TABLE OF CONTENTS Rev. 11/8/2021 COL, MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Corp. Page 1 of 20
COL-X-XX-XX & -HDG (HOT DIP GALVANIZED)
CROSS OVER LADDERS - INSTRUCTION MANUAL
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the
packaging and maintains the orientation of the product in the packaging; then inspect the product closely
to determine whether it sustained damage during transport. If damage is discovered during the
inspection, immediately record a complete description of the damage on the bill of lading. If the
product is undamaged, discard the packaging.
NOTES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where
the product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either: a)
the instructions in this manual; or b) information provided on labels affixed to the product. Neither is Vestil
responsible for any consequential damages sustained as a result of failing to exercise sound judgment
while assembling, installing, using or maintaining this product.
V
ESTIL
M
ANUFACTURING
C
ORP
.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: info@vestil.com
Table of Contents
Page
Signal Words
………………………………………………………………………………………….………………
2
Safety Instructions
…………………………………………………………………………..……………………….
2
Exploded Parts Diagrams and Bills of Materials………..………………………………
………………………..
3 - 18
Labeling Diagram.………….….
……………………………………………………….........................................
19
Limited Warranty
……………………………………………………………………………………………….…….
20
TABLE OF CONTENTS Rev. 11/8/2021 COL, MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Corp. Page 2 of 20
SIGNAL WORDS
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable
seriousness of those injuries, if the product is misused in the ways described. Other signal words call attention to
uses of the product likely cause property damage. The signal words used appear below along with the meaning of
each word.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme
situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.
Each person who assembles, installs, uses, or maintains this product should read the entire manual and fully
understand the directions in advance. If after reading the manual you do not understand an instruction, ask
your supervisor or employer for clarification, because failure to adhere to the directions in this manual
might result in serious personal injury.
SAFETY INSTRUCTIONS
Vestil diligently strives to identify foreseeable hazards associated with the use of its products. However, material
handling is inherently dangerous and no manual can address every conceivable risk. The end-user ultimately is
responsible for exercising sound judgment at all times.
Electrocution might result if any part of the product contacts electrified wires. Reduce the likelihood of
electrocution by applying common sense:
DO NOT contact electrified wires with any part of this device, your body, or clothing.
DO NOT use or store the product where contact with electrified wires is likely.
Always inspect the usage area before using the product & implement precautions that account for conditions.
If this product is used improperly or carelessly, the operator and/or bystanders might sustain serious
personal injuries or even be killed. To reduce the likelihood of injury:
• Failure to read and understand the entire manual before assembling, installing, using or servicing the
product is a misuse of the product.
• Read the manual to refresh your understanding of proper use and maintenance procedures.
• DO NOT attempt to resolve any problem(s) with the product unless you are both authorized to do so and certain that it
will be safe to use afterwards.
• DO NOT modify the product in any way. Modifying the unit automatically voids the LIMITED WARRANTY and might
make the unit unsafe to use.
• DO NOT use the unit until it is solidly anchored to the floor with 3/8” anchor bolts that are at least 4.5” long.
• DO NOT exceed the maximum rated load. See Label 1153 in LABELING DIAGRAM on p. 19.
• Inspect the product at least once per week.
A. DO NOT use this product if the inspection damage. Examples of structural damage include, but are not limited
to, the following: 1) Cracked, broken or significantly deformed load-bearing members; 2) cracked welds; 3)
missing or deformed safety chain/strap; 3) corrosion, severe wear; 4) other conditions that affect the ability of the
product to support weight or itself. Replace each part that fails to pass an inspection and DO NOT use the
product until it is repaired.
B. DO NOT use the product if any unusual noise or movement is observed. If a malfunction occurs, remove the unit
from service and notify your supervisor & maintenance personnel about the issue.
• DO NOT use this device UNLESS all product labels are readable and undamaged. See LABELING DIAGRAM.
Proper use, maintenance, and storage are essential for this product to function properly.
o Always use this product in accordance with the instructions in this manual and consistent with any training relevant
to machines, devices, etc. used in conjunction with this product.
o Keep the product clean & dry.
o Thoroughly inspect the unit at least once per week for damage such as broken welds, breaks, deformations,
significant wear or rusting/corrosion of frame members, handrails, or steps. DO NOT continue to use the unit until all
damage is repaired and all replacement parts are installed.
