Maintenance Bypass Panel

Models: SUT20KMBP, SUT20KMBPX, SUT30KMBP, SUT40KMBPX

Installation and Operation Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Contents

1. Introduction 2

2. Important Information About This Manual 2

2.1 Manual Symbols 2

3. Safety Precautions 2

4. Inspection Upon Receipt of Goods 3

4.1 General 3

4.2 Visible Damage 3

4.3 Concealed Damage 3

4.4 Return of Damaged Goods 3

5. System Overview 3

6. System Speciﬁcations 3

6.1 Electrical 3

6.2 Environmental 3

6.3 General Speciﬁcations 3

7. Installation 4

7.1 Preparation 4

7.1.1 Equipment Inspection 4

7.1.2 Necessary Equipment and Tools 4

7.1.3 Installation Safety Precautions 4

7.1.4 Storage 4

7.2 Installation Steps 4

7.2.1 Equipment Location 4

7.2.2 Equipment Mounting 4

7.2.3 Equipment Connections 5

7.2.4 Pre-Energizing Inspection 5

7.2.5 Energizing 5

8. System Operation 6

9. Maintenance 6

9.1 Short Circuits and Overloads 6

10. Reference Materials 7

11. Warranty 8

Español 9

Français 17

Русский 25

Before installing or maintaining this equipment, it is extremely important to read this manual and be sure that all equipment drawings

and schematics are reviewed and clearly understood. If there are any questions concerning this manual or any of the installation or

maintenance procedures and/or requirements, please contact a Tripp Lite representative before proceeding.

Information in this manual is not intended for use as a training manual for nonqualiﬁed personnel.

When installing this equipment, always follow all applicable federal, state and local regulations to ensure safe and proper equipment

installation.

Only qualiﬁed persons should attempt to install or service this equipment. A qualiﬁed person is one who has skills and knowledge

related to the construction and operation of electrical equipment and installations and has received safety training on the hazards

involved.

Equipment installation and maintenance should always be performed with heavily insulated tools. It is also recommended to wear

rubber gloves and boots and to use insulating mats to stand on when working on this equipment.

Always wear eye protection when installing or maintaining power equipment.

To avoid personal injury, including electrical shock, severe burns and possible death, all jewelry, including bracelets, rings and

watches, must be removed prior to installing or servicing this equipment.

For the safety of others, never leave an open cabinet or panel unattended.

Any modiﬁcations to the equipment without authorization by Tripp Lite could result in equipment damage, personal injury or death.

Never work on power equipment while it is energized. De-energize equipment and lock off all power to the equipment before working

inside.

Inspection and maintenance should only be performed on equipment that has been de-energized and electrically isolated so that no

accidental contact can be made with energized parts.

SAVE THESE INSTRUCTIONS!

This manual contains important information that is needed during the installation and maintenance of the system.

3. Safety Precautions

1. Introduction

2. Important Information About This Manual

2.1 Manual Symbols

Warning:

Indicates information provided to protect the user against personal injury, safety hazards and/or possible equipment damage.

Electrical Hazard:

Indicates that an electrical hazard exists that will result in personal injury or death if instructions are not followed.

Important:

Indicates information provided as an installation or operating instruction or tip, as well as general important installation and system

information.

Tripp Lite would like to thank you for choosing our product for your equipment needs. We know there are a lot of choices and we appreciate

the opportunity to supply each of our customers with the highest-quality power products manufactured in the United States today. All of our

solutions are factory-tested to the highest standards.

Sales support for future equipment needs or upgrades is provided by our regional sales staff and qualiﬁed representatives. All technical

questions and service issues should be directed to our main ofﬁce by visiting www.tripplite.com/support.

Tripp Lite

www.tripplite.com

Technical Support

www.tripplite.com/support

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	SUT30KMBP
Bredde:	508 mm
Dybde:	116.8 mm
Højde:	444.5 mm
Vægt:	8620 g
Brugervejledning:	Ja
Produktfarve:	Sort
Kontroltype:	Løftestang
Produkttype:	Bypass-afbryder
Pakkevægt:	17240 g
Pakkedybde:	635 mm
Pakkebredde:	558.8 mm
Pakkehøjde:	254 mm
Husmateriale:	Galvaniseret stål
Monteringstype:	Vægbeslag
Bæredygtighedscertifikater:	RoHS
Indgangsspænding:	120 V
Hovedkassen højde (udvendigt):	254 mm
Hovedkassens længde (udvendigt):	635 mm
Hovedkassens bruttovægt (udvendigt):	17240 g
Hovedkassens bredde (udvendigt):	558.8 mm
Oprindelsesland:	USA
Produkter pr. hovedkasse (udvendigt):	1 stk
Antal faser:	3
