-spaced outlets to accommodate transformers without covering other outlets. DO NOT plug

in extension cords. DO NOT OVERLOAD the surge protector’s outlets. The surge protector can

accommodate a total equipment load of up to 15 amps (whether plugged into a single outlet or

spread out over multiple outlets). If the load on the surge protector exceeds 15 amps, the circuit

breaker* will trip and the outlets will stop providing power. If the circuit breaker trips, reduce the

load by unplugging some devices. Depress the circuit breaker to reset.

* Circuit breakers are integrated into the power switch on select models and offered as a separate feature on other models.

17-04-264-9336F8-EN.indd 2 4/26/2017 4:07:18 PM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	Protect It! TLP66USBR
Vekselstrømsindgangsfrekvens:	60 Hz
Bredde:	91.9 mm
Dybde:	36.1 mm
Højde:	210.1 mm
Vægt:	740 g
Produktfarve:	Sort
Pakkevægt:	870 g
Pakkedybde:	45 mm
Pakkebredde:	169.9 mm
Pakkehøjde:	245.1 mm
Materiale:	Plast
Certificering:	UL1363, UL1449, cUL
LED-indikatorer:	Ja
Kabellængde:	1.8 m
Ledningsfri:	Ingen
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	260.4 mm
Hovedkassens længde (udvendigt):	362 mm
Hovedkassens bruttovægt (udvendigt):	8310 g
Hovedkassens bredde (udvendigt):	244.6 mm
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	10 stk
Hovedkasse (udvendig) GTIN (EAN/UPC):	10037332210132
USB-opladning:	Ja
Maksimal strøm:	1800 W
Strømstik:	NEMA 5–15P
Nominel indgangsspænding:	120 V
Port 1 udgangsstrøm:	3.4 A
Port 2 udgangsstrøm:	3.4 A
AC udgange, antal:	6 AC stikkontakt(er)
AC stikkontakt typer:	NEMA 5-15R
Overspænding energivurdering:	1080 J
Nominel udgangsstrøm:	15 A
Spidsstrøm, almindelig modus:	36000 A
