AEG SB2E 750 R SuperTorque Manual

AEG Slagboremaskiner SB2E 750 R SuperTorque

Læs gratis den danske manual til AEG SB2E 750 R SuperTorque (84 sider) i kategorien Slagboremaskiner. Denne vejledning er vurderet som hjælpsom af 39 personer og har en gennemsnitlig bedømmelse på 4.7 stjerner ud af 20 anmeldelser. Har du et spørgsmål om AEG SB2E 750 R SuperTorque, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/84
GB
D
F
I
E
P
NL
DK
S
SF
TR
RUS
RC
SBE 600 R
SB2E 680 R
SB2-700
SB2E 700 R
SB2E 700 RS
SB2E 705 PLUS
SB2E 750 R
SB2E 760 R
Instructions for use
Please read and save these
instructions.
Gebrauchsanleitung
Bitte lesen und aufbewahren.
Instruction d’utilisation
Prière de lire et de conserver.
Istruzioni d’uso
Si prega di leggere le istruzioni e
di conservarle.
Instrucciones de uso
Lea y conserve estas
instrucciones por favor.
Instruções de serviço
Por favor leia e conserve em seu
poder.
Gebruiksaanwijzing
Lees en let goed op deze
adviezen.
Brugsanvisning
Vær venlight at læse og
opbevare.
Bruksanvisning
Var god läs och tag tillvara dessa
instruktioner.
Käyttöohje
Lue ja säilytö
Kullanøm kølavuzu
Lütfen okuyun ve saklayin
Èíñòðóêöèÿ ïî
èñïîëüçîâàíèþ
Ïîæàëóéñòà, ïðî÷òèòå è
ñîõðàíèòå íàñòîÿùóþ
èíñòðóêöèþ
12
1
ENGLISH SBE 600 R, SB2E 680 R, SB2-700, SB2E 700 R, SB2E 700 RS, SB2E 705 PLUS, SB2E 750 R, SB2E 760 R
You have high standards and expect to purchase quality goods – quality offered by
Atlas Copco.
We have built a durable and reliable electric power tool for you.
Please read the instructions for use before first operation so you can handle your
power tool effectively and safely.
We are sure that buying an AEG Electric Power Tool from Atlas Copco was the right
choice!
SBE 600 R SB2E 680 R SB2–700
Nominal power 600 W 705 W 700 W. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
No-load speed 0–3100 min-1
. . . . . . . . . . . . .
1st gear 0–1350 min-1 1500 min-1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2nd gear 0–3200 min-1 3600 min-1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Percussion rate 49600 min-1 51200 min-1 51200 min-1
. . . . . . . . . . . . . . . . . . .
Drilling capacity in
Concrete 20 mm 20 mm 20 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brick and tile 20 mm 24 mm 24 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steel 13 mm 13 mm 13 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wood 35 mm 40 mm 40 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drill opening range 1,5-13 mm 1,5-13 mm 1,5–13 mm. . . . . . . . . . . . . . . . . .
Drive shank 1/2
” ” ”x20 1/2 x20 1/2
x20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chuck neck diameter 43 mm 43 mm 43 mm. . . . . . . . . . . . . . . . . . . . . . . . . .
Weight 1,9 kg 2,2 kg 2,2 kg. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SB2E 700 R SB2E 750 R SB2E 760 R
SB2E 700 RS
SB2E 705 PLUS
Nominal power 705 W 750 W 760 W. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
No-load speed
1st gear 0–1350 min-1 0 1350 min–-1 0 1350 min–-1
. . . . . . . . . . . . . . . . . . . . .
2nd gear 0–3200 min-1 0 3200 min–-1 0 3200 min–-1
. . . . . . . . . . . . . . . . . . . . .
Percussion rate 51200 min-1 51200 min-1 51200 min-1
. . . . . . . . . . . . . . . . . . .
Drilling capacity in
Concrete 20 mm 20 mm 20 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brick and tile 24 mm 24 mm 24 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steel 13 mm 13 mm 13 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wood 40 mm 40 mm 40 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drill opening range 1,5
– –13 mm 1,5
13 mm 1,5-13 mm. . . . . . . . . . . . . . . .
Drive shank 1/2
” ” ”x20 1/2 x20 1/2
x20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chuck neck diameter 43 mm 43 mm 43 mm. . . . . . . . . . . . . . . . . . . . . . . . . .
Weight 2,5 kg 2,5 kg 2,5 kg. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
J Please pay attention to the safety instructions in the attached leaflet!
J Dust that arises when working on material containing asbestos or stonework
containing crystalline silicic acid is harmful to the health. Please follow accident
prevention regulations.
J Appliances used at many different locations including open air must be connected
via a current surge preventing switch.
J Always wear goggles when using the machine. It is recommended to wear gloves,
sturdy non slipping shoes and apron.
J Sawdust and splinters must not be removed while the machine is running.
J Do not pierce the motor housing as this could damage the double insulation (use
adhesives).
J Always disconnect the plug from the socket before carrying out any work on the
machine.
Only plug-in when machine is switched off.
J Keep mains lead clear from working range of the machine. Always lead the cable
away behind you.
J Always use the auxiliary handle, even if the machine has a safety clutch since this
safety clutch only engages when the machine blocks with a jerk.
J Do not use diamond core drills on hammer mode.
J When drilling in walls ceiling, or floor, take care to avoid electric cables and gas or
waterpipes.
Introduction
Technical Data
Advice for your
safety
