Owner’s Manual

SmartOnline® 16 & 20kVA UPS

with N+1 Conﬁguration Options

Models: SU16KRT, SU16KRT-1TF, SU16KRT8, SU16KRTG, SU16KRTHW, SU20KRT,

SU20KRT-1TF, SU20KRT8, SU20KRTG, SU20KRTHW, SU20KRTHWTFASSM

Introduction 2

Important Safety Warnings 3

Mounting 4

Features 6

Connection 8

Manual Bypass Operation 10

Storage & Service 12

Warranty & Product Registration 12

Español 13

Français 25

Русский 37

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

10kVA UPS Loads 10kVA and lower

Parallel

PDU

10kVA UPS

10kVA UPS Loads 10-20kVA

Parallel

PDU

10kVA UPS

Introduction

Your Tripp Lite 16/20kVA UPS system includes two 8/10kVA power modules along with a parallel PDU and communications cable that

combines the output of the two UPS power modules to directly power your equipment. Your UPS automatically supports N+1 fault tolerance

at load levels up to 50% and non-redundant operation at loads greater than 50%. The included parallel PDU with bypass switch also

enables hot-swappable replacement of either or both power modules without downtime. For additional conﬁguration assistance, contact

Tripp Lite.

10kVA Redundant Conﬁguration (10kVA max load) 20kVA Non-Redundant Conﬁguration (20kVA max load)

Redundant Operation YES

Fault-Tolerance YES

Hot-Swappable UPS Replacement YES

Increased Capacity NO

Redundant Operation NO

Fault-Tolerance NO

Hot-Swappable UPS Replacement YES

Increased Capacity YES

When two UPS systems are

loaded to a maximum of 50%,

your conﬁguration will receive full

redundancy—fault-tolerance with

full support for hot-swappable UPS

replacement in the case of sudden

UPS failure.

When two UPS systems are loaded to a maximum of 100%, your

conﬁguration will receive the full capacity of both UPS systems

combined to power larger loads. This conﬁguration does NOT

carry redundancy or fault-tolerance options. Hot-swappable UPS

replacement is possible if you put the PDU in bypass mode (See

“ ” Section).Manual Bypass Operation

To ensure fault-tolerance, load the two parallel UPS systems to a

maximum of 50% of the combined rating for both UPS systems. For

example, if you have two 10kVA UPS systems, you will have fault-

tolerant operation if the load level remains at 10kVA or lower.

Your can use this conﬁguration to grow your UPS power capacity to

16kVA (when two 8kVA UPS systems are used) or 20kVA (when two

10kVA UPS systems are used). In this conﬁguration, fault-tolerance

is NOT available.

For 16/20KVA UPS Conﬁgurations

• Economy-mode operation is not supported

• For best results, connect an equal number of external battery packs to each UPS power module.

Note: Use the included 8/10kVA power module manual for UPS operation and conﬁguration options once you have completed the setup of your 16/20kVA

UPS per the installation information on the following pages.

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	SUPDMB20K
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	176.8 mm
Dybde:	114 mm
Højde:	521.7 mm
Vægt:	6760 g
Pakkevægt:	9070 g
Pakkedybde:	596.9 mm
Pakkebredde:	325.1 mm
Pakkehøjde:	281.9 mm
Dimensioner (BxDxH):	178 x 114 x 521 mm
Certificering:	UL1778, CSA, EN62040-1
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	281.9 mm
Hovedkassens længde (udvendigt):	596.9 mm
Hovedkassens bruttovægt (udvendigt):	9070 g
Hovedkassens bredde (udvendigt):	325.1 mm
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	1 stk
Strømbeskyttelsesfunktioner:	Overbelastning
Input forbindertype:	Hardwire
Nominel udgangsspænding:	200-240 V
Nominel indgangsspænding:	200-240 V
AC udgange, antal:	10 AC stikkontakt(er)
AC stikkontakt typer:	C19 coupler,NEMA L6-30R
Strøm (maks.):	- A
PDU-typer:	Basis
