Side 1/2

EKI 2428G- -4FA

Rackmount Ummanaged Redundant Industrial Switch

Specifications

The EKI 2428G is an unmanaged switch with 24 -

Gigabit ports and 4 Gigabit SFP ports that can

provide users with abundant ports to connect

many devices. It is designed for rack-mount

installation, and suitable for edge to core

networks.

Before installation, please make sure that you

have received the following:

•

1 x EKI- - 2428G 4FA Rackmount Ummanaged

Switch

•

1 x Startup manual

If anything is missing or damaged, contact your

distributor or sales representative immediately.

General

•

Compatibility: IEEE 802.3, 802.3u, 802.3x,

802.3ab, 802.3z

• LAN: 10/100/1000 Base-TX

•

SFP: Up to 110 km (depends on SFP)

•

Ethernet RJ- m45 Distance: Up to 100

•

Connectors:

24 x 10/100/1000Base- -T/TX RJ 45

4 x SFP(mini GBIC) port-

•

Power Requirements:

100~240V single AC power input

•

Power Consumption: 18 W

•

Dimensions (W x H x D): 442 x 44 x 211.1 mm

•

Enclosure: Metal shell with solid mounting kits

•

Operating Temperature: 0 ~ 55°C (32 ~ 131°F)

•

Storage Temperature: - - 20 ~ 70°C ( 4 ~158°F)

•

Operating Humidity: 10 ~ 95% (non condensing)-

•

Storage Humidity: 10 ~ 95% (non- )condensing

•

EMC: CE FCC Class A

•

Warranty: 5years

For more detailed information, please refer to the

full manual which can be found on the Advan-

tech’s website.

User Manual

Notes

For more information on this and other Advantech

products, please visit our websites at:

http://www.advantech.com/products

For technical support and service:

http://www.advantech.com/support/

This startup manual is for EKI- -2428G 4FA

Part No:

1st Edition

Dec 2017

Packing List

Overview

STARTUP

MANUAL

1 Startup Manual

Warning: This is a Class A product. In domestic environment this product may cause radio interference in which case the user

may be required to take adequate measures.

1. Read these safety instructions carefully.

2. Keep this user manual for later reference.

3. Disconnect this equipment from any AC outlet before

cleaning. Use damp cloth. Do not use liquid or spray

detergents for cleaning.

4. For plug in equipment, the power outlet socke must -

be located near the equip ment and must be easily -

accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during

installation. Dropping it or letting it fall may cause

damage.

7. The openings on the enclosure are fo air convection.

Protect the equipment from overheating. DO NOT

COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct

before connecting the equipment to the power outlet.

9. Position the power cord so that people cannot step

on it. Do not place anything over the power cord.

10. All cautions and warning on the equipment should

be noted.

11. the equipment If is a not used for long time, disconnect

it from the power source to avoid damage by transient

over voltage.

12. Never pour any liquid into an opening. This may cause

fire or electrical shock.

13. Never open the equipment. For safety reasons, the

equipment should be opened only by qualified

service personnel.

1. one Position one bracket to align with the holes on

side of the switch and secure it with the bracket

screws. Then attach the remaining bracket to the

other side of the Switch.

2. After attaching the mounting brackets, position the

EKI- -2428G 4FA Ummanaged Switch in the rack by

lining up the holes brackets the appropriate in the with

holes on the rack. Secure the Switch to the rack by a

screw driver with the rack-mounting screws.

14. If one of the following situations arises, get the equipment

checked by service personnel:

•The power cord or plug is damaged.

•Liquid has peretrated into the equipment.

•The equipment has been exposed to moisture.

•The equipment does not work well, or you cannot

get it to work according to the user manual.

•The equipmen ha been droppe an damaged. t s d d

•The equipment has obvious signs of breakage.

15. Do NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

WHERE THE STORAGE TEMPERATURE MAY GO

BELOW - (-20°C 4°F) OR ABOVE 70°C (158°F) THIS

COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT

SHOULD BE IN A CONTROLLED ENVIRONMENT.

Startup Manual 2

Rack Mounting Safety Instructions

Overview
