Side 1/15

CONTENTS

BEFORE USING THE WASHING MACHINE

FIRST WASH CYCLE

PRECAUTIONS AND GENERAL RECOMMENDATIONS

DESCRIPTION OF THE WASHING MACHINE

PREPARATION OF THE WASHING

DETERGENTS AND ADDITIVES

CLEANING THE FOREIGN BODY TRAP

DRAINING RESIDUAL WATER

CARE AND MAINTENANCE

TROUBLESHOOTING GUIDE

AFTER-SALES SERVICE

TRANSPORT AND HANDLING

INSTALLATION

ELECTRICAL CONNECTION

3gb10019.fm5 Page 58 Friday, July 13, 2001 7:30 PM

Black Process Plate

BEFORE USING THE WASHING MACHINE

1.Remove the packaging and check

a. Cut and remove the shrink-wrap.

b.Remove the top protection and the protective

corners.

c. Remove the bottom protection by tilting and

turning the appliance on one rear bottom

corner.

2.Remove the transport bracket

•The appliance is fitted with transport screws and

a transport bracket to prevent damage during

transport. Before using the washing machine

you must remove the transport bracket (see

“Installation/Remove the transport bracket”).

Do not forget to screw back 4 screws to the rear

panel by which was fixed the transport bracket - to

avoid noisy and vibration of the machine.

3.Install the washing machine

•Place the appliance on a flat and stable floor

surface.

• Adjust the feet to ensure that the machine is

stable and level (see “Installation/Adjust the

feet”).

4.Water supply

•Connect the water supply inlet hose in

accordance with the regulations of your local

water company (see “Installation/Connect the

water inlet hose”).

• Water supply: Cold water only

• Tap: 3/4” threaded hose connection

• Pressure: 100-1000 kPa (1-10 bar).

“For Great Britain & Ireland only:

•Water inlet: hot and cold fill. The warm water

inlet temperature must not exceed 60° C.”

5.Drain hose

•Connect the drain hose to the siphon or hook it

over the edge of a sink with the “U” bend (see

“Installation/Connect the water drain hose”).

•If the washing machine is connected to a built-

in drainage system, ensure the latter is equipped

with a vent to avoid simultaneous loading and

draining of water (siphoning effect).

6.Electrical connection

•Electrical connections must be carried out by a

qualified technician in compliance with the

manufacturer’s instructions and the current

standard safety regulations.

•The technical data (voltage, power and fuses)

are given on the rating plate on the rear of the

appliance.

•The appliance must be connected exclusively by

means of a socket with an earth connection in

accordance with current regulations. The

appliance must be earthed by law. The

manufacturer declines all liability for damage to

persons or property deriving directly or

indirectly from failure to observe the directions.

•Do not use extension leads or multi sockets.

•Before any maintenance on the washing

machine disconnect it from the mains supply.

•Access to the mains plug or to disconnection

from the mains supply via a double-pole switch

must be ensured at all times following the

installation.

•Do not operate the washing machine if it has

been damaged during transport. Inform the

After-Sales Service.

•Mains cable replacement is only to be carried out

by After-Sales Service.

•The appliance must be connected to an effective

earthing installation, in compliance with the

regulations in force. In particular, appliances

installed in premises containing a shower or a bath

must be protected by a differential residual current

device of at least 30 mA. Earthing the appliance is

obligatory under the law. The manufacturer declines

all liability for damage to persons or property

deriving either directly or indirectly from failure to

observe the directions above.

•The washing machine may only be used in the

household for the prescribed uses.

Dimensions:

Width: 400 mm

Height: 900 mm

Depth: 600 mm

3gb10019.fm5 Page 59 Friday, July 13, 2001 7:30 PM

Black Process Plate
