Side 1/2

INSTRUCTIONS

For a detailed description of all the features and specications

of this product please visit our website.

Tested in New Zealand. Made with care in China

IN THE UNLIKELY EVENT OF YOUR TENT DEVELOPING A LEAK

2. Firstly check all valves are screwed in correctly.

3. AERO-FRAMEDeﬂate the faulty and unzip the ﬂysheet sleeve.

4. Remove the tube from the Outer by cutting the cable tie holding the zipper

ends together and unzip.

CAUTION: DO TO OPEN THESE ZIPS WHEN THE POLE IS INFLATED.

5. Remove the clear tube from the sleeve.

6. Partially inﬂate the tube and check for leaks (bubbles) in a basin of water.

7. Using the repair patch provided cover the hole and seal.

8. Partially inﬂate the tube and re insert into the pole sleeve. Zip together.

9. Connect the zipper ends with the replacement Cable ties provided.

INNER TENT ATTACHMENT

1. Lay out the inner inside the tent with

the door facing the center and the black

ﬂoor facing downwards.

2. Attach the buckles at the rear corners

of the tent and connect the toggles on

the inner through the corresponding rings

working your way from the rear to the

front.

3. The room can remain attached when

deﬂating the tent.

INSTRUCTIONS

12. It is recommended that guy ropes are

pegged out at all times and windows are

opened whenever possible to allow

adequate ventilation.

Insert pegs at a 45

angle

3. Unzip the triangle Valve Cover

on the Right hand side of the tent

and locate the AERO-FRAME

valves.

1. Clear your site making sure there are no sharp

objects where you are going to pitch your tent. Try

to get a site that is as ﬂat as possible. Spread tent

out, the PVC windows are located at the front.

2. Peg out the 4 peg points on the main body of the

tent as shown.

4. Remove the valves completely and re-screw in to ensure the valve is not

cross-threaded. Screw in ﬁrmly but do not over tighten. Open the valve caps.

5. The Pump features a double hose adapter

which allows two tubes to be inﬂated at the

same time.

Ensure the pump is conﬁgured as per the

following diagram.

Attach the of the hoses to the AERO-FRAME

valve inlets.

6. AERO-FRAME. Begin to inﬂate the center and left hand side

Have someone walk inside to help raise the frame during

inﬂation. Inﬂate to 7 PSI.

DO NOT INFLATE ABOVE 8PSI. THIS MAY CAUSE DAMAGE

TO THE POLES AND THE TENT.

7. Once inﬂated to the correct pressure, remove the pump hoses and securely attach

the valve caps. Close the Valve Cover.

8. Inﬂate the Rear and the Right

Hand Side Room AERO-FRAME

following the same procedure as

above, then remove the hose and

securely attach the valve caps.

Finally inﬂate the Front Awning

AERO-FRAME.

9. Peg out the remaining peg points around

the tent ensuring that the ﬂoor sits ﬂat. It is

easier to align the front door correctly with

the door closed.

10. Peg out the front and room anchor

webbings. These should sit at a 45

angle to

the ground.

DEFLATION

1. AERO-FRAME.Remove the valves from the Take care as poles will be under

pressure.

2. AERO-FRAME It may be necessary to remove some excess air from the

before rolling up your tent. This can be done by carefully walking down the

length of the tube towards the valve end.

PSI

INFLATE

DEFLATE

DOUBLE ADAPTER

PRESSURE GAUGE

PRESSURE RELEASE VALVE

Valve Cover

Peg

points

PSI

Peg

points

Room

Anchor

Webbings

Front

Anchor

Webbings

FRONT

Draft Vents

11. Peg out the 6 draft vents on either side

of the bedrooms. These can be pegged

closed during cooler weather conditions.

Valve Cover

Valve Covers

Produkt Specifikationer

Mærke:	Zempire
Kategori:	Telt
Model:	Aerodome III
