Side 1/5
78OEW100201A
Physical Dimensions (mm)
I n s t a l l a t i o n M a n u a l
A R E S - 5 2 2 1 O
282
880
730.6
123-328.8
226.2
124
345
486
285
51
44
64
207
8-217 8-217449
668
884.3
213
255
730.6
2
7.5
13
146
201
216
231
261
2
Ø7
100
100
Ø4.5
75
75
5.5 kg
12.13 lb
≤ 27″
2-8 kg
4.41-17.64 lb
≤ 27″
6-12 kg
13.23-26.46 lb
Heavy Duty
≤8.5 cm
Keyboard Tray
2.5 kg
5.51 lb
1
Step
2
Step
4
Step
Installation Process
Masonry Walls or Cement Walls
Remove the cover.
Note: For a brick-piled masonry wall or cement wall, holes of
10mm diameter and 55mm depth should be drilled.
5 mm
N
C
D
3
Step
5 mm
N
E
I
N
J
N
4-5mm
Do not tighten the screws.
1 2 3
55mm (2.17 )
Ø10mm
25
64
( )
Drill a hole at the marked position
with an electric drill and drill bit.
4
5
Remove the cover.
Affix the wall mount bracket (F)
onto the wall with lag bolts (B).
Stud
Stud
55mm (2.17)
Ø4.5mm
3
16
( )
˝
8 mm
8 mm
1 2
3
Stud Walls
Note: For a stud wall, holes of 4.5mm diameter and
55mm depth should be drilled.
Affix the wall mount bracket (F)
onto the wall with lag bolts (B).
F
1
2
F
1
2
B
B
A
