Side 1/60
Classic Series 2
Split Ducted Unit
Installation and Commissioning Guide - Outdoor
Model Numbers
Classic Condenser Add On C
CRA100S
CRA130S
CRA130T
CRA150S
CRA150T
CRA170S
CRA170T
CRA200T
CRA230T
CCA130S
CCA150S
CCA170S
CCA170T
CCA200T
CCA230T
IMPORTANT NOTE:
Please read this manual carefully before installing or operating your air conditioning unit.
That’s better. That’s Actron.
Installation and Commissioning Guide - Split Ducted Outdoor Unit
Doc. No.0525-073 Ver. 3 200129
Installation and Commissioning Guide Split Ducted Outdoor Units
02
Table of Contents
01. Inspection .................................................................................................................................4
. Product Inspections
. Codes, Regulations and Standards
02. General Information 4 ..................................................................................................................
03. Safety Instructions 5 ....................................................................................................................
04. Installation Information 6 ............................................................................................................
05. Operation Manual Access 8 ..........................................................................................................
. Download from website
. Near Filed Communication (NFC) Tag
06. Components Overview 10 .............................................................................................................
07. Control Panel 11 ...........................................................................................................................
. Single Phase (-kW) 
. Three Phase (- kW) 
. Three Phase - Soft Starter Option (- kW) 
08. Unit Dimensions and Clearances ............................................................................................... 13
. CRAS 
. CRAS / CRAT / CCAS 
. CRAS / CRAT / CCAS 
. CRAS / CRAT CCAS / CCAT 
. CRAT / CCAT 
. CRAT / CCAT 
09. Unit Lifting Procedure ..............................................................................................................19
10. Outdoor Unit Preparation 21 .........................................................................................................
11. Field Pipe Connection .............................................................................................................. 22
. Piping and Brazing 
. Pressure Testing 
. Evacuation Procedure (Triple Evacuation) 
12. Electrical Installation 27 ................................................................................................................
. Split Unit Electrical Connection 
13. Maximum Cable Lengths 30 .........................................................................................................
. Wiring Configuration : Recommended 
. Wiring Configuration : Alternate 
14. Cable Length - Zoning ..............................................................................................................32
15. Wiring Connections ..................................................................................................................33
. LR Wall Control Wiring Connections 
. LM-RS- Optional Sensor Wiring Connections 
. AERSS Optional Duct Sensor Wiring Connections 
. Demand Response Management 
16. Control Source Configuration (CtrS) 35 .........................................................................................
17. Third Party Control Input (InZone Board and/or Outdoor Board) 36 .............................................
. Third Party Control Input (Single Speed Fan Operation) 
. Third Party Control Input (Variable Speed Fan Operation) 
. Run and Fault Indication Output (Outdoor Board) 
. Remote On/Off 
