PCIE-1803 Startup Manual 1

Before installation, please make sure that you have re-

ceived the following:

• PCIE-1803 DAQ card

• Quick Start User Manual

If anything is missing or damaged, contact your distributor

or sales representative immediately.

User Manual

For more detailed information on this product, please refer

to the PCI-1803 User Manual on Advantech Support Portal:

https://support.advantech.com/support/new_default.aspx.

FCC Class A

This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when

the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio fre-

quency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference

to radio communications. Operation of this equipment in

a residential area is likely to cause interference in which

case the user is required to correct interference at his own

expense.

This product has passed the CE test for environmental

specicationswhenshieldedcablesareusedforexternal

wiring. We recommend the use of shielded cables. This kind

of cable is available from Advantech. Please contact your

local supplier for ordering information.

PCIE-1803

8-ch, 24-Bit, 128 kS/s Dynamic Sig-

nal Acquisition PCI Express Card

Startup Manual

The Advantech PCIE-1803 is a high-performance data

acquisitionmodulespecicallydesignedforsoundand

vibration applications.

• AIChannels:8(simultaneouslysample,di󰀨erentialor50

Ωpseudo-di󰀨erential)

• ADCResolution:24bits(Delta-sigma)

• SampleRate:1kS/sto128kS/s(withresolution≤272.84

μS/s)

• Input Range: ±1, ±2, ±5, ±10 V

• Input Coupling: AC/DC, selectable per channel

• Input over-voltage protect

• Full auto-calibration

• Built-inanti-aliasinglter

• IEPE Excitation: Disabled, 2 mA, selectable per channel

• Board-to-board synchronization

• DIChannels:1(interrupt)

• DO Channels: 2

(Fordetailspecications,pleaserefertotheusermanualof

PCIE-1803)

General

• Bus Type: PCI Express x1

• I/O Connectors:

1x36-pinMini-SCSI(forAI),

1xHDMI(forclock,trigger,andDI/Os)

2xIDC10(forsynchronization)

• Dimensions(LxH):168x98mm(6.6”x3.9”)

• OperatingTemperature:0~70°C(32~158°F)

• StorageTemperature:-40~80°C(-40to176°F)

• StorageHumidity:5~95%RH,non-condensing

We recommend installing the driver before installing the

PCIE-1803 card to guarantee problem-free installation.

The Advantech DAQNavi Device Drivers setup program

or the PCIE-1803 can be downloaded from the Advantech

website(www.advantech.com).Followthestepsoutlined

below to install the driver software.

1. Execute the PCIE-1803 driver package.

2. The driver installation program should be launched.

When the setup program is launched, a setup screen

will be displayed.

3. Clickthe“Next”buttonandwaitfordriverinstallation.

4. Clickthe“Finish”buttontoexitthesetupprogram.

Overview Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://support.advantech.com

This manual is for the PCIE-1803.

Part No. 2041180300

Printed in Taiwan

1st Edition

November2019

Declaration of Conformity

Specications

Driver Installation

2 PCIE-1803 Startup Manual

1. Turno󰀨yourcomputerandunplugthepowercordandcables.TURNOFFyourcomputerbeforeinstallingorremoving

any components.

2. Remove the cover of your computer.

3. Remove the slot cover on the back panel of your computer.

4. Touch the metal part on the surface of your computer to neutralize the static electricity that might be on your body.

5. Insert the PCIE-1803 card into a PCI Express slot. Hold the card only by its edges and carefully align it with the slot. Insert

thecardrmlyintoplace.Useofexcessiveforcemustbeavoided;otherwise,thecardmightbedamaged.

6. Fasten the bracket of the PCIE-1803 card on the back panel rail of the computer with screws.

7. Connectappropriateaccessories(suchassource/syncsignalcables,wiringterminals,etc.ifnecessary)tothecard.

8. Replace the cover of your computer chassis. Re-connect the cables you removed in step 1.

9. Plug in the power cord and turn on the computer.

Hardware Installation

Block Diagram
