Table of Contents Rev. 5/23/2025 FHSN, MANUAL.doc
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 1 of 17
FHSN-Series Knockdown Steel Fixed Height Gantry Cranes
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to
determine whether it sustained damage during transport. If damage is discovered, record a
complete description of
it on your bill of lading. If the product is undamaged, discard the
packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and
maintenance comply with laws, regulations, codes, and mandatory standards applied where the
product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts,
labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The
department
can also be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-manuals.php.
Vestil Manufacturing Co.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestil.com e-Mail: info@vestil.com
Specifications……...………………....….
FHSN Exploded Views………………………………………..
Signal Words….……………………..……
Fig. A: FHSN-2-10, FHSN-2-15, & FHSN-2-20……………….
Safety Instructions……………………..
Fig. B: FHSN-4-10, FHSN-4-15, & FHSN-4-20……………….
National Standards………………….…
Fig. C: FHSN-6-10, FHSN-6-15, & FHSN-6-20…………….….
Assembling the Crane……….…….....
Fig. D: FHSN-8-10, FHSN-8-15, & FHSN-8-20……………….
Using the Crane……………………..…
Fig. E: FHSN-10-10 & FHSN-10-15………………………...…
Loading the Crane………………...….
Installing the Optional Festoon Kit……………………….
Record of Satisfactory Condition….
Inspections & Maintenance…………..
Labeling Diagram…………………….
Limited Warranty………………...……
