PCE-3032/PCE-4132 Startup Manual 1

Before you begin installing your card, please ensure the

following items have been shipped:

1. 1 x PCE-3032/PCE-4132 PICMG 1.3 System Host

Board

2. 1 x PCE-3032/PCE-4132 Startup Manual

3. 1 x Serial ATA HDD data cable

4. 1 x 2-port COM cable kit

5. 1 x 4-port USB 2.0 cable kit

6. 1 x Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

PCE-3032/PCE-4132 LGA1200 Intel

Xeon

, Core™

i9/i7/i5/i3/Celeron

/Pentium

PICMG 1.3 Half-size

System Host Board with DDR4/Dual GbE LAN

Startup Manual

General

• CPU:LGA1200-socket Core™ i9/i7/i5/i3, Pentium

and

Xeon

W series processors

Note:Only PCE-4132 supports Intel

Xeon

processors.

• L2Cache: Please refer to CPU specication for detailed

information.

• BIOS: AMI SPI BIOS 256Mb (PCE-4132)/128Mb (PCE-

3032)

• SystemChipset:Intel

W480E (PCE-4132)/Intel®

H420E (PCE-3032)

• Systemmemory:

- PCE-4132: Up to 64 GB in 2 x 260-pin SODIMM sock-

ets. Supports dual-channel DDR4 2666/2933 SDRAM

with or without ECC function.

- PCE-3032: Up to 64 GB in 2 x 260-pin SODIMM sock-

ets. Supports dual-channel DDR4 2666/2933 SDRAM

without ECC function.

• SATAharddiskdriveinterface:PCE-3032 supports 3

x SATA 3.0 ports without RAID function, and PCE-4132

supports 4 x SATA 3.0 ports with SW RAID 0,1,5,10.

• Serialports:2 x RS-232 serial ports

• Watchdogtimer:Programmable 1~255 sec

• USB:4 x USB 3.0 and 6 x USB 2.0

• GPIO:1 x programmable 8-bit GPIO pin-header

Display

• Chipset:Intel

HD Graphics embedded in the processor.

EthernetInterface

• Chipset supports:

LAN 1: Intel

I210AT (PCE-3032) and I210AT (PCE-

4132).

LAN 2: Intel

I210AT (PCE-3032) and I210AT (PCE-

4132).

• Connection: 2 on-board RJ-45 connectors with LED

indicators.

MechanicalandEnvironmental

• Dimensions: (L x W): 172.6 x 126.3 mm/6.7 x 4.97 in

• Power supply voltage: +3.3 V, +5 V, +12 V, 5 VSB

• Power requirements:

CPU:Intel®i7-10700ECPU@2.90GHz,DDR:4GBSO-

DDR4-2666*2

Voltage +V12 +V5_SB +V3.3 +V5

Current 4.36A 0.17A 1.8A 2.13A

• Operating temperature: 0 ~ 60 °C / 32 ~ 140 °F (depend-

ing on CPU)

• Weight: 0.33 kg / 72 lb (weight of board)

SpecicationsPackingList

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

https://www.advantech.com/support

This manual is for the PCE-3032/PCE-4132 Series Rev. A2.

PCE-3032: PCE-4132:

Part No. 2041303201

Printed in China

2nd Edition

October 2022

2 PCE-3032/PCE-4132 Startup Manual

The board has a number of jumpers that allow you to con-

gure your system to suit your application. The table below

lists the function of each of the jumpers and connectors.

Connectors

Label Function

LAN1

PCE-3032: Intel® I210AT

PCE-4132: Intel® I210AT

LAN2

PCE-3032: Intel® I210AT

PCE-4132: Intel® I210AT

VGA VGA connector

COM12 Box header for RS-232*2

FP1

HDD LED, power LED, SNMP SM_Bus,

reset, power on/o󰀨

JCASE1 Case open

CPUFAN1 CPU FAN connector (4-pin)

LANLED1 LAN1/2 LED connector

HDAUD1 HD audio extension module connector

USB3C1 USB 3.2 port 1

USB3C2 USB 3.2 port 2

USB3H1 USB 3.2 port 3, 4

USB2A1 USB 2.0 port 1

USB2C1 USB 2.0 port 2

USB2H1 USB 2.0 port 3, 4

USB2H2

USB 2.0 port 5, 6

SATA0 Serial ATA0 (SATA 3.0)

SATA1 Serial ATA1 (SATA 3.0)

SATA2 Serial ATA2 (SATA 3.0)

SATA3 Serial ATA3 (SATA 3.0, PCE-4132 only)

CPU CPU Socket

DIMMA1 Memory connector channel A

DIMMB1 Memory connector channel B

GPIO1 GPIO pin header

LPC2 Low pin count module expansion pin-header

PWR1 12 V, 5 V power connector

DP2

DVI/DP via optional cable

DP1

Display pin header to stack board (Display

type depends on optional stack board)

EXPCIE1 Mini PCIe pin header to stack board

Jumpers

Label Function

JCMOS1 CMOS clear

JWDT1+JOBS1

Hardware monitor alarm+watchdog

timer output selection

JME1 Enable ME



JCMOS1:ClearCMOS

ClosedPins Result

1-2 Keep CMOS (Default)

2-3 Clear CMOS

JOBS1+JWDT1:Hardwaremonitoralarm+watchdog

timeroutputselection 

Function JumperSettings

2-3 Enable watchdog timer (Default)

4-5

Enable Hardware monitor alarm

(Default)

JME1:EnableME

ClosedPins Result

1-2

Enable ME

(Default)

2-3 Disable ME

1 2 3 4 5

1 2 3



JumpersandConnectors



JumpersandConnectors



(Cont.)
