PPC-415W/421W Startup Manual 1

Before installation, ensure that the following items are

included with the product:

1. 1 x Panel PC

2. 1 x PPC-415W/PPC-421W startup manual

3. 2 x Phoenix connector

4. 10/12 x Mount brackets (12 for PPC-421W, 10 for

PPC-415W)

5. 10/12 x Mount screws (12 for PPC-421W, 10 for PPC-

415W)

If any of the above items are missing or damaged, contact

your distributor or sales representative immediately.

Before installing software on the panel PC, install the cor-

responding drivers to ensure full functionality.

All drivers can be downloaded from the Advantech website

at http://www.advantech.com.

PPC-415W/PPC-421W 15.6”/21.5” Panel PC with

TFT LCD and 13th Gen Intel

Core

i Processor

Startup Manual

Front View

Rear View

VESA mount screws: 4 x M4 screws

Screw depth: 8 mm (max.)

A. 1 x Expansion slot (PCI or PCIe x1)

B. 1 x Mic-In/Line-Out C. 2 x Intel Gigabit Ethernet

D. 1 x DisplayPort E. 2 x RS-232

F. 1 x Isolated RS-422/485 G. 1 x Power button

H. 1 x DC Input and AT/ATX switch

I. 1 x HDMI J. 3 x USB 3.2, 1 x USB 2.0

K. 2 x RS-232 (right side, optional)

D E F G

J I H

Packing List

For more information about this product, visit the

Advantech website at

http://www.advantech.com/products/fanless-panel-

pcs/sub_1-2jkjm3

For technical support and customer service, visit the

Advantech support website at

http://support.advantech.com/support/new_de-

fault.aspx

This manual is for PPC-415W/421W series, Rev. A0.

Part No. 2041421W00

Printed in China

Edition 1

November 2023

Appearance

I/O Layout

Software Installation

2 PPC-415W/421W Startup Manual

Specications

Product PPC-415W PPC-421W

LCD Display 15.6" 21.5"

Display Type 15.6" TFT LCD (LED backlight) 21.5" TFT LCD (LED backlight)

Resolution Max. 1920 x 1080 1920 x 1080

Brightness 450 cd/m

300 cd/m

Color 16.7M 16.7M

Viewing Angle 85 (Left), 85 (Right), 85 (up), 85 (Bottom) 89 (Left), 89 (Right), 89 (Up), 89 (Down)

Contrast 800 1000

Backlight Lifetime 50, 000 hours 30, 000 hours

Touchscreen type Multi-touch projected capacitive

Light Transmission 88 % ± 2 %

Controller USB interface

CPU Intel

Core™i7-1365URE/i5-1345URE/i3-1315URE

Memory 2 x SODIMM, DDR5 4800, max. 32GB x 2

Storage

1 x 2.5" SATA bay; 1 x M.2 2242/2280 M Key

slot for Storage (SATA or NVME PCIe x 4,

support SATA RAID)

2 x 2.5" SATA bay (supports Intel RAID); 1 x

M.2 2242/2280 M Key slot for Storage (SATA or

NVME PCIe x 4, support SATA RAID)

Network (LAN) 2 x Intel I226LM controller; Speed: 10M/100M/1000M/2.5G

I/O Ports

5 x Serial ports: 2 x RS-232, 1 x RS-422/485 with 1K V

isolation,2 x RS-232 (on right side

optional)

3 x USB3.2, 1 x USB2.0

1 x Line-Out, 1 x Mic-In

1 x HDMI 1.4

1 x DisplayPort (1.4a)

1 x 8bit GPIO (Optional)

Hardware Security 1 x TPM2.0

Expansion

1 x M.2 2230 E Key slot for wireless card

1 x PCIe x 4; 1 x PCI (optional)

Speaker 2 x 1W

OS Support Microsoft

Windows 11 (64 bit),Win 10 IOT LTSC, Linux

Power Supply 9 - 32 Vdc

Power Consumption Typ.70W Max.105W Typ.75W Max.110W

Operating Temperature -20 ~ 60 °C (-4 ~ 140 °F)

Storage Temperature -40 ~ 60 °C (-40 ~ 140 °F) -30 ~ 60 °C (-22 ~ 140 °F)

Relative Humidity 95% @ 40°C (non-condensing)

Shock Operating 10 G Peak Acceleration (11 ms Duration), Follows IEC 60068-2-27

Vibration Operating random vibration test, 5 ~ 500Hz, 2Grms with SSD, following IEC 60068-2-64

Safety and EMC

Safety: CB, UL, CCC, UKCA

EMC: CE, FCC Class B, VCCI,UKCA, BSMI

Dimensions

419.70mm x 269.00mm x 59mm

(16.5 x 10.6 x 2.3 in)

558.4x 349.8 x 63.8 mm

(21.9 x 13.7 x 2.5 in)

Weight 5.4kg (11.9 lb) 7.67kg (16.9lb)
