Side 1/8

Quick guide

PRODUCT DESCRIPTION

CONTROL PANEL

1. Control panel

2. Fan

3. Circular heating element

(not visible)

4. Shelf guides

(the level is indicated on the front

of the oven)

5. Door

6. Upper heating element/grill

7. Lamp

8. Identification plate

(do not remove)

9. Lower heating element

(not visible)

1. SELECTION KNOB

For switching the oven on by

selecting a function. Turn to the

position to switch the oven off.

2. ANALOG CLOCK

3. THERMOSTAT KNOB

Turn to select the desired

temperature.

4. LED THERMOSTAT /

PREHEATING

Switches on during the heating

process. Switches off once the

desired temperature is reached.

1 2 3 4

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

ACCESSORIES

WIRE SHELF DRIP TRAY* BAKING TRAY* SLIDING RUNNERS*

Use to cook food or as a

support for pans, cake tins

and other ovenproof items

of cookware

Use as an oven tray

for cooking meat, sh,

vegetables, focaccia, etc.

or position underneath the

wire shelf to collect cooking

juices.

Use for cooking all bread

and pastry products, but

also for roasts, sh en

papillotte, etc.

To facilitate inserting or

removing accessories.

TURNSPIT* * Available only on certain models.

The number and the type of accessories may vary depending on which model is

purchased.

Other accessories can be purchased separately from the After-sales Service.

For uniform roasting of large

pieces of meat and poultry.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf horizontally by sliding it across

the shelf guides, making sure that the side with the

raised edge is facing upwards.

Other accessories, such as the drip tray and the

baking tray, are inserted horizontally in the same way

as the wire shelf.

REMOVING AND REFITTING THE SHELF GUIDES

• To remove the shelf guides, lift the guides up and

then gently pull the lower part out of its seating: the

shelf guides can now be removed.

• To refit the shelf guides, first fit them back into their

upper seating. Keeping them held up, slide them

into the cooking compartment, then lower them into

position in the lower seating.

FITTING THE SLIDING RUNNERS IF PRESENT

Remove the shelf guides from the oven and remove

the protective plastic from the sliding runners.

Fasten the upper clip of the runner to the shelf guide

and slide it along as far as it will go. Lower the other

clip into position. To secure the guide, press the lower

portion of the clip firmly against the shelf guide. Make

sure that the runners can move freely. Repeat these

steps on the other shelf guide on the same level.

Please note: The sliding runners can be tted on any level.

USING THE TURNSPIT IF PRESENT

Push the skewer through the centre of the meat

(bound with string if poultry) and slide the meat onto

the skewer until it is positioned firmly on the fork and

cannot move. Push the second fork onto the skewer

and slide it on until it holds the meat firmly in place.

Tighten the fixing screw to secure it in position. Insert

the end into the recess provided in the oven’s cooking

compartment and rest the rounded part on the

relevant support.

Please note: To collect the cooking juices, position the drip

tray below and add 500 ml of water. To avoid burning

yourself when the skewer is hot, only handle it by the plastic

handle (which must be removed before cooking).

The use of this accessory is allowed only in combination with

the Turbogrill function.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Ovn
Model:	WTA C 8411 SC AN
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50-60 Hz
Bredde:	595 mm
Dybde:	564 mm
Højde:	595 mm
Produktfarve:	Anthracit
Kontroltype:	Dreje
Strøm:	13 A
Ledningslængde:	0.9 m
Placering af apparat:	Indbygget
Integreret ur:	Ja
Urtype:	Mekanisk
Installationsrum bredde:	- mm
Installationsrum dybde:	- mm
Installationsrum højde:	- mm
Selvrensende:	Ja
Kontrolposition:	Front
Energieffektivitetsklasse:	A
Rengøringstype:	Katalytisk
Ovn - størrelse:	Medium
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	73 L
Strøm for samtlige ovne:	2600 W
Antal ovne:	1
Ovn nettokapacitet:	73 L
Konventionel madlavning:	Ja
Energiforbrug (konventionel):	0.91 kWh
Energiforbrug (tvungen konvektion):	0.82 kWh
