PCE-5B12-00 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• PCE-5B12-00A1E startup manual 1st ED
• M4*6*0.7 Round Screws P/N: 1939000410
• 2-year Quality Warranty Card P/N: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
• PICMG 1.3 slots: PCE-5B12-00A1E supports PCE-5000
and 7000 series CPU boards
• PCIe slots: 10 PCIe x16 and 1 PCIe p1-x4
*If you have any questions about memory, I/O or IRQ
resource limitations, please contact Advantech locally or
• PCIe switch: One 5 ports/48 lanes and two 24 ports/96
lane PCIe Gen2 switch reduce data latency
• USB (2.0) ports: 4 Universal Serial Bus ports as pin
Mechanical and Environment
• Dimensions: 327.66 x 417 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V,
• Power requirements: Refer to CPU board, add-on card
& peripheral documentation
• Operating temperature: 0 ~ 60° C (Depending on sys-
• Weight: 1.1 kg (weight of board)
PCE-5B12-00A1E Backplane: 12-slot BP for 20-slot
chassis, 10 PCIe x16, and 1 PCIe x4
The backplane has a number of connectors and jumpers
that allow you to configure your system to suit your ap-
plication. The table below lists the function of each of the
SHBA1 ~ SHBD1 PICMG 1.3 CPU board slot
PPCIEX4_1 PCIe p1-x4 with PCIe x16 slot
P1PCIEX16_1~5 PCIe x16 slot
P2PCIEX16_1~5 PCIe x16 slot
EATXPWR1 ATX 2.0 24-pin power connector
EATPWR1 AT 12-pin Power connector
ATX 12 V Auxiliary 4-pin power
ATX 12 V Auxiliary 4-pin power
EATX12V1 ATX 12 V 8-pin power connector
EATX12V2 ATX 12 V 8-pin power connector
PWR3V1 3.3 V Auxiliary power connector
PWR3V2 3.3 V Auxiliary power connector
ATX 5V & 12V 4-pin power con-
FAN1 ~ FAN7 Fan connectors
FANDEC1 Fan speed detect connector
Chassis sensor board connectors
JFP1 Power and reset button connector
ATX feature Connector (5 VSB,
PSON) for Advantech redundant
power supply: 1757001757,
Connectors and Jumpers Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com/eplatform
For technical support and service, please visit our
http://www.advantech.com/support/
This manual is for PCE-5B12-00A1E.
