Side 1/36
Operator’s Manual
High Power Countertop Induction Ranges with Temperature Control Probe
©
2020 The Vollrath Company L.L.C. Part No. 351714-1 ml 2/28/20
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
Warning is used to indicate the presence of a hazard that will or can
cause severe personal injury or death.
Caution is used to indicate the presence of a hazard that will or can
cause minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment:
• Unplug this equipment from the wall outlet when not in use.
• Use this equipment only in a flat, level position.
• To protect against electrical shock do not immerse the cord or plug
in water. Keep the cord away from heated surface. Do not let the
cord hang over the edge of table or counter.
• As a precaution, persons using a pacemaker should stand back 12"
(30 cm) from an operating unit. Studies have shown that the
induction element will not disrupt a pacemaker.
• Keep all credit cards, driver licenses and other items with a magnetic
strip away from an operating unit. The unit’s magnetic field will
damage the information on these strips.
• The heating surface is made of a strong, non-porous material.
However, should it crack or break, stop using and immediately
unplug the unit. Cleaning solutions and spills could penetrate the
broken cooktop and create a risk of electrical shock.
• Do not operate this equipment with a damaged cord or plug or if it is
not functioning properly.
• Do not operate unattended. Closely supervise units operating in
public areas and/or around children.
• Do not place any objects inside the air intake or exhaust panels.
• Do not modify the equipment or a attach any accessory other than
the included temperature control probe and USB flash drive.
TABLE OF CONTENTS
Function and Purpose ................................................. page 1
Cookware Requirements ............................................. page 2
Environment Requirements ......................................... page 2
Clearance Requirements ............................................. page 2
Features and Controls ................................................. page 3
Operation .................................................................... page 4
Edit the Default Programs ........................................... page 7
Cleaning ...................................................................... page 8
TroubleShooting ......................................................... page 9
Replace the Fuse ......................................................... page 11
FUNCTION AND PURPOSE
This equipment is intended to heat food in commercial food service
operations only. It is not intended for household, industrial or
laboratory use.
It is intended to be used with induction-ready cookware. Performance
is optimized with Vollrath induction-ready cookware. Other cookware
may have different properties which may alter performance.
The Temperature Control Probe is intended to provide advanced
temperature control. It is not intended to be used as a thermometer for
measuring the temperature of food. The temperature control probe port
is intended for use only with the Vollrath supplied probe. It is not a
headphone jack. The USB port is intended for use only with the
supplied USB flash drive.
WARNING
CAUTION
Item No.
Watts Plug
Item No.
Watts Plug
HPI4-2600 2600
NEMA
6-20P
HPI4-300002
3000
Schuko
HPI4-3000 3000 HPI4-300003 UK
HPI4-3800 3800 HPI4-300004 China
HPI4-260002
2600
Schuko HPI4-380002
3800
Schuko
HPI4-260003 UK HPI4-380003 UK
HPI4-260004 China HPI4-380004 China
2 High Power Countertop Induction Ranges with Temperature Control Probe Operator’s Manual
COOKWARE REQUIREMENTS
Note: Cookware with inferior construction or material may not perform
well. Cookware with a larger base diameter can be used, however only
the area of the cookware above the induction coil will heat. The more
cookware extends past the coil, the more the overall performance will
be reduced.
ENVIRONMENT REQUIREMENTS
NOTICE: Indoor use only.
NOTICE: Do not place the equipment on or near heat-producing
equipment.
NOTICE: This equipment requires a dedicated circuit.
CLEARANCE REQUIREMENTS
NOTICE: This equipment is not designed to be enclosed or built into any area. Sufficient airflow must be allowed around the equipment.
Blocking the airflow could reduce performance.
Compatible
Incompatible
•Flat base 4¾" to 14"
(12.1 to 35.6 cm) in diameter
• Ferrous stainless steel, iron, cast
iron
• Base is not flat
• Base is less than 4¾"
(12.1 cm) in diameter
• Pottery, glass, aluminum,
bronze or copper cookware
4¾" to 14"
less than 4¾"
Maximum Ambient Temperature as measured at the air intake. See
below): 104°F (40°C)
2" (5.1 cm) minimum clearance Air intake Air exhaust
Single Range Two Ranges
NOTICE: Operating more than two ranges side by side is not recommended.
