ZTE CORPORATION

NO. 55, Hi-tech Road South, ShenZhen, P.R.China

Postcode: 518057 Tel: +86-755-26779999

URL: http://www.zte.com.cn E-mail: mobile@zte.com.cn

ZTE MF60

Quick Start Guide

2 4 5 6 73 8 9

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or

utilized in any form or by any means, electronic or mechanical, including

photocopying and microfilm, without the prior written permission of ZTE

Corporation.

The manual is published by ZTE Corporation. We reserve the right to make

modications on print errors or update specications without prior notice.

Version No. : R1.0

Introduction

ZTE MF60 is a 3G/2G mobile hotspot device, working in GSM/GPRS/

EDGE/WCDMA/HSPA/HSPA+ network. The client devices could connect to

it via USB or Wi-Fi interface. The device supports data and SMS services,

enabling you to communicate anytime and anywhere.

This manual provides instructions on how to install and get started with the

product. For information about connection of services, please consult your

service provider.

Specication

Data Service

HSPA+: DL 21.6 Mbps,

UL 5.76 Mbps

WCDMA CS: 64 kbps UL/DL

WCDMA PS: 384 kbps UL/DL

Interface USB and Wi-Fi

Wi-Fi Standard 802.11b/g

Wi-Fi Security WEP/WPA/WPA2/WAPI

USB Version USB 2.0 HIGH SPEED

USB Interface Type Micro USB

Weight 86 g

Dimensions (W×H×D): 99.6 mm*54 mm*14.6 mm

microSD card Support up to 32 GB microSD card

Power Adapter 5 V/700 mA

Battery 1500 mAh

*Standby time 100 hours

*Working time 4 hours

Operate system

Windows 7, Windows Vista(32bit or 64bit),

Windows XP (SP2 or later)

MAC (10.4 or later)

Web Browser

IE (7.0 or later), Firefox (2.0 or later), Opera (10.0

or later), Safari (4.0 or later), Chrome (5.0 or

later)

Operating temperature 0 °C ~ +35 °C

Storage temperature -20 °C ~ +50 °C

Charging temperature 0 °C ~ +45 °C

Humidity 5%~ 95%

Notes:

microSD is a trademark of SD Card Association.

The device’s standby and working time are only for your reference, and

based on ideal working environment.

Getting to Know Your Device

The following gure shows the appearance of the device, it is only for your

reference. The actual device may be different.

Right Side Front Left Side Bottom

Interface and Buttons

1. Power Button Hold the Power button to switch on/off the device.

2. Memory card slot

(microSD card)

It is where you insert the memory card (microSD

card).

3. WPS Button

4. LED Screen

It indicates the network type, signal strength,

battery status, and Wi-Fi, etc.

5. External Antenna

Port

It is used to connect an external antenna to

enhance the signal strength.

6. Charger/USB port

• Charge your device.

• Connect the client to your device via USB cable.

Notes:

• Hold the WPS and Power buttons simultaneously until the LED

screen turns off, and then release the buttons. The device will restart

automatically and restore to the factory default settings.

• Please use the original external antenna if necessary.

LED Indicator

When the device is powered on, the following icons will appear on the LED

screen, with the corresponding indicates listed in the table below:

Icon Indication

Indicates the network signal strength.

Indicates the network type. 2G or 3G icon will appear on the

LED screen according to the network being connected.

Connect to the Internet automatically.

Connect to the Internet manually.

Roaming network indication.

New message received.

Indicates Wi-Fi status and the number of the connecting users.

Indicates the battery status.

Hardware Installation

Inserting SIM Card and Battery

1. Slide the back cover and remove it.

2. Insert the SIM card into the SIM card holder.

3. Insert the battery as shown with the contacts located against the metal

springs, and press the battery down into the case.

4. Slide the back cover and lock the cover in its place.

Inserting microSD Card

1. Pull the microSD cover out of the card slot.

Notes:

Do not pull the cover rudely, as it is connected with the device.

2. Insert the microSD card into the microSD slot. The following picture

shows the correct inserting direction. You will hear a click when the

microSD card locks in place.

3. Close the microSD cover.

Switching On/Off Your Device

Hold the Power button to switch on/off the device.

Notes:

The device is powered on when the LED screen lights up.

Charging Your Device

You can charge your device by using USB cable or adapter.

1. Insert the charger lead carefully.

2. The plug only ts one way. Do not use excessive force to insert the plug.

Working Mode

Your device supports three working modes. For the client, we only use PC or

laptop as the example in this document.

USB Mode: Connect to the device with the USB cable.

Wi-Fi Mode: Connect to the device via Wi-Fi.

Mixed Mode: Connect to the device with the above two connection methods.

Notes:

If you want to connect to the Internet by using Wi-Fi mode, make sure that

the client supports the Wi-Fi function.

The following picture is the application example. All of the client devices can

surf on the Internet at the same time.

Establish a connection between your device and

the client

Via USB Cable

1. Connect your device and the client with the USB cable.

2. Power on your device.

3. Follow the system prompts to complete the software installation.
