Side 1/12

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

Owner’s Manual

Super Series

Surge Suppressors

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

The Super Series line of quality surge suppressors protects your sensitive equipment from spikes,

surges and line noise on the AC power line. Super Series “PLUS TEL” and “DELUXE” models

include RJ-style phone jacks for protection against spikes, surges and line noise on a single

telephone line. Super Series “PLUS COAX” models include F coaxial jacks for protection against

spikes, surges and line noise on a standard cable TV coaxial line.

Connecting the Super Series Surge Suppressor

Connection to AC Power Line (All Models)

The Super Series Surge Suppressor power cord should only be connected to a standard 3-wire

grounded 120 Volt AC 60 Hz outlet. The Super Series Surge Suppressor is equipped with a 4-way

mounting bracket and can be mounted on a ﬂat surface or wall. Use #8 round-head screws.

CAUTION!

DO NOT connect to an ungrounded AC outlet. DO NOT use with 2-wire

extension cords or adapters. Lack of a proper ground connection will

eliminate common-mode protection and cause small leakage potential

on the case. However, you can plug 2-wire devices into any of the surge

suppressor’s outlets. COAX models are NOT lightning arrestors. DO NOT

install COAX models in line with TV, AM, FM, amateur radio or any other

kind of outside antenna used either for reception or transmission of

radio or television signals.

201002037 93-1847.indb 1 2/8/2010 11:29:55 AM

Connection To Telephone Line (Select Models Only)

Super Series PLUS TEL and DELUXE models have two female RJ-style phone jacks that accept

connection of a wide range of equipment with male RJ-style plugs. These models provide 2-wire/

single telephone line protection. PLUS TEL and DELUXE models MUST always be the FIRST

item connected in line from the telephone jack. They MUST always be plugged into a 3-wire

grounded outlet for the telephone protection to work. Connect the phone cord from the wall jack

directly to the jack labelled “IN” (or “LINE”). Connect the phone cord from the device to be

protected directly to the jack labelled “OUT” (or “EQUIP”). The connected equipment is now

protected against spikes, surges and line noise on the telephone line.

Connection To Coaxial Line (Select Models Only)

Super Series PLUS COAX models have two “F” connector jacks that accept connection of

equipment with coaxial cables. PLUS COAX models MUST always be the FIRST item connected

in line from the coaxial jack. PLUS COAX models MUST always be plugged into a 3-wire

grounded outlet for the coaxial protection to work. Connect the coaxial cable from the wall jack

directly to the PLUS COAX jack labelled “LINE” (or “IN”). Connect the coaxial cable from

the device to be protected directly to the PLUS COAX jack labelled “EQUIP” (or “OUT”). The

connected equipment is now protected against spikes, surges and line noise on the coaxial cable.

Connecting the Super Series Surge Suppressor continued

Connecting Equipment

Features

After you have properly connected your Super Series Surge Suppressor to the AC line (and

telephone and coaxial line, if applicable), you can connect the AC power cords of equipment to

the surge suppressor. DO NOT OVERLOAD the surge suppressor. Connect loads having a total

current draw of up to 15 amps. Each outlet can handle up to 15 amps, but do not exceed a total

load of 15 amps for all outlets. If the circuit breaker trips, remove overload and depress circuit

breaker button to reset.

Circuit Breaker (All Models)

If the current draw of the equipment connected to the Super Series Surge Suppressor exceeds 15

amps for longer than a few seconds, the circuit breaker will open (trip) to prevent any possible

damage. When the circuit breaker trips, the plunger will be extended. Allow the breaker to cool

for one minute before depressing the plunger to reset.

Illuminated “ON/OFF” Switch (Select Models)

With the Super Series Surge Suppressor plugged into a 120V AC outlet, this switch will

illuminate RED whenever moved to the “ON” position. This indicates 120V AC power is present

at the unit’s AC receptacles.

Diagnostic Indicator Lights

There are up to three LEDs on the front panel that indicate various operating parameters when the

unit is plugged into a live 120V AC outlet.

• Protection Present (Green LED) (All Models)

Indicates the surge suppression components are intact and providing full protection against

spikes and surges. This LED should be illuminated anytime the “ON/OFF” switch is

turned ON and power is present as indicated by the lighted power switch. If the Protection

Present LED does not illuminate, then some of the surge suppression components are not

functioning and the unit should be returned for repair as soon as possible. You may still use

the unit; however, connected equipment will be protected from spikes and surges at a lesser

level than normal.

201002037 93-1847.indb 2 2/8/2010 11:29:55 AM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Ikke kategoriseret
Model:	TR-6FM
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	88.9 mm
Dybde:	241.3 mm
Højde:	44.4 mm
Vægt:	750 g
Produktfarve:	Grå
Pakkevægt:	1040 g
Pakkedybde:	317.5 mm
Pakkebredde:	152.4 mm
Pakkehøjde:	50.8 mm
Responstid:	0.000001 ms
Kabler inkluderet:	Telefon (RJ-11)
Materiale:	Plast
Certificering:	UL, FCC, cUL/CSA
LED-indikatorer:	Ja
Kan monteres på væggen:	Ja
Kabellængde:	1.83 m
Ledningsfri:	Ingen
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	342.9 mm
Hovedkassens længde (udvendigt):	533.4 mm
Hovedkassens bruttovægt (udvendigt):	19100 g
Hovedkassens bredde (udvendigt):	317.5 mm
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	20 stk
Kabelfarve:	Grå
Hovedkasse (udvendig) GTIN (EAN/UPC):	10037332010619
Antal RJ-11-porte:	2
Maksimal strøm:	1800 W
Strømstik:	NEMA 5–15P
Nominel indgangsspænding:	120 V
AC udgange, antal:	6 AC stikkontakt(er)
AC stikkontakt typer:	NEMA 5–15R
Overspænding energivurdering:	3040 J
Beskyttelsesfunktioner mod strømstød:	Fax, Modem, Telephone
EMI/RFI støjfiltrering:	Ja
Nominel udgangsstrøm:	15 A
Spændingsblokering:	140 V
