USER MANUAL
1. SAFETY INSTRUCTIONS
Please read the instructions carefully. They contain important information about the installation,
operation and maintenance.
• Please keep this User Manual for future reference. If you sell the unit to another user, be sure that
he also receives this instruction booklet.
• Unpack and check the unit carefully that it has not been damaged during transport before using
the unit.
• Before operating, ensure that the voltage and frequency of power supply match the power requi-
rements of the unit.
• The unit should be connected to a main socket outlet with a protective earth connection
• The unit is for indoor use only in a dry location.
• The unit must be installed in a location with adequate ventilation, at least 0.5m from adjacent
surfaces. Be sure that no ventilation slots are blocked.
• Disconnect mains power before fuse replacement or servicing.
• Replace fuse only with the same type.
• Makesuretherearenoinammablematerialsclosetotheunitduringoperation.
• Usesafetycablewhenxingthisunit.
• In the event of serious operating problem, stop using the unit immediately.
• Never try to repair the unit by yourself. Repair carried out by unskilled people can lead to damage
or malfunction. Please contact the nearest authorized technical assistance center and always use
the same type of spare parts.
• Do not touch any wires during operation as high voltage might be causing electric shock.
• The product is for decorative purposes only and not suitable as a household room illumination.
DISCONNECT DEVICE
Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable.
2. SPECIFICATIONS
PROPAR6-HEX PROPAR12-HEX PROPAR18-HEX
Power supply 110-240V~ 50/60Hz
Consumption 60W 105W 180W
Fuse T1A, 250V T2A, 250V T3.15A, 250V
DMX control channels 6 / 8 / 12 / HSV + HSI
DMX512 Connection 3-pin XLR 3-pin XLR 3- & 5-pin XLR
LED type 12W 6-in-1 RGBWA+UV
Number of LEDs 6 12 18
Beam angle 25°
Max.housingtemp. 65°C 75°C 75°C
Min.distancetoammablesurfaces 0.5m
Min. distance to lighted objects 0.1m
Dimensions 235x215x110mm 280x280x110mm 310x310x110mm
Weight 2.6kg 3.2kg 5.2kg
EN 2
