Side 1/3

English

Acer LCD Monitor Quick Start Guide (QSG)

Important safety instructions

Please read the following instructions carefully.

1. To clean the LCD monitor screen:

• Turn off the LCD monitor and unplug the power cord.

• Spray a non-solvent cleaning solution onto a rag and clean the screen gently.

2. Do not place the LCD monitor near a window. Exposing the monitor to rain, moisture or sunlight can severely damage it.

3. Do not apply pressure to the LCD screen. Excessive pressure may cause permanent damage to the display.

4. Do not remove the cover or attempt to service this unit yourself. An authorized technician should perform servicing of any

nature.

5. Store the LCD monitor in a room with a temperature of -20° to 60° C (-4° to140° F). Storing the LCD monitor outside this

range may result in permanent damage.

6. Immediately unplug your monitor and call an authorized technician if any of the following circumstances occur:

• Monitor-to-PC signal cable is frayed or damaged.

• Liquid spills onto the LCD monitor or the monitor is exposed to rain.

• The LCD monitor or case is damaged.

Attaching the monitor to the base

1. Remove the monitor from the packaging.

2. Attach the footstand to the base. (for selected models).

3. Turn clockwise to lock. Ensure that the base in locked onto the stand. (for selected models)

4. Secure the base to the stand by turning the screw using the intergrated tab or a suitable coin. (for selected models)

Connecting your monitor to a computer

1. Turn off your computer and unplug your computer's power cord.

2. Connect the signal cable to the VGA (optional) and/or DVI-D

(optional) and/or HDMI (optional) input socket of the monitor, and

the VGA (optional) and/or DVI-D (optional) and/or HDMI (optional)

output socket of the graphics card on the computer. Then tighten the

thumbscrews on the signal cable connector.

3. Optional: Connect the audio input socket (AUDIO IN) of the LCD

monitor and the line-out port on the computer with the audio cable.

4. Insert the monitor power cable into the power port at the back of the

monitor.

5. Plug the power cords of your computer and your monitor into a

nearby electrical outlet.

Note: Audio output is only for audio output model. Please check user manual for more instruction.

External controls

1&2 Power button Turns the monitor on/off. Blue indicates power on. Amber indicates standby/

power saving mode.

3&4 </> Minus / Plus If the OSD is active, press the or buttons to toggle between the OSD Minus Plus

options. If the OSD is inactive, press the or buttons to adjust the Minus Plus

volume. (Optional).

5 Menu OSD functions Press to view the OSD. Press again to enter a selection in the OSD.

6 Auto Auto If the OSD is active, press Auto to exit the OSD. Once the OSD is inactive, press

Auto and the monitor will automatically optimize the display position, focus, and

clock of your display.

7 Empowering Key Press this button to select scenario mode.

English

Note: Acer monitor is purposed for video and visual display of information obtained from electronic

devices.

Regulations and safety notices

FCC notices

This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC

rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can

be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the device and receiver.

• Connect the device into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

Notice: Shielded cables

All connections to other computing devices must be made using shielded cables to maintain compliance with EMC regulations.

Notice: Peripheral devices

Only peripherals (input/output devices, terminals, printers, etc.) certied to comply with the Class B limits may be attached to

this equipment. Operation with non-certied peripherals is likely to result in interference to radio and TV reception.

Caution

Changes or modications not expressly approved by the manufacturer could void the user authority, which is granted by the

Federal Communications Commission, to operate this product.

In order to prevent damage to the monitor, do not lift the monitor by its base.

Operation conditions

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept any interference received, including interference that may

cause undesired operation.

Notice: Canadian users

CAN ICES-3(B)/NMB-3(B)

Produkt Specifikationer

Mærke:	Acer
Kategori:	Skærm
Model:	KA270HD
Tænd-/slukkontakt:	Ja
Brugervejledning:	Ja
Produktfarve:	Sort
Skærm diagonal:	27 "
Skærmopløsning:	1920 x 1080 pixel
Berøringsskærm:	Ingen
HD-type:	Fuld HD
Skærmteknologi:	LED
Naturligt aspektforhold:	16:9
Responstid:	4 ms
Synsvinkel, horisontal:	178 °
Synsvinkel, vertikal:	178 °
Skærm form:	Flad
3D:	Ingen
Indbyggede højttaler(e):	Ingen
Antal HDMI-porte:	1
HDCP:	Ja
DVI-port:	Ja
VESA montering:	Ja
Panel montering grænseflade:	100 x 100 mm
Strømforbrug (standby):	- W
Strømforbrug (typisk):	32 W
Bredde (uden stativ):	567 mm
Dybde (uden stativ):	192 mm
Højde (uden stativ):	435 mm
Vægt (uden stativ):	3740 g
Skærm:	LED
Strømforbrug (slukket):	0.24 W
Understøttede grafikopløsninger:	1920 x 1080 (HD 1080)
Energiforbrug (SDR) pr. 1000 timer:	26 kWh
Energieffektivitetsklasse (SDR):	F
Energiforbrug (HDR) pr. 1000 timer:	- kWh
Energieffektivitetsskala:	A til G
Harmoniseret systemkode (HS):	85285210
Indbygget kamera:	Ingen
Paneltype:	VA
Slot til kabellås:	Ingen
Billedformat:	16:9
Vis antal farver:	16,78 millioner farver
Farve:	Sort
Pixeltæthed:	82 ppi
Maksimal opdateringshastighed:	60 Hz
Skærmoverflade:	Mat
Skærmens lysstyrke (typisk):	300 cd/m²
Kontrastforhold (typisk):	3000:1
Kontrastforhold (dynamisk):	100000000:1
Pixel pitch:	0.311 x 0.311 mm
Indbygget USB-hub:	Ingen
Antal VGA-porte (D-sub):	1
Højdejustering:	Ingen
Hældningsvinkelområde:	-5 - 35 °
TV-tuner, integreret:	Ingen
Hældningsindstilling:	Ja
Tynd klient installeret:	Ingen
Kode for europæisk produktregister for energimærkning (EPREL):	399743
