Side 1/8

Page 1

IN-LINE BLOWER

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY

TO PERSONS, OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer. If

you have questions, contact the manufacturer or your distributor.

2. Before servicing or cleaning unit, switch power off at service panel

and lock the service disconnecting means to prevent power from

being switched on accidentally. When the service disconnecting

means cannot be locked, securely fasten a prominent warning

device, such as a tag, to the service panel.

3. Installation work and electrical wiring must be done by a qualified

person(s) in accordance with all applicable codes and standards,

including fire-rated construction codes and standards.

4. Sufficient air is needed for proper combustion and exhausting of

gases through the flue (chimney) of fuel burning equipment to pre-

vent backdrafting. Follow the heating equipment manufacturer’s

guideline and safety standards such as those published by the

National Fire Protection Association (NFPA), and the American

Society for Heating, Refrigeration and Air Conditioning Engineers

(ASHRAE), and the local code authorities.

5. When cutting or drilling into wall or ceiling, do not damage electri-

cal wiring and other hidden utilities.

6. Ducted fans must always be vented to the outdoors.

7. To reduce the risk of fire, use only steel ductwork.

8. If this unit is to be installed over a tub or shower, it must be marked

as appropriate for the application and be connected to a GFCI

(Ground Fault Interrupter) - protected branch circuit.

9. Never place a switch where it can be reached from a tub or

shower.

10. This unit must be grounded.

TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

1. Never leave surface units unattended at high settings. Boilovers

cause smoking and greasy spillovers that may ignite. Heat oils

slowly on low or medium settings.

2. Always turn hood ON when cooking at high heat or when flambe-

ing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef

Flambe’).

3. Clean ventilating fans frequently. Grease should not be allowed

to accumulate on fan or filter.

4. Use proper pan size. Always use cookware appropriate for the

size of the surface element.

TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT

OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING:*

1. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or

metal tray, then turn off the burner. BE CAREFUL TO PREVENT

BURNS. If the flames do not go out immediately, EVACUATE AND

CALL THE FIRE DEPARTMENT.

2. NEVER PICK UP A FLAMING PAN - You may be burned.

3. DO NOT USE WATER, including wet dishcloths or towels - violent

steam explosion will result.

READ AND SAVE THESE INSTRUCTIONS

Installer: Leave this manual with

the homeowner.

Homeowner: Use and Care

information on page 4.

FOR DOMESTIC COOKING ONLY

WARNING

4. Use an extinguisher ONLY if:

A. You know you have a Class ABC extinguisher and you already

know how to operate it.

B. The fire is small and contained in the area where it started.

C. The fire department is being called.

D. You can fight the fire with your back to an exit.

* Based on “Kitchen Fire Safety Tips” published by NFPA.

CAUTION

1. For general ventilating use only. Do not use to exhaust hazardous

or explosive materials and vapors.

2. To avoid motor bearing damage and noisy and/or unbalanced

impellers, keep drywall spray, construction dust, etc. off power

unit.

3. If ventilator is installed in an unconditioned space (such

as an attic): Surround the ventilator with thermal insulation - to

minimize possible condensation.

4. Please read specification label on product for further information

and requirements.

TABLE OF CONTENTS

This manual is divided into sections as follows:

 “TYPICAL INSTALLATION”

This section shows a common installation.

- Mounting (New Frame Construction)

- Mounting (Existing Frame Construction)

- Mounting Using Hanger Kit (included)

- Ducting (Horizontal blower discharge)

- Wiring

 “MOUNTING OPTIONS”

 “WIRING PLATE POSITION”

 “DUCTING OPTIONS”

- Blower Discharge Positions

- Ducting (Vertical blower discharge)

 “ATTACH POWER CORD TO HOOD”

 “USE AND CARE”

MODEL 808331

Page 2

10” ROUND

DUCT

CEILING JOIST

(24” centers

shown)

2 X 4 FRAMING

(wide side down)

MOUNTING

BRACKETS

(Attached to

opposite sides

of housing &

upside-down,

so housing is

flush with

finished ceiling)

DUCTING (Horizontal blower discharge)

Two ways to connect ductwork to a factory-shipped unit.

ROOF CAP

10”

ROUND

ELBOW

10”

ROUND

DUCT

WALL

CAP

MOUNTING

SCREW

4½” X 18½”

TO 10” ROUND

TRANSITION

4½” X 18½”

TO 10” ROUND

TRANSITION

10” ROUND

DUCT

4½” X 18½” TO 10”

ROUND TRANSITION

10”

ROUND

DUCT

MOUNTING USING HANGER KIT (included)

Blower factory-shipped in straight-through

discharge position.

TYPICAL INSTALLATION

Blower factory-shipped in straight-through

discharge position. IMPORTANT: Remove shipping tape from damper

Remove the shipping tape from the damper flap and make sure that

damper flap opens and closes freely inside the ductwork. Use duct

tape to make ductwork connections secure and air-tight.

ACCESS

PANEL

ACCESS

PANEL SCREW

GRILLE NUT

(Install into

square holes in

housing)

MOUNTING

BRACKET

10” ROUND

DUCT

(OUTLET)

10” ROUND

DUCT (INTAKE)

HANGER

KIT NUT &

WASHER

HANGER

KIT BOLT

& WASHER

HANGER

KIT

EYE-BOLT

HANGER

KIT CHAIN

TYPICAL INSTALLATION

MOUNTING (New Frame Construction)

CEILING

JOIST

(24” centers

shown)

10” ROUND DUCT

Factory-shipped unit installed in new construction.

MOUNTING

SCREW

Blower factory-shipped

in horizontal

discharge position.

Mounting brackets

factory-shipped in

position for ½” ceil-

ing material.

MOUNTING (Existing Frame Construction)

4½” X 18½”

TO 10” ROUND

TRANSITION

10” ROUND

DUCT

4½” X 18½”

TO 10” ROUND

TRANSITION

EXTENSION

SPRING

4½” X 18½”

TO 10”

ROUND

TRANSI-

TION
