Side 1/2
E203 | Universelle Schutzschalter-Verriegelung |
Bedienungsanleitung
www.abus.com
V1 | G18
Technische Änderungen vorbehalten. Für Irrtümer und Druckfehler keine Haftung.
©
ABUS | D 58292 Wetter | Germany
2.
Stellen Sie den Schutzschalter in die
„Aus/Off“-Position.
Öffnen Sie die Abdeckung der
Verriegelung. Drehen Sie das Schraubrad
gegen den Uhrzeigersinn, um die
Verriegelung so weit wie nötig zu
öffnen.
WARNUNG:
DAS PRODUKT SOLLTE AUSSCHLIESSLICH VON GESCHULTEM PERSONAL VERWENDET WERDEN. DAS PRODUKT SOLLTE NUR FÜR DIE BESCHRIEBENEN ANWENDUNGEN
GENUTZT WERDEN. FOLGEN SIE DEN PRODUKTANWEISUNGEN FÜR DIE RICHTIGE ANWENDUNG. GESCHULTES PERSONAL SOLLTE DIE ANWENDUNG ÜBERPRÜFEN,
UM SICHERZUSTELLEN, DASS DAS PRODUKT SICHER ANGEBRACHT IST. NICHTEINHALTEN DER PRODUKTANWEISUNGEN UND WARNUNGEN KANN ZU SCHWEREN
VERLETZUNGEN ODER ZUM TODE FÜHREN.
Weitere Hinweise und entsprechende Anwendungsfilme zu jeder Wartungsschutz-Verriegelung finden Sie unter
http://www.abus.com/ger/Objektsicherheit/Arbeitsschutz.
E203 | Universal Circuit Breaker Lockout Device |
User Manual
Universelle Schutzschalter-Verriegelung


1.
4.
Positionieren Sie die Schutzschalter-
Verriegelung so an dem Schutzschalter,
dass die Öffnung die Wippe umschließt
und die Verriegelung möglichst eng am
Schutzschalter anliegt.
Drehen Sie das Schraubrad im Uhr-
zeigersinn, um die Verriegelung auf der
Wippe zu befestigen.
Bitte zwingend beachten:
Stellen Sie sicher, dass sich die Schutz-
schalter-Wippe nicht zurück in die

Schutzschalter-Wippe wird sich weiter-
hin etwas bewegen lassen, aber sie darf
nicht die „An/On“-Position erreichen.
Ist dies der Fall, ist erforderlich, dass Sie
die Verriegelung neu anbringen.
3.
6.
Sitzt die Verriegelung fest und sicher
auf dem Schutzschalter und verhindert
die „An/On“-Position, schließen Sie die
Abdeckung.
Führen Sie ein Vorhangschloss durch die vorgesehene vertikale Öffnung. Alternativ
können Sie ein entsprechendes Schloss mit flexiblem Seil durch die horizontal
verlaufende Öffnung führen, um mehrere Verriegelungen in Reihe zu sichern.
5.
www.abus.com
V1 | G18
Subject to technical alterations. No liability for mistakes and printing errors.
©
ABUS | D 58292 Wetter | Germany
2.
Application:
Set the circuit breaker to the „Off“
position.
Open the cover of the lockout device.
Turn the hand know screw counter-
clockwise to open the lockout device as
far as necessary.
WARNING:
PRODUCT SHOULD ONLY BE USED BY PERSONNEL PROPERLY TRAINED IN LOCKOUT PROCEDURES. PRODUCT SHOULD ONLY BE USED ON THE APPROPRIATE

ENSURE THAT PRODUCT IS SECURE AND EQUIPMENT WILL NOT OPERATE. FAILURE TO FOLLOW PRODUCT INSTRUCTIONS AND WARNINGS MAY RESULT IN
SERIOUS BODILY INURY OR DEATH.
You will find additional notes and corresponding application videos to every lockout device following the link:
http://www.abus.com/eng/Service/Videos/Industrial-safety
Universal circuit breaker lockout device


1.
4.
Position the circuit breaker lockout
device on the circuit breaker so that the
opening encloses the rocker and the
device abuts against the circuit breaker.
Turn the screw wheel clockwise to
secure the device at the circuit breaker
rocker.
Please note the following:
Make sure the circuit breaker rocker
cannot be switched back to the “On“
position. The circuit breaker rocker can
still be moved a little, but must not
reach the “On“ position. If it can do so,
you must re-attach the device.
3.
6.
If the device sits tightly and securely
on the circuit breaker and prevents the
“On” position from being set, put the
cover over the screw.
Insert one padlock through the vertical opening provided. Alternatively, you can
insert a corresponding lock with a flexible cable through the horizontal holes
provided in order to secure more than one device in-line.
5.
