Acer LCD Monitor Quick Start Guide (QSG)

Important safety instructions

Please read the following instructions carefully.

1. To clean the LCD monitor screen:

• Turn off the LCD monitor and unplug the power cord.

• Spray a non-solvent cleaning solution onto a rag and clean the screen gently.

2. Do not place the LCD monitor near a window. Exposing the monitor to rain, moisture or sunlight can severely damage

it.

3. Do not apply pressure to the LCD screen. Excessive pressure may cause permanent damage to the display.

4. Do not remove the cover or attempt to service this unit yourself. An authorized technician should perform servicing of

any nature.

5. Store the LCD monitor in a room with a temperature of -20° to 60° C (-4° to140° F). Storing the LCD monitor outside

this range may result in permanent damage.

6. Immediately unplug your monitor and call an authorized technician if any of the following circumstances occur:

• Monitor-to-PC signal cable is frayed or damaged.

• Liquid spills onto the LCD monitor or the monitor is exposed to rain.

• The LCD monitor or case is damaged.

Attaching the monitor to the base

1. Remove the monitor from the packaging.

2. Attach the footstand to the base. (for selected models).

3. Turn clockwise to lock. Ensure that the base in locked onto the stand. (for selected models)

4. Secure the base to the stand by turning the screw using the intergrated tab or a suitable coin. (for selected models)

Connecting your monitor to a computer

1. Turn off your computer and unplug your computer's power cord.

2. Connect the signal cable to the VGA (optional) and/or HDMI

(optional) input socket of the monitor, and the VGA (optional) and/or

HDMI (optional) output socket of the graphics card on the computer.

Then tighten the thumbscrews on the signal cable connector.

3. Optional: Connect the audio input socket (AUDIO IN) of the LCD

monitor and the line-out port on the computer with the audio cable.

4. Insert the monitor power cable into the power port at the back of the

monitor.

5. Plug the power cords of your computer and your monitor into a

nearby electrical outlet.

Note: Audio output is only for audio output model. Please check user manual for more instruction.

FreeSync (HDMI only):

It can allow a FreeSync supported graphics source to dynamically adjust display refresh rate based on typical content

frameratesforpowerefcient,virtuallystutterfreeandlow-latencydisplayupdate.

External controls

1&2 Power button Turns the monitor on/off.Blue indicates power on. Amber indicates standby/ power saving

mode.

3 Function key

a. Press to view Main page.Press again to enter next function in the Function Menu.

b. When the Function Menu is active, press this key selected or move to the next function.

4 Function key

Input

/ /

a. Press to view Main page.Press again to enter Input select function.

b. When the Function Menu is active, press this button selected or move to the previous

function.

English

5 Function key

a. Press to view Main page.Press again to enter Volume adjustment function.

b. When the Function Menu is active, this button will enter a selection in the OSD.

6 Function key

a. Press to view Main page. Press again to enter brightness adjustment function.

b. When the Function Menu is active. Press to return previous Menu or exit current Menu..

7 Function key

a. When the Main page is active,Press to trigger the Game mode control

b. When the Function Menu is active, press to exit current Menu.

For displays with glossy bezels the user should consider the placement of the display as the bezel cause

disturbingreectionsfromsurroundinglightandbrightsurfaces.

Regulations and safety notices

FCC notices

This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC

rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which

can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the device and receiver.

• Connect the device into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

CE declaration of conformity

Hereby, Acer Inc., declares that this LCD monitor is in compliance with the essential requirements and other relevant

provisions of EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU, and RoHS Directive 2011/65/EU and Directive

2009/125/EC with regard to establishing a framework for the setting of ecodesign requirements for energy-related product.

Notice: Shielded cables

All connections to other computing devices must be made using shielded cables to maintain compliance with EMC

regulations.

Notice: Peripheral devices

Onlyperipherals(input/outputdevices,terminals,printers,etc.)certiedtocomplywiththeClassBlimitsmaybeattached

tothisequipment.Operationwithnon-certiedperipheralsislikelytoresultininterferencetoradioandTVreception.

Caution

Changesormodicationsnotexpresslyapprovedbythemanufacturercouldvoidtheuserauthority,whichisgrantedby

the Federal Communications Commission, to operate this product.

In order to prevent damage to the monitor, do not lift the monitor by its base.

Operation conditions

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device

may not cause harmful interference, and (2) this device must accept any interference received, including interference that

may cause undesired operation.

Notice: Canadian users

CAN ICES-3(B)/NMB-3(B)

Disposal of waste equipment by user in private household in the European Union

This symbol on the product or on its packaging indicates that this product must not be disposed of

with your other household waste. Instead, it is your responsibility to dispose of your waste equipment

by handing it over to a designated collection point for the recycling of waste electrical and electronic

equipment. The separate collection and recycling of your waste equipment at the time of disposal

will help to conserve natural resources and ensure that it is recycled in a manner that protects

human health and the environment. For more information about where you can drop off your waste

equipmentforrecycling,pleasecontactyourlocalcityofce,yourhouseholdwastedisposalservice

or the shop where you purchased the product.

Produkt Specifikationer

Mærke:	Acer
Kategori:	Skærm
Model:	KG221QA
