Tablet PC
AIM- S Series77
Startup Manual
AIM- S Appearance77
Up: AIM-77S (MSR SKU) Down: AIM-77S (non-MSR SKU)
Left: Front View Right: Rear View
For more information on this and other
Advantech products, please visit our website
at:
http://www.advantech.com
For technical support and service, please visit
our support website at:
http://support.advantech.com
This manual is for AIM- S Series77
First Edition
March 2025
Description of Parts
A: Power Indicator & Hall Sensor
B: Ambient Light Sensor
C: 5MP Front Camera (FF)
D: Barcode Scanner (optional)
E: microSD Slot
F: USB Type C (USB3.0 & 45W 3.0)PD
G: Audio Combo Jack (CTIA)
H: Microphone
I: Barcode Trigger Button
J: 8MP Rear Camera (AF)
K: Power Button
L: Volume Key (up & down)
M: NFC (optional)
N: MSR (optional)
O: Pogo pin for Peripherals
P: Speaker
Easy Setup
Power Computeron
1. Model: AIM- S Rating77
From Type C: Vdc / 3 A15
From Pogo Pin (Docking): 12 Vdc / 3.75A
2. This product is intended to be supplied by a UL
Listed Power Adapter (FSP / FSP045-A2BR3,
15Vdc/3A output, Tmax: 40°C, Altitude: 2000
meters) for model AIM- S. Please contact 77
Advantech for further information and assistance.
3. When you power on the AIM-77S for the first time,
please charge the computer's embedded battery
via the Type C adapter or Docking to release the
battery shipping mode. Then push the Power
button K(“ ” on description of parts.) for 2~3 seconds
to start the computer.
4. The product is equipped with a 10.1 Capacitive ”
Touch Panel. Use finger to touch the Active Area to
operate the computer.
5. The product is equipped with two LED indicator for
power status and barcode scanning status.
Power LED:
a) The RED LED blinks when internal battery
capacity is below 10% to warn the user to
charge.
b) The Blue LED lights up when internal battery is
being charged.
c) The Green LED lights up when internal battery
is full.
d) When the computer is turned on and the battery
capacity is above 81%, after the user inserts the
Type C Power adapter to charge, the green
LED lights up and remains in the non-charging
state.
e) When the computer is turned on and the battery
capacity is above 81%, after the user put the
computer on thermal printer docking or magnet
cradle to charge, the green LED lights up and
remains in the non-charging state. Then in
docking mode, the green LED light will turn off
after 5 minutes.
Barcode LED: When built- barcode scan in
successfully, BCR LED will flash red color.
6. When the computer is running, pressing and
holding the power button for 1 second will turn off
the LCD backlight to save power. Pressing the
power button again will re-enable the backlight;
holding the power button for 10 seconds while the
computer is running will reset(reboot) the system.
7. Environment:
◼ Operating Temperature: -0°C ~ +40°C
◼ Humidity: 90% at 40°C (non-condensing)
◼ Storage/Transportation Temperature:
-10°C ~ +60°C.
If you encounter any system failure or serious incident
related to the equipment, please report it to the
manufacturer or local agent.
Battery Caution
CAUTION!
AIM-77S is designed with built-in non- placeable re
battery. Please do not replace the battery by yourself.
Please contact a qualied technician or your retailer for
help. There is a danger of explosion if battery is
incorrectly replaced. Replace only with same or
equivalent type recommended by the manufacturer
(1) Leaving AIM-77S and its Battery in an extremely high
temperature surrounding environment that can result in
an EXPLOSION or the leakage of ammable liquid or
gase s.
(2) If AIM-77S and its Battery are subject to extremely
low air pressure, may result in explosion or leakage of it
ammable liquids or gases.
Only qualied personnel should replace the battery.
Please consult local authorities for disposal instructions.
Do not dispose of batteries in re.
Battery Charging Notice
It is important to consider the environment temperature
whenever you are charging the - battery pack. The Li ion
process is more ecient at normal room temperature
(22°C ~28 ) or slightly cooler. It is essential that you °C
charge batteries within the stated range of 0°C to 40°C.
Charging batteries outside of the specied range could
damage the batteries and shorten their charging life
cycle.
Storage and Safety Notice
the battery capacity may be depleted due to the
accumulation of internal resistance. If this happens,
Must be recharged before use .
Lithium-ion batteries can be stored in an environment of
- ~ + , but if they are close to the upper or 10°C 60°C
lower limit of this temperature range, the power will be
consumed faster.
It is recommended to store AIM- S within normal room 77
temperature ranges.
Wireless Network Settings
1. While using Wi-Fi 6GHz bands, please connect to
your router with AX or AX mixed mode.
2. When connecting a Bluetooth device, please avoid
interference from other 2.4GHz devices.
Image Update
1. The shipping image can be updated by OTA via
DeviceOn vantech MDM tool) or by USB drive (Ad
or by anther PC.
2. Calibration: It is suggested to be carried out by
manufacturer authorized and trained personnel.
