Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

1. Control panel

2. Fan

3. Circular heating element

(not visible)

4. Shelf guides

(the level is indicated on the

front of the oven)

5. Door

6. Water drawer

7. Upper heating element/grill

8. Lamp

9. Identification plate

(do not remove)

10. Lower heating element

(not visible)

CONTROL PANEL DESCRIPTION

3 4 5 76 8 9

1. ON / OFF

For switching the oven on and

off and for stopping an active

function.

2. FUNCTIONS DIRECT ACCESS

For quick access to the functions

and menu.

3. NAVIGATION BUTTON MINUS

For scrolling through a menu and

decreasing the settings or values

of a function.

4. BACK

For returning to the previous

screen.

During cooking, allows settings to

be changed.

5. DISPLAY

For immediately starting a

function.

6. CONFIRM

For confirming a selected function

or a set value.

7. NAVIGATION BUTTON PLUS

For scrolling through a menu and

increasing the settings or values of

a function.

8. OPTIONS / FUNCTIONS DIRECT

ACCESS

For quick access to the functions,

duration, settings and favorites.

9. START

For starting a function using the

specified or basic settings.

ACCESSORIES

WIRE SHELF DRIP TRAY BAKING TRAY SLIDING RUNNERS*

Use to cook food or as a

support for pans, cake tins

and other ovenproof items

of cookware.

Use as an oven tray for

cooking meat, sh,

vegetables, focaccia, etc. or

position underneath the wire

shelf to collect cooking

juices.

Use for cooking all bread and

pastry products, but also for

roasts, sh en papillotte, etc.

To facilitate inserting or

removing accessories.

* Available only on certain models

The number and the type of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf horizontally by sliding it across

the shelf guides, making sure that the side with the

raised edge is facing upwards.

Other accessories, such as the drip tray and the

baking tray, are inserted horizontally in the same way

as the wire shelf.

REMOVING AND REFITTING THE SHELF GUIDES

• To remove the shelf guides, lift the guides up and

then gently pull the lower part out of its seating:

The shelf guides can now be removed.

• To refit the shelf guides, first fit them back into

their upper seating. Keeping them held up, slide

them into the cooking compartment, then lower

them into position in the lower seating.

FITTING THE SLIDING RUNNERS (IF PRESENT)

Remove the shelf guides from the oven and remove

the protective plastic from the sliding runners.

Fasten the upper clip of the runner to the shelf guide

and slide it along as far as it will go. Lower the other

clip into position. To secure the guide, press the lower

portion of the clip firmly against the shelf guide.

Make sure that the runners can move freely. Repeat

these steps on the other shelf guide on the same

level.

Please note: The sliding runners can be tted on any level.
