EHLT, EHLTD & PST, 24-126-120, 0413.doc
V
ESTIL MFG. CO. 1
VESTIL MANUFACTURING CORP.
2999 N. Wayne St., Angola, IN 46703
Ph: 260-665-7586 · Fax: 260-665-1339
E-mail: sales@vestil.com · Website: www.vestil.com
MODELS EHLT (1-4K), EHLTD (2K, 70RH) & PST (1-3K),
43”-55” RAISED HEIGHTS
Serial number ____________
Installation Instructions ……..................…………....… 2
Operation Instructions ……………………….….…… 3-4
Routine Maintenance & Safety Checks …………….… 5
Structural, Exploded Parts (EHLT) .............…….….…. 6
Structural, Exploded Parts (PST) ...........………............ 7
Structural Bill of Materials (EHLT & PST) ................... 8
Motor & Transformer Connections ................................ 9
Electrical & Hydraulic Diagrams .............................. 10-12
Power Unit’s Operation ………………...…..………... 13
DC Power Unit, Exploded Parts ................................ 14-15
AC Power Unit, Exploded Parts ................................ 16-17
Troubleshooting …………………………....………… 18
Safety Label Identification .............................................19
Warranty …………………………………….……..…. 20
IMPORTANT NOTES, WARNINGS AND SAFETY INSTRUCTIONS
Ensure that all employees understand and follow the following.
Failure to read and understand this owner’s manual before using or
servicing the scissor lift constitutes a misuse of the product. All persons
who will install, use, or care for this product must be familiar with this
information.
o Non-portable units must be securely anchored to a level concrete surface.
o The scissor lift is intended for use only on level, concrete surfaces.
o The lift’s load must be centered and evenly distributed on the platform.
o The platform should be lowered before transporting any loads (PST only).
o The load must be removed and the platform fully lowered before any work
is performed on the scissor lift.
o Do not use the scissor lift if any damage or unusual noise is observed.
o Always watch the load carefully when the scissor lift is in operation.
o Ensure that all information/ safety/warning labels remain in place and are
legible. See the labels page.
o For battery-powered units, review the Battery Info page.
o Do not use brake fluid or jack oils in the hydraulic system. If oil is needed,
use an anti-wear hydraulic oil with a viscosity grade of
150 SUS at 100°F, (ISO 32 cSt @ 40°C), or Dexron transmission fluid.
o Contact the manufacturer for any needed MSDS information.
Do not perform any modifications to the scissor lift without the
manufacturer’s approval. Failure to receive authorization for changes to
the equipment could void the warranty.
Maintenance and repairs are to be done only by personnel qualified to
perform the required work. Consideration will not be given for warranty
repair charges without prior written authorization by the manufacturer.
WHEN ORDERING
REPLACEMENT PARTS:
We take pride in using quality
parts on the equipment we
manufacture. We are not
responsible for equipment
problems resulting from the use
of unapproved replacement
parts.
To order replacement or
spare parts for this equipment,
contact the factory.
In any communication with
the factory please be prepared
to provide the machine’s serial
number, which is indicated on
the machine dataplate.
RECEIVING INSTRUCTIONS
It is possible that this product
could incur damage during
transit.
Inspect the unit closely when
it arrives. If you see evidence
of damage or rough handling to
either the packaging or to the
product when it is being
unloaded, immediately
make a
note of it on the Bill Of Lading!
It is important that you
remove the product’s packaging
upon its arrival to ensure that
there is no concealed damage
or to enable a timely claim with
the carrier for freight damage.
Also verify that the product
and its specifications are as
ordered.
OWNER’S
MANUAL
