Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

FIRST TIME USE

Wait at least two hours, after the installation, before connecting

the appliance to the power supply. Connect the appliance to the

power supply it starts the operation automatically. The ideal storage

temperatures for the food are preset in the factory.

After turning the appliance on, you must wait for 4-6 hours for the

correct storage temperature to be reached for a normally lled

appliance.

CONTROL PANEL

1. On/stand-by indicator

2. Fast cool indicator

3. Precision control indicator

4. Fridge/freezer temperature display (°C)

5. Stop alarm indicator

6. Fast freeze indicator

7. Black out alarm indicator

8. Fridge temperature button / fast cool

button

9. Precision control button

10. On/stand-by

11. Stop alarm

12. Freezer temperature button / fast freeze

button

1 2

6 7

8 9

11 12

ON/STANDBY

To put the product in Stand-by, press and hold the On/ Stand By button

for 3 seconds. All the indicators turn o except On/Standby indicator.

Press again to reactivate the appliance.

FRIDGE TEMPERATURE

To adjust the Fridge Temperature, press the Fridge °C button. The

Fridge Temperature can be adjusted between +2°C and + 8°C, as

shown by the Fridge Temperature LEDs.

FREEZER TEMPERATURE

To adjust the Freezer Temperature, press the Freezer °C button. The

Freezer Temperature can be adjusted between -16°C and -24°C, as

shown by the Freezer Temperature LEDs.

FAST COOL

Using Fast Cool function it is possible to increase the cooling

capacity in the refrigerator compartment. The use of this function

is recommended when placing a very high quantity of food in the

refrigerator compartment. Press the Fast Cool button to activate Fast

Cool function. When activated, the Fast Cool indicator turns on. The

function is automatically disabled after 6 hours, or can be manually

disabled by pressing Fast Cool button again.

FAST FREEZE

The use of this function is recommended when placing a very high

quantity of food to be frozen in the freezer compartment.

24 hours before freezing fresh food, press the Fast Freeze button to

activate the Fast Freeze function. When activated, the Fast Freeze

indicator turns on. After 24 hours place the food to be frozen in the

middle freezing zone of freezer compartment.

The function is automatically disabled after 48 hours, or can be

manually disabled by pressing Fast Freeze button.

PRECISION CONTROL FUNCTION

Precision control function is an advanced technology that reduces

temperature uctuations in the whole freezer compartment to

minimum, thanks to an innovative air system, totally independent from

the fridge. Freeze burns are reduced up to 60% and food preserves its

original quality and color. To activate/deactivate the precision control

function simply press the precision control function button. The

function works properly in a dened range of temperature: between

-22°C and -24°C.

When the function is engaged and the current temperature in the

freezer is set to the warmer set point than -22°C, the temperature is

automatically set to -22°C to match the working range. If the function

is engaged and the user modify the freezer temperature out of the

working range, the function is automatically switched o. In case of

Fast freezing is engaged, the function “Precision control function” is

inhibited until the Fast Freezing function switched o.

FAN*

The Fan improves temperature distribution inside the refrigerator

compartment, allowing better preservation of stored food.

The fan will start/stop working depending on the temperature and/

or humidity level inside the fridge. If the appliance has the Fan it can

be equipped with the antibacterial lter. If the appliance has the Fan it

can be equipped with the antibacterial lter. Visit the website page or

contact consumer service to purchase the lter.

LED LIGHT

If the LED light system does not work, please contact the Service to

replace it.

Important: The refrigerator compartment light switches on when the

refrigerator door is opened. If the door is kept open for more than 8

minutes the light will be automatically switched o.

HUMIDITY CONTROL*

Open the humidity

regulator (position B) if you

want to store food in a less

humid environment like

fruit, or close it (position

A) to store food in a more

humid environment like

vegetable.

TUCK SHELF*

Thanks to the rail system, this shelf allows you to slide under the front

part, creating an extra space for storing tall bottles or pitchers.

EASY ACCESS TRAY IN FREEZER*

Freezer tray is useful to easily access frequently used products, freeze

or simply store leftovers or small items.

* Available only on certain models

NO-FROST REFRIGERATOR COMPARTMENT

Refrigerator compartment defrosting is completely automatic.

Droplets of water on the rear wall inside the refrigerator compartment

indicate that the automatic defrost phase is in progress.

The defrost water is automatically run into a drain hole and collected in

a container, where it evaporates.

FRESH BOX 0°

The Fresh Box 0° compartment guarantees a temperatures operating

range from -2°C to 3°C depending on chosen fridge temperature

setting which is ideal to:

• store meat, sh and delicate food;

• rapid cooling of hot foods;

• low temperature defrosting (it inhibits the proliferation of

microorganisms)

You can get the 0°C temperature, in standard conditions, when the

fridge compartment temperature is set for minimum temperature.

Remember that by changing the fridge temperature you change the

Fresh Zone 0° compartment temperature as well. Keep in mind that

Fresh Box 0° compartment is a mechanical feature operating all the

time, it cannot be switched o.

NO-FROST FREEZER COMPARTMENT

No Frost freezers provide chilled air circulation around the storage

areas, and prevent the formation of ice, thereby completely eliminating

the need for defrosting.

Frozen items don’t stick to the walls, labeling stays legible and storage

space remains neat and clear.

HOW TO STORE FRESH FOOD AND BEVERAGE

Legend

TEMPERATE ZONE

Suggested for storage of tropical fruit, cans, drinks,

eggs, sauces, pickles, butter, jam

COOL ZONE

Suggested for the storage of cheese, milk, daily food,

delicatessen, yogurt

COOLEST AREA

Suggested for the storage of cold cuts, desserts, meat

and sh

FRUIT & VEGETABLE DRAWER

FREEZER DRAWERS

FREEZING ZONE DRAWER

(Max cool zone)

Suggested to freeze fresh / cooked food.

ALARM TABLE

Alarm type Signal Cause Cure

Door open alarm Door open alarm indicator remains on,

the acoustical alarm is activated and the

Alarm Indicator blinks.

The Fridge or Freezer door has

remained open for more than

2 minutes.

Close the door or press the Stop

Alarm to mute the acoustical alarm.

Temperature alarm The Temperature display blinks (°C) and

the Alarm Indicator remains on.

Inside the Freezer the

temperature is not adequate.

Press the Stop Alarm button;

the acoustical alarm stops, the

Temperature Display (°C) blinks and

the Alarm Indicator remains on until

a temperature < -10°C is reached.

Long black-out alarm The Black Out Alarm icon remains on,

the Alarm indicator blinks.

Prolonged power failure,

able to cause the inside

temperature to increase to 0°C.

Press the Stop Alarm button; the

acoustical alarm stops.

Malfunction The letter “F” blinks on the display (°C). Product malfunction. Contact the After-sales Service.

* Available only on certain models

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Køleskab
Model:	W9C 941C OX
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	655 mm
Højde:	2013 mm
Vægt:	82000 g
Produktfarve:	Rustfrit stål
Lampe type:	LED
Indbygget skærm:	Ja
Strøm:	1.2 A
Ledningslængde:	2.45 m
Årligt energiforbrug:	158 kWh
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Tilsluttet belastning:	150 W
Støjniveau:	39 dB
Justerbare fødder:	Ja
Energieffektivitetsskala:	A til G
Støjemissionsklasse:	C
Energieffektivitetsklasse:	C
Vendbare døre:	Ja
Fryser, netto rumindhold:	98 L
Frysekapacitet:	15 kg/24t
Opbevaringstid under strømafbrydelse:	- t
Klimaklasse:	SN-T
Køleskab antal hylder/kurve:	4
Antal grøntsagsskuffer:	1
Køleskabsdøre:	4
Køleskab, netto rumindhold:	257 L
Total netto kapacitet:	355 L
No Frost (køleskab):	Ja
Køleskab indvendigt lys:	Ja
Stjernebedømmelse:	4*
Fryser position:	Bottom-placeret
Automatisk afrimning (fryser):	Ja
Hylder, materiale:	Glas
Ismaskine:	Ingen
Multi-Airflow-system (køleskab):	Ja
No Frost (fryser):	Ja
Hurtig frys funktion:	Ja
Fryser antal hylder/kurve:	3
Åben dør alarm:	Ja
Super Cool funktion:	Ja
Frisk zone, aflukke:	Ja
Automatisk afrimning (køleskab):	Ja
Temperaturalarm:	Ja
Minimal driftstemperatur:	10 °C
Maksimal driftstemperatur:	43 °C
Antal aftagelige hylder:	3
Fejlalarm:	Ja
Justerbare hylder:	Ja
Fejlindikation:	Ja
Ventilation:	Ja
